TECHNICAL FEATURES
Power Supply
Input Power (27°C - 65% U.R.)
Max Input Power (32°C - 80% U.R.)
Heating Element Input power
Dehumidification Capacity 27°C - 65% U.R. (liters)
Dehumidification Capacity 32°C - 80% U.R. (liters)
Fan Speeds
Refrigerant type
Refrigerant quantity
Air Flow
Tank Capacity (liters)
Dimensions (HxWxD) mm
Weight
Noise level (sound power)
Water Proof Level
OPERATING WORKING LIMITS
Max working conditions in dehumidification mode: DB / WB
Min working conditions in dehumidification mode: DB / WB
Secco Tech
230V - 50Hz
190 W – 1,2 A
232 W – 1,3A
--
6,6 /24 h
13 /24 h
1
R 134A
0,160 kg
3
120 m
/h
2
300X427X258
13 kg
36 dB(A)
IPX0
35°C/31°C
2° C/1° C
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Olimpia splendid secco tech
Summary of Contents for Olimpia splendid secco tech
- Page 1 TECHNICAL FEATURES Secco Tech Power Supply 230V - 50Hz 190 W – 1,2 A Input Power (27°C - 65% U.R.) 232 W – 1,3A Max Input Power (32°C - 80% U.R.) Heating Element Input power 6,6 /24 h Dehumidification Capacity 27°C - 65% U.R. (liters) 13 /24 h Dehumidification Capacity 32°C - 80% U.R.
-
Page 2: Selecting Functions
INTRODUCTION The dehumidifier is fitted with an electronic logic system which controls operation and optimises consumption and performance. The keys and information on the control panel have the following meanings 1) Start / Stand-by key 2) Operating mode selection key 3) Desired humidity / increment key (selection range from 30 to 90%). -
Page 3: Function Details
FUNCTION DETAILS • DEHUMIDIFICATION indicated by the "drop" symbol light on the display. Compressor and fan are switched on if the minimum OFF time (Cf) has elapsed and if the relative humidity value is higher than the set point + 3; compressor and fan remain ON as long as the relative humidity value is above the set point –... -
Page 4: Alarm Codes
ALARM CODES Display Likely Cause Suggested Solution Indication "Hr" flashing Relative humidity drops below very low values (<22%). Activate the dehumidifier with higher ambient humidity conditions. Humidity sensor broken. Change humidity sensor or whole PCB (according to the model). "tE" flashing The ambient evaporator temperature sensor Change ambient temperature is damaged. - Page 5 SECCO TECH WIRING DIAGRAM A1 - Power board A2 - Control board A3 - Humidity/temperature sensor board B1 - Evaporator temperature probe F1 - Overload protector M1 - Compressor M2 - Fan motor S1 - Microswitch...
