ADB Wi-Fi Remote Control
• AP Name: the name you choose for the Access Point (e.g. AP UpStage
Left)
• SSID
11
: the name you choose for the WLAN (e.g. Studio1)
• Channels: your Channel number => You can change the setting to match
an existing wireless network (Default setting is channel 6)
• WEP: Enabled / Disabled => Change the encryption settings, for more
secure wireless communication
• WEP Encryption: select 64 Bit or 128 Bit
• WEP Mode: HEX
• Key: Enable key index 1 and give a key 1 =>
Do not use the number shown in the example (1234567890).
Write down this WEP Key number; you will need it later on to configure the
Pocket PC.
Press Apply to finalize the setup of the Access Point.
Note: SSID => must be identical for all Access Points on the same network!
11
A service set identifier (SSID) is a sequence of characters that uniquely names a wireless local area network.
Manual – page 16
Issue: 1.03
www.adblighting.com
64 bit = 10 digits
128 bit = 26 digits
