TECHNICAL FEATURES
Power Supply
Input Power (27 C - 65% U.R.)
Max Input Power (32 C - 80% U.R.)
Dehumidification Capacity 27 C - 65% U.R. (liters)
Dehumidification Capacity 32 C - 80% U.R. (liters)
Fan Speeds
Refrigerant type
Refrigerant quantity
Air Flow
Tank Capacity (liters)
Dimensions (HxWxD) mm
Weight
Noise level (sound pressure)
Noise level (sound power)
Water Proof Level
OPERATING WORKING LIMITS
Max working conditions in dehumidification mode: DB / WB
Min working conditions in dehumidification mode: DB / WB
Secco Prof
230V - 50Hz
520 W – 2,2A
620 W – 2,7A
18 /24 h
28 /24 h
1
R 134A
0,230 kg
3
380 m
/h
10
720 x 310 x 450
27 kg
53 dB(A)
62 dB(A)
IPX1
35° C/31°C
2° C/1° C
Advertisement
Table of Contents
Related Manuals for Olimpia splendid Secco Prof
Summary of Contents for Olimpia splendid Secco Prof
- Page 1 TECHNICAL FEATURES Secco Prof Power Supply 230V - 50Hz Input Power (27 C - 65% U.R.) 520 W – 2,2A Max Input Power (32 C - 80% U.R.) 620 W – 2,7A Dehumidification Capacity 27 C - 65% U.R. (liters) 18 /24 h Dehumidification Capacity 32 C - 80% U.R.
-
Page 2: Selecting Functions
INTRODUCTION The dehumidifier is fitted with an electronic logic system which controls operation and optimises consumption and performance. The keys and information on the control panel have the following meanings 1) Start / Stand-by key 2) Desired humidity / temperature increment key 3) Desired humidity / temperature decrement key 4) Humidity indication key 5) Detected ambient humidity(blinking) / Selected humidity... -
Page 3: Function Details
FUNCTION DETAILS • DEHUMIDIFICATION indicated by the "drop" symbol light on the control panel. Compressor and fan are switched on if the minimum OFF time (Cf) has elapsed and if the relative humidity value is higher than the set point + 3; compressor and fan remain ON as long as the relative humidity value is above the set point –... -
Page 4: Alarm Codes
ALARM CODES Display Likely Cause Suggested Solution Indication "Hr" flashing Relative humidity drops below very low values (<22%). Activate the dehumidifier with higher ambient humidity conditions. Humidity sensor broken. Change humidity sensor or whole PCB (according to the model). "tE" flashing The ambient evaporator temperature sensor Change ambient temperature is damaged. - Page 5 SECCO PROF WIRING DIAGRAM A1 = Electronic card (power); A2 = Electronic card (control); B1 = Humidity feeler; B2 = Evaporator sensor; F1 = Compressor thermal cut-out; K1 = Compressor relay; K2 = Fan control; M1 = Motor-driven compressor; M2 = Fan;...
