CDP-01
Additional Instruction Manual
For Armless Recoiler Application
With Staggerwind (Variable Ratio)
Using SE-21A Sensor And SBPC (MS: 100333)
CDP-01
05-19-06
Figure Sheet 1-900
© 2006 Fife Corporation. All rights reserved.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CDP-01 and is the answer not in the manual?

Questions and answers

Related Manuals for Fife CDP-01

Summary of Contents for Fife CDP-01

  • Page 1 CDP-01 Additional Instruction Manual For Armless Recoiler Application With Staggerwind (Variable Ratio) Using SE-21A Sensor And SBPC (MS: 100333) CDP-01 05-19-06 Figure Sheet 1-900 © 2006 Fife Corporation. All rights reserved.
  • Page 2 CDP-01 05-19-06 Figure Sheet 1-900 © 2006 Fife Corporation. All rights reserved.
  • Page 3 These additional instructions explain the special features of the system delivered to the customer. They are intended for being used in conjunction with the CDP-01 Reference Manual. The CDP-01 Reference Manual applies except as noted to the contrary in these instructions.
  • Page 4 CDP-01 05-19-06 Figure Sheet 1-900...

  • Page 5: Table Of Contents

    START UP / GUIDING SENSOR CALIBRATION (GUIDE CHANNEL) ....... 2-9 START UP / GUIDING SENSOR CALIBRATION (REFERENCE CHANNEL)....2-10 START UP / SENSOR DRIVE POLARITY ................ 2-11 START UP / MANDREL DRIVE POLARITY ..............2-12 TROUBLESHOOTING FAULT DIAGNOSIS - FAULT RECTIFICATION..............3-1 CDP-01 05-19-06 Figure Sheet 1-900...
  • Page 6 CDP-01 05-19-06 Figure Sheet 1-900...

  • Page 7: General Introduction

    CDP-01-MHH with FifeNet firmware is required for this application. Software Part Numbers The software part numbers are located on the side of the CDP-01 housing. They include the Matrix Setup no. (MS), State Machine no. (SM) and firmware version ( Dx ).
  • Page 8 CDP-01 05-19-06 Figure Sheet 1-900...

  • Page 9: Overview Of Function

    OVERVIEW OF FUNCTION Operator Control Options The CDP-01 signal amplifier can be operated by way of the CDP-01 control panel (internal operation) for setup purposes only. For normal operational control, the parallel port (external operation) must be used. Control is to be supplied from a remote control panel or programmable logic controller.

  • Page 10: Input Matrix - External Control

    SM Status Feedback Reserved for State Machine control. WORD Common Status Register CDP-01 status WORD Key pressed Current key pressed on CDP-01 panel. WORD Drive 2 Operation Mode Drive 2 mode status WORD Drive 2 Sensor Mode Drive 2 sensor status...

  • Page 11: Explanation Of The Operating Modes

    Check: LED (3) lit. Setup functions can be performed and sensor modes selected, if desired. ‘Left’ Press the - or + key to set ‘Left’ or ‘Right’ to manually alter the position of the drive. ‘Right’ CDP-01 05-19-06 Figure Sheet 1-900...
  • Page 12 STATUS - The mandrel drive is switched to Automatic. mandrel now follows the position of the sensor positioner. The guide point or system gain can be altered, if desired. Reference: CDP-01 Reference Manual, ‘Basic Settings’ section. CDP-01 05-19-06 Figure Sheet 1-900...
  • Page 13 Note: Jogs are not allowed in Automatic mode JOG SENSOR OUT / IN Select ‘Jog Sensor Out’ or ‘Jog Sensor In’ via external control to manually alter the position of the sensor. Note: Jogs are not allowed in Automatic mode CDP-01 05-19-06 Figure Sheet 1-900...

  • Page 14: Start Up / Position Transducer Calibration

    The LED bar graph indicates contrast. If the contrast is too low an error message is displayed (left and right outer LEDs flash). Press the Automatic key to store the settings. Press the Manual key to abort the procedure. CDP-01 05-19-06 Figure Sheet 1-900...
  • Page 15 The LED bar graph indicates contrast. If the contrast is too low an error message is displayed (left and right outer LEDs flash). Press the Automatic key to store the settings. Press the Manual key to abort the procedure. CDP-01 05-19-06 Figure Sheet 1-900...

  • Page 16: Start Up / Sensor Bandwidth To Mandrel Ratio Calibration

    Note: If it is desired to abort this procedure, press and hold the Manual key until LED 5 turns off. The previous calibration is retained. When the calculations are complete (approximately 30 additional seconds), LED 5 will turn off. CDP-01 05-19-06 Figure Sheet 1-900...

  • Page 17: Start Up / Guiding Sensor Calibration (Guide Channel)

    Press and hold the Left or Right Jog key until the web completely covers the sensor field of view. Press the F2 key. Press the Automatic key to store the settings. Press the Manual key to abort the procedure. CDP-01 05-19-06 Figure Sheet 1-900...

  • Page 18: Start Up / Guiding Sensor Calibration (Reference Channel)

    Press and hold the Left or Right Jog key until the web completely covers the sensor field of view. Press the F2 key. Press the Automatic key to store the settings. Press the Manual key to abort the procedure. CDP-01 05-19-06 Figure Sheet 1-900...

  • Page 19: Start Up / Sensor Drive Polarity

    If the sensor moves the wrong direction, press the Manual key and change the Servo Center polarity. Reference: CDP-01 Reference Manual, section “Servo Center Polarity”. Sensor Automatic Polarity Select Drive 3 by pressing key 20.

  • Page 20: Start Up / Mandrel Drive Polarity

    If the mandrel moves to either end, press the Manual key and change the Servo Center polarity. Reference: CDP-01 Reference Manual, section “Servo Center Polarity”. If the mandrel oscillates, press the Manual key and change the Servo Center gain.

  • Page 21: Troubleshooting

    SUPPLEMENTARY OPERATING MANUAL TROUBLESHOOTING An incorrect setting on the CDP-01 is often the cause for incorrect or unwanted guiding characteristics. Faults and the procedures for rectifying the faults are described in more detail in the CDP-01 Reference Manual, Chapter ‘Frequent Setting Errors’.
  • Page 22 FIFE CORPORATION 222 W. Memorial Road, Oklahoma City, OK 73114-2317, USA / Post Office Box 26508, Oklahoma City, OK 73126-0508, USA Phone: 405.755.1600 / 800.639.3433 / Fax: 405.755.8425 / E-mail: fife@fife.com / Web: www.fife.com CDP-01 05-19-06 Figure Sheet 1-900...
