USB-1608FS User's Guide

Microcontroller

Type
Program memory
Data memory

Power

Parameter
Supply current
Supply current (Note 6)
+5 V USB power available
(Note 7)
Output current (Note 8)
This is the total current requirement for the USB-1608FS which includes up to 10 mA for the
Note 6:
status LED.
"Self-powered hub" refers to a USB hub with an external power supply. Self-powered hubs allow
Note 7:
a connected USB device to draw up to 500 mA. "Root port hubs" reside in the PC's USB host
Controller. The USB port(s) on your PC are root port hubs. All externally-powered root port hubs
(desktop PC's) provide up to 500 mA of current for a USB device. Battery-powered root port
hubs provide 100 mA or 500 mA, depending upon the manufacturer. A laptop PC that is not
connected to an external power adapter is an example of a battery-powered root port hub. If your
laptop PC is constrained to the 100 mA maximum, you need to purchase a self-powered hub.
This refers to the total amount of current that can be sourced from the USB +5 V and digital
Note 8:
outputs.
General
Device type
Device compatibility
Environmental
Operating temperature range
Storage temperature range
Humidity
Mechanical
Dimensions
USB cable length
User connection length
Table 10. Microcontroller specifications
High performance 8-bit RISC microcontroller
16,384 words
2,048 bytes
Conditions
USB enumeration
Continuous mode
! Connected to self-powered hub
! Connected to externally-powered root port hub
USB 2.0 (full-speed)
USB 1.1, USB 2.0
0 to 70 °C
-40 to 70 °C
0 to 90% non-condensing
79 mm (L) x 82 mm (W) x 25 mm (H)
3 meters max
3 meters max
4-4
Specifications
Specification
< 100 mA
150 mA
4.5 V min, 5.25 V max
350 mA max
