5. Get connected

There are different ways to connect the Remote Control to your desk(s). This User
Manual describes some of those connection set-ups. For other system lay-outs
please contact ADB's ISIS
The following chapter describes these configurations:
• Basic Connection: one lighting desk and one Access Point.
• Standard Connection: one/several desks and one/several Access Points.
• Customized Connection: one/several desks and one/several Access Points,
with security (Access Control).

5.1. Basic Connection

Connect a standalone desk or a Master/Slave system with one Access Point.
Hardware & Software Requirements:
• Pocket PC with Win Mobile 2003 and integrated wireless LAN
• ADB Wi-Fi Software
• An Ethernet Switch is required in case of a Master/Slave system
• Wireless Access Point : D-link DWL-200AP
• Ethernet cables (the selected WAP is Auto-MDI/MDIX
• Desk with ISIS
5.2. Standard and Customized Connection
These set-ups are suitable to connect one or more desks with one or more Access
Points.
Hardware & Software Requirements:
• Pocket PC Win Mobile 2003 and integrated wireless LAN
• ADB Wi-Fi Software
• Wireless Access Point : D-link DWL-200AP
• ADB Desk with ISIS
• Ethernet Switch (is not required when using one desk, one Access Point and
the distance between Desk and Access Point does not exceed 100 m.)
• Ethernet cables (one cable for each node
2
The Ethernet Port on the DWL-2000AP is Auto-MDI/MDIX. You can use either a standard or a
cross-link Ethernet cable to connect the Ethernet port of the DWL-2000AP to an Ethernet switch or a
console
3
A node is any device connected to a network. Nodes can be computers, personal digital assistants
(Pocket PC), lighting desks, or other network appliances.
®
Support team. E-mail
®
2.10 software
®
2.10 software (or later)
www.adblighting.com
ADB Wi-Fi Remote Control
isissupport@adblighting.com
2
)
3
)
Manual – page 5
Issue: 1.03
