Page 1
Angle Grinder MODEL MT954 MODEL MT958 MODEL MT959 006847 DOUBLE INSULATION I N S T R U C T I O N M A N U A L WARNING: For your personal safety, READ and UNDERSTAND before using. SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE.
SPECIFICATIONS Model MT954 MT958 MT959 Wheel diameter 100 mm 100 mm 100 mm Spindle thread M10 x 1.5 M10 x 1.5 M10 x 1.5 12,000 11,000 12,000 No load speed (min Overall length 256 mm 266 mm 265 mm Net weight 1.5 kg...
15. Disconnect tools. its intended function. Check for alignment of moving When not in use, before servicing and when chang- parts, free running of moving parts, breakage of ing accessories such as blades, bits and cutters. parts, mounting and any other conditions that may 16.
Page 4
23. Do not use the tool on any materials containing metallic objects ) and avoid damaging internal asbestos. parts. 24. Do not use water or grinding lubricant. 26. When use cut-off wheel, always work with the dust collecting wheel guard required by domes- 25.
1. Switch lever ASSEMBLY CAUTION: • Always be sure that the tool is switched off and unplugged before carrying out any work on the tool. Installing side grip (Optional accessory for MT954,MT959) 005979 MT954 MT959 CAUTION: • Always be sure that the side grip is installed securely before operation.
Page 6
Installing the wheel guard 001647 Mount the wheel guard with the tab on the wheel guard band aligned with the notch on the bearing box. Then rotate the wheel guard 180° clockwise. Be sure to tighten the screw securely. 1. Wheel guard 2.
OPERATION 001651 WARNING: • It should never be necessary to force the tool. The weight of the tool applies adequate pressure. Forcing and excessive pressure could cause dangerous wheel breakage. • Continued use of a worn-out wheel may result in wheel explosion and serious personal injury.
