CDP-01
Additional Instruction Manual
For Recoiler Application With Staggerwind
Using SE-34 Sensor And SBPC-2X (MS:100279)
CDP-01
02-04-03
Figure Sheet 1-856-A

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CDP-01 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Fife CDP-01

Summary of Contents for Fife CDP-01

  • Page 1 CDP-01 Additional Instruction Manual For Recoiler Application With Staggerwind Using SE-34 Sensor And SBPC-2X (MS:100279) CDP-01 02-04-03 Figure Sheet 1-856-A...
  • Page 2 CDP-01 02-04-03 Figure Sheet 1-856-A...
  • Page 3 These additional instructions explain the special features of the system delivered to the customer. They are intended for being used in conjunction with the CDP-01 Reference Manual. The CDP-01 Reference Manual applies except as noted to the contrary in these instructions.
  • Page 4 CDP-01 02-04-03 Figure Sheet 1-856-A...

  • Page 5: Table Of Contents

    OPERATOR CONTROL OPTIONS ..................2-1 SPECIAL FEATURES OF EXTERNAL CONTROL ..............2-1 EXTERNAL CONTROL......................2-2 CONTROL MATRIX .......................2-2 CDP-01 DATA ........................2-3 EXPLANATION OF THE OPERATING MODES............2-4 to 2-5 EXPLANATION OF THE SENSOR MODES.................2-5 START UP / POSITION TRANSDUCER CALIBRATION .............2-6 START UP / SENSOR BANDWIDTH TO MANDREL RATIO CALIBRATION .....2-7 START UP / MANDREL DRIVE POLARITY .................2-8...
  • Page 6 CDP-01 02-04-03 Figure Sheet 1-856-A...

  • Page 7: General Introduction

    A CDP-01-H12 or CDP-01-M12 with FifeNet firmware is required for this application. Software Part Numbers The software part numbers are located on the side of the CDP-01 housing. They include the Matrix Setup no. (MS), State Machine no. (SM) and firmware version ( Dx ).
  • Page 8 CDP-01 02-04-03 Figure Sheet 1-856-A...

  • Page 9: Overview Of Function

    OVERVIEW OF FUNCTION Operator Control Options The CDP-01 signal amplifier can be operated by way of the CDP-01 control panel (internal operation) for setup purposes only. For normal operation, control through the SBPC must be used (external control). Control is to be supplied from a remote control panel or programmable logic controller.

  • Page 10: External Control

    ‘23’. RGPC shift left in Seek Overide with oscillation off would be a hex value of ‘1A’.) NOTE: If the Control Matrix is set to ‘00’, the CDP-01 will change to Manual mode. CDP-01...

  • Page 11: Cdp-01 Data

    SM Command Feedback Reserved for state machine control. WORD SM Status Feedback Reserved for state machine control. WORD Key Pressed Current key pressed on CDP-01. WORD Drive 1 Operation Mode Drive 1 status. WORD Drive 1 Sensor Mode Drive 1 status.

  • Page 12: Explanation Of The Operating Modes

    Press the - or + key to set ‘Left’ or ‘Right’ to manually alter the position of the drive. ‘Right’ JOG MANDREL LEFT / RIGHT Select ‘Jog Mandrel Left’ or ‘Jog Mandrel Right’ via external control to manually alter the position of the mandrel. CDP-01 02-04-03 Figure Sheet 1-856-A...

  • Page 13: Explanation Of The Sensor Modes

    The mandrel drive is switched to Automatic. The mandrel now follows the sensor output signal. The guide point or system gain can be altered, if desired. Reference: CDP-01 Reference Manual, ‘Basic Settings’ section. CENTER MANDREL Select ‘Center Mandrel’ via external control.

  • Page 14: Start Up / Position Transducer Calibration

    The LED bar graph indicates contrast. If the contrast is too low an error message is displayed (left and right outer LEDs flash). Press the Automatic key to store the settings. Press the Manual key to abort the procedure. CDP-01 02-04-03 Figure Sheet 1-856-A...

  • Page 15: Start Up / Sensor Bandwidth To Mandrel Ratio Calibration

    CDP-01. Locate the end of the SE-34 sensor bandwidth by moving the web edge away from the junction box until the sensor begins to scan.

  • Page 16: Start Up / Mandrel Drive Polarity

    If the mandrel moves to either end, press the Manual key and change the Servo Center polarity. Reference: CDP-01 Reference Manual, section “Servo Center Polarity”. If the mandrel oscillates, press the Manual key and change the Servo Center gain.

  • Page 17: Troubleshooting

    SUPPLEMENTARY OPERATING MANUAL TROUBLESHOOTING An incorrect setting on the CDP-01 is often the cause for incorrect or unwanted guiding characteristics. Faults and the procedures for rectifying the faults are described in more detail in the CDP-01 Reference Manual, chapter ‘Frequent setting errors’. Application-specific faults are explained below.
  • Page 18 CDP-01 02-04-03 Figure Sheet 1-856-A...
