Ethernet Communication

The SCADAPack 32P controller has one 10BaseT Ethernet port. 10BaseT is a single
communications channel running at 10MHz over unshielded, twisted - pair cabling. 10BaseT uses
differential signaling.
5.1

LAN Port Settings

Connections to the LAN port are made through a RJ-45 modular connector. The wiring and pin
connections for this connector are described in section 5.1.3-RJ-45 Modular Connector for
Ethernet.
Refer to section 3.1-Field Wiring Connections for the location of the LAN port on the SCADAPack
32P.
5.1.1

TCP/IP Settings

The following table shows the TCP/IP parameters supported by the LAN port. These parameters are
set from the ISaGRAF Workbench or from an application program running in the SCADAPack 32P
controller. Default values are set when a Cold Boot is performed on the SCADAPack 32P controller.
Parameter
IP Address
Subnet Mask
Gateway
The IP Address is the address of the controller. The IP address is statically assigned. Contact your
network administrator to obtain an IP address for the controller.
The Subnet Mask is determines the subnet on which the controller is located. The subnet mask is
statically assigned. Contact your network administrator to obtain the subnet mask for the controller.
The Gateway determines how your controller communicates with devices outside its subnet. Enter
the IP address of the gateway. The gateway is statically assigned. Contact your network
administrator to obtain the gateway IP address.
5.1.2

Modbus/TCP Settings

The following table shows the Modbus/TCP parameters supported by the LAN port. These
parameters are set from the ISaGRAF Workbench or from an application program running in the
SCADAPack 32P controller. Default values are set when a Cold Boot or Service Boot is performed
on the SCADAPack 32P controller.
Parameter
Master Idle Timeout
Server Receive Timeout
Maximum Server
Connections
SCADAPack 32P Controller Hardware Manual
May 26, 2006
Supported Values
In the format 255.255.255.255
Default: 0.0.0.0
In the format 255.255.255.255
Default: 0.0.0.0
In the format 255.255.255.255
Default: 0.0.0.0
Supported Values
Any value in seconds.
Default: 10 seconds
Any value in seconds.
Default: 10 seconds
Valid values are 1 to 20.
Default: 20
