Dear Customer,
We are very pleased that you have decided to purchase our POWER BOX 40/16.
With this newly developed product you now have a powerful Dual-Power-control
system for your valuable model aeroplane. This will allow you to have not only the
extra safety advantage of coupling two on board flight battery-packs. But to also
have permanent control of the momentary voltage of each battery-pack.
Furthermore this latest Dual-Power control unit also includes one powerful servo-
amplifier for each of the four receiver-channels. This special feature will enable you
to connect several servos to each receiver line out.
Although this new Dual-Power-Control unit is extremely easy to handle you will
need to have some knowledge for it's correct use. This comprehensive manual will
therefore help you to quickly familiarise yourself with your new accessory.
However, in order to fully understand the advantages and safety features of this
unit all we ask is that you carefully read this manual right through before you
commence using your new Dual-Power-Control. We sincerely hope you'll enjoy
the many safety features we have built into your new POWER-BOX 40/16.

Table of contents

1. Functions of the Dual-Power-Control system........................... Page 2
2. Unit Specifications.................................................................. Page 4
3. Connections and operation controls........................................ Page 5
4. Information on usage and security .......................................... Page 6
5. Warranty information............................................................... Page 7
6. Additional equipment.............................................................. Page 7
1. Function of the Dual-Power control
The POWER BOX 40/16 is a Dual-Power-Control system which besides it's main
function of being a power control unit - it also displays the momentary voltage of
both of the two connected battery packs by a line of 5 ultra bright LEDs. Therefore
you are always able to check the exact voltage of the two battery packs. This
feature allows you to continually check if there's enough energy left in either of your
two battery packs for another long thermic-flight.
In addition you can also connect up to four servos covering the four most important
channels of your model-aeroplane to the Dual-Power-Control without causing any
problems. This is because the servo-pulses for each of the four channels connected
POWER BOX 40/16
- 2 -
