Video or audio Elvox 2-wire entrance panels with traditional push-buttons
Installation and operation manual
1
2
3
1
2
3
OK
1
2
3
1
START
PREC.
SI / YES
PREV
2
STOP
SUCC.
NEXT
3
FINE
OK
END

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 12F3 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Elvox 12F3

Summary of Contents for Elvox 12F3

  • Page 1 Installation and operation manual PREC. START PREC. PREV SI / YES PREV SUCC. STOP SUCC. NEXT NEXT FINE Video or audio Elvox 2-wire entrance panels with traditional push-buttons...
  • Page 2 SAFETY INSTRUCTIONS FOR INSTALLERS DESCRIPTION Types 12F3 and 12F5 comprise respectively an electronic base unit for the - Carefully read the instructions on this leaflet: they give important in- assembling of two models of entrance panels. formation on the safety, use and maintenance of the installation.
  • Page 3 STANDARD MODULES HEIGHT OF 2-MODULE HEIGHT OF 3-MODULE The standard modules consist of: an electronic unit and a connection ter- ENTRANCE PANELS ENTRANCE PANELS minal block. The electronic unit is equipped with a speech unit, camera (on video versions), wiring for terminal block connections, wiring for connec- tion of additional modules and 8 call push-buttons, 6 of which are used for standard programming.
  • Page 4 - Two-module entrance panels with push-buttons in double row 1200 SERIES AUDIO/VIDEO ENTRANCE PANELS (TWO/THREE MODULES) - Two-module entrance panels Art. 1224/D Art. 1222/D Art. 1226/D Art. 1228/D - Three-module entrance panels with push-buttons in double row Art. 1221 Art. 1222 Art.
  • Page 5 ADDITIONAL ENTRANCE PANELS The additional entrance panels with traditional type push-buttons are con- nected to the electronic base units type 12F3 and 12F5 to extend the num- ber of push-buttons. Modules type 12TS (for entrance panels with push-buttons in single row) or type 12TD (for push-buttons in double row), which are inserted in the frames under the plates, are connected one after the other by means of the wiring supplied with the modules.
  • Page 6 RAINPROOF COVERS 1P21 1P22 1P23 1P24 for 1 panel for 2 panels for 3 panels for 4 panels 2 modules high alta 2 moduli 2 modules high 2 modules high 39,5 124 front side 224 front side 324 front side 424 front side 120 rear side 220 rear side...
  • Page 7 FLUSH-MOUNTED ENTRANCE PANEL INSTALLATION WITH RAIN- Fig. 6 PROOF COVERS. Assembly of flush-mounted entrance panel requires the use of the flush- mounted back boxes type 9092 (9192), 9093 (9193) respectively for 2 or 3 electronic modules mounted vertically (Fig. 4 and 5). If the entrance panel uses more than one flush-mounted back box, the rainproof covers must also be used (see push-button plates: accessories on page 4, series 1Pxx), according to the number of modules fitted verti-...
  • Page 8 Type 12TS in panels with push-buttons in single row (from 5 or more calls). Type 12TD in panels with push-buttons in double row (from 9 or Fig. 9 part. 1 more calls). Type 12F3, Type 12F5 Type 12TS o 12TD Fig. 11 START PREC.
  • Page 9 Contrast (only video door entry units) SV (removed) always keep without jumper. o Door call ringtone type models Vimar®) SA (inserted) for audio entrance panels series 12F3 o Intercommunicating ringtone type (only for some models SA (removed) for video entrance panels 89F5/... or audio Vimar®) entrance panels 89F3/...
  • Page 10 ID ENTRANCE PANEL, IDENTIFICATION PANEL CODE PUSHBUTTON HARDWARE PROGRAMMING The identification panel code is required when there is more than one (Perform modifications with system switched off) entrance panel on the installation and only for the panels previously identified as SLAVE. The operation must be carried out after connecting The hardware programming of push-buttons enables the assignment of a all the entrance panels, carrying out the previous operations and powe- unique hardware identification code to each pushbutton of the panel.
  • Page 11 Do not use 105 ... 108 109 ... 112 1 ... 4 5 ... 8 113 ... 116 117 ... 120 9 ... 12 13 ... 16 121 ... 124 125 ... 128 17 ... 20 21 ... 24 129 ... 132 133 ...
  • Page 12 TABLE 2 - PUSH-BUTTONS IN DOUBLE ROW Fig. 15 Do not use 0 ... 8 9 ... 16 17 ... 24 25 ... 32 33 ... 40 41 ... 48 Art. 1224 Art. 1258 49 ... 56 57 ... 64 65 ...
  • Page 13 STANDARD PARAMETER PROGRAMMING Fig. 15C Perform the following procedure with the panels powered and after asso- ciating the panel ID code. This procedure applies to all panels, Master or LED switched off Slave. During programming, the panel is in the engaged status and cannot be used for normal operation in the system.
  • Page 14 - RESET EEPROM Restores all default parameter settings. On entry to the parameter editing mode, the two red LEDs (DL1 and DL2) DL3 DL4 will start to flash 8 times and the panel emits a continuous high tone. TIME During flashing, press the push-buttons PREVIOUS, OK, STOP in se- quence to start deletion of the EEPROM.
  • Page 15 - F1 TIME - PUSHBUTTON REMAPPING To be programmed at user's discretion. This is the activation time of Enables modification to the code sent by a pushbutton, regardless of the device connected between terminals +12V / F1. Default value = 1 its physical position assigned with the hardware programming.
  • Page 16 INSTALLATIONS WITH ACTIVE DISTRIBUTOR 692D/2. The termination jumper must be positioned on “B” (for Elvox cable) or on “C” (for CAT5 twisted pair cable) IF AND ONLY IF the BUS terminates at the de- vice itself. It must be left on “A” if effecting entry-exit using terminals 1-2 on 692D/2.
  • Page 17 SINGLE AND MULTIPLE RESIDENCE AUDIO DOOR ENTRY SYSTEM WITH INTERPHONES SERIES PETRARCA, 8870, 6600 AND ONE AUDIO ENTRANCE PANEL (REF. SI435). Interphone cable riser Mains F- Art. 6922 EXT+ EXT+ A0 - Interphone type 6901, type 6901/D EXT- EXT- A1 - Interphone series Petrarca type 6209 VLED VLED A2 - Interphone series 6600...
  • Page 18 SINGLE AND MULTIPLE RESIDENCE AUDIO DOOR ENTRY SYSTEM WITH INTERPHONES SERIES PETRARCA, 8870, 6600 AND THREE AUDIO ENTRANCE PANELS (REF. SI338). Interphone cable riser A0 - Interphone type 6901, type 6901/D A1 - Interphone series Petrarca type 6209 A2 - Interphone series 6600 type 6601/AU, 660C/AU, 6701/AU type 6611/AU, 661C/AU, 6711/AU, type 6xxx/AUF A3 - Interphone series 8870 type 8879...
  • Page 19 AUDIO DOOR ENTRY SYSTEM FOR BUILDING COMPLEX WITH ONE MAIN ENTRANCE PANEL AND ONE STAIRWAY PANEL PER APARTMENT BLOCK (REF. si340+si334). SI334 SI334 ID=2 ID=1 Mains Mains I- Art. 692S I- Art. 692S F- Art. 6922 F- Art. 6922 BUS D BUS P BUS D BUS P...
  • Page 20 AUDIO DOOR ENTRY SYSTEM FOR BUILDING COMPLEX WITH THREE MAIN ENTRANCE PANELS AND TWO STAIR- WAY PANELS PER APARTMENT BLOCK (REF. si341+si334). SI334 SI334 Mains Mains I- Art. 692S I- Art. 692S F- Art. 6922 F- Art. 6922 BUS D BUS P BUS D BUS P...
  • Page 21 CONNECTION OF MONITORS WITH AND WITHOUT FLOOR DISTRIBUTOR TYPE 692D AND 692D/2 (REF. si638). G- Art. 6923 Monitor cable riser Monitor cable riser Mains G- Art. 6923 Mains 1C 2C N2- Art. 692D/2 G- Art. 6923 Monitor cable riser Video door entry system cable riser wiring. The video door entry units (interphones) can be connec- ted to the cable riser in the following ways: Mains...
  • Page 22 SINGLE AND MULTIPLE RESIDENCE VIDEO DOOR ENTRY SYSTEM WITH PETRARCA, GIOTTO AND 6600 SERIES VIDEO INTER- PHONES AND ONE VIDEO ENTRANCE PANEL (REF. si433). Monitor cable riser Mains G- Art. 6923 B0 - Monitor series Wide touch type 7311 B1 - Monitor series 7200 type 7211 B2 - Monitor series 6600 type 6621, 662C, 6721 type 6611, 661C, 6711,...
  • Page 23 WIRING DIAGRAM FOR “TWO WIRE ELVOX” VIDEO INTERPHONE INSTALLATIONS WITH TWO OR MORE MO- NITOR RISERS WITH DISTRIBUTORS TYPE 692D/2 (SI424). Monitor cable riser G- Art. 6923 Mains Mains 1C 2C F- Art. 6922 Art. 692D/2 B0 - Monitor series Wide touch type 7311...
  • Page 24 VIDEO ENTRANCE PANEL SYSTEM FOR SINGLE AND TWIN RESIDENCE WITH MONITORS SERIES PETRARCA, GIOTTO, 6600, ONE ENTRANCE PANEL WITH EXTERNAL CAMERA IN B/W (Ref. SI367). Monitor cable riser G- Art. 6923 Mains B0 - Monitor series Wide touch type 7311 B1 - Monitor series 7200 type 7211 B2 - Monitor series 6600 type 6621, 662C, 6721...
  • Page 25 SINGLE AND MULTIPLE RESIDENCE VIDEO DOOR ENTRY SYSTEM WITH INTERCOMMUNICATING MONITORS (REF. si611). Monitor cable riser Monitor cable riser 1C 2C 1C 2C Art. 692D/2 Art. 692D/2 Mains Mains I- Art. 692S F- Art. 6922 I- Art. 692S F- Art. 6922 BUS D BUS P BUS D...
  • Page 26 VIDEO DOOR ENTRY SYSTEM FOR BUILDING COMPLEX (REF. SI380). Monitor cable riser Monitor cable riser Mains ID=2 Mains ID=1 I- Art. 692S I- Art. 692S F- Art. 6922 F- Art. 6922 BUS D BUS P BUS D BUS P EXT+ EXT+ EXT- EXT-...
  • Page 27 VIDEO DOOR ENTRY SYSTEM FOR BUILDING COMPLEX WITH THREE MAIN ENTRANCE PANELS AND TWO STAIR- WAY PANELS PER APARTMENT BLOCK (AUDIO AND VIDEO) (REF. SI382). Audio entry panel with push-buttons C0 - Audio entry panel with alphanumeric display Video entry panel with push-buttons D0 - Video entry panel with alphanumeric display Power supply type 6922 Separator type 692S...
  • Page 28 Electronic unit with alphanumeric keyboard, backlit sign with house Electronic unit with alphanumeric keyboard (up to 8 modules type number (panel Art. 12N4, 12N3, 12N2, 12N1) 805N, 80PN). Monitor cable riser Monitor cable riser ELVOX ELVOX ELVOX ELVOX EXT+ EXT+...
  • Page 29 EXT+ EXT- VLED Art. 6582 Art. 6582 Art. 6582 EXT+ EXT- VLED +12V type 6582 +12V ELVOX ELVOX ELVOX ELVOX Add power sup- power power ply for the first supply for the supply for the 60 modulesi next 60 modu-...
  • Page 30 VARIANT Wiring diagram for additional mechanical doorbells. Additional doorbells operating at 12V can be connected by using relay type 0170/101 connected as shown in the diagram. Mains A0 - Interphone type 6901, type 6901/D G- Art. 6923 A1 - Interphone series Petrarca type 6209 A2 - Interphone series 6600 type 6601/AU, 660C/AU, 6701/AU type 6611/AU, 661C/AU, 6711/AU, type 6xxx/AUF...
  • Page 31 VARIANT Wiring diagram of additional electronic ringtone type 860A. The electronic ringtone type 860A features a two or three-note ringtone connected between terminal 7 and terminal 8. The ringtone must be powered at mains voltage. The doorbell rhithm follows the call push- button pressure. Ringtone Ringtone Ringtone...
  • Page 32 VARIANT Wiring diagram for additional mechanical doorbells. Additional doorbells operating at 12V can be connected by using relay type 0170/101 connected as shown in the diagram. Relay Art. 0170/101 Relay Max Last Art. 0170/101 3A 230V Max Last 3A 230V Additional ringtone Additional ringtone Ringtone power supply...
  • Page 33 Relay Art. 0170/101 Mains G- Art. 6923 Additional ringtone Ringtone power supply VARIANT Wiring diagram with simultaneous switch-on of two or more moni- tors with power supply type 6923. The power supply unit Type 6922 can simultaneously power one video entrance panel and two monitors Type 6029, 6029/C, 6611, 6621, 661C, 662C, 6711, 6721 switched on.
  • Page 34 ADDITIONAL SUPPLY VOLTAGES The hereby wiring diagrams are reference examples for the ta- In “Elvox TWO WIRE ” installations, power supply type 6922 po- bles to follow (Tab. A, Tab. B and Tab. C) for the insertion of the wers all the appliances: entrance panels, interphones, monitors, additional power supply type 6923.
  • Page 35 Table for audio entrance panel systems with 1 or more entrance panels connected in parallel and one audio riser. Table A. Number of audio entrance panels con- Number of interphones inserted with the nected in parallel. Number of power supplies Type 6923 same call 1 active and the others engaged From 1 to 10...
  • Page 36 Via Pontarola, 14/a 35011 Campodarsego PD Tel. +39 049 920 2511 Fax +39 049 920 2603 S6I.12F.50E RL. 10 13 02 www.elvox.com ELVOX - Campodarsego - Italy...
