1 Part Names and Positions

Please check names and positions of each part with the following image.
Terminal connector
* Model design and appearance are subject to change without any prior notice.
CAUTION:
Make sure the polarity is correct. Incorrect connection may cause malfunction or damage the IP device.
10225 Westmoor Drive, Suite 300, Westminster, CO 80021 | www.3xlogic.com | (877) 3XLOGIC
Video Out
GREEN : DI
WHITE : DI
COM
ORNAGE : DO
LAN / POE
connector
Power Adaptor connector
VISIX Camera Quick Start Guide | VX-2A-B-IWD (R)
SD Card
Reset
Power Adaptor Connector (DC 12V)
3
