Summary of Contents for Wohler RM-3358W-2C
- Page 1 CONFIDENCE IS EVERYTHING.™ World Leader of In-Rack, Audio, Video, Data Monitoring, and Closed Captioning Solutions RM-3358W-2C 3RU, 3-Widescreen, 5.8” Display Analog Video Monitor with Optional SDI Inputs User Guide Part Number 821681, Revision B the video division of...
-
Page 2: Customer Support
Wohler Technologies, Inc. reserves the right to change or improve our products at any time and without notice. In no event will Wohler Technologies, Inc. be liable for direct, indirect, special, incidental, or consequential damages resulting from any defect in the hardware, software, or its documentation, even if advised of the possibility of such damages. -
Page 3: Table Of Contents
User Guide Introduction Overview The RM-3358W-2C is a color video monitor with a 3RU front panel containing three 5.8” widescreen active matrix TFT LCD displays with either 16:9 or 4:3 aspect ratio. Each LCD is back-lit with a cold cathode fluorescent tube. -
Page 4: Safety Instructions
R M - 3 3 5 8 W - 2 C U s e r G u i d e S a f e t y I n s tr u c ti o n s Safety Instructions Read, keep, and follow all of these instructions; heed all warnings. Do not use this equipment near water. -
Page 5: Installation Recommendations
RM-3358W-2C User Guide I n s ta l la t i o n R e c o m me n d a t io n s Installation Recommendations Unpacking Unpack the unit from the shipping container and inspect all articles for shipping damage. -
Page 6: Features
A/C mains power source (65W, 100 to 240 VAC, 50/ 60Hz) to the IEC connector provided on the rear panel of the unit. Cable Recommendations Wohler recommends you use Belden 1694A (or equivalent) cables for composite (analog) or SDI video signals. Features The standard RM-3358W-2C unit features two composite analog (CVBS) video inputs per LCD display for a total of six inputs. -
Page 7: Specifications
RM-3358W-2C User Guide S p e ci f i c a t i o n s Specifications Table 1–1 Specifications Specification Value Six composite (CVBS) video inputs (two per screen) with A/B select. Each screen Video Input has optional input module as the "B"... - Page 8 R M - 3 3 5 8 W - 2 C U s e r G u i d e F r o n t P a n e l C o n t r o l s Figure 1–1 Front Panel Controls Tally Lights Aspect...
-
Page 9: Rear Panel Connectors
RM-3358W-2C User Guide R e a r P a n e l C o n n e c t o r s • Brightness: This potentiometer adjusts the brightness of the display. • LCD Video Display: View the selected video input source (A or B) on the LCD display. - Page 10 R M - 3 3 5 8 W - 2 C U s e r G u i d e R e a r P a n e l C o n n e ct o r s • CVBS Inputs (on BNCs): Composite (CVBS) video signals are accepted at these BNC connectors.
-
Page 11: Optional Sdi Input Modules
RM-3358W-2C User Guide O p t io n a l S D I I n p u t M o d u le s Optional SDI Input Modules The RMSDI-1 and the RMSDI-2 optional SDI input modules are identical except the RMSDI-1 does not have an SDI output and uses a manual switch for the NTSC/PAL selection. -
Page 12: Technical Functional Overview
Figure 1–6 on page 11 illustrates the functionality of the RM-3358W-2C. © 2 00 9 Wo h le r Te ch n ol og ie s , I n c . A l l r i g h t s r e s e rve d . - Page 13 Figure 1–6 Block Diagram of the RM-3358W-2C © 2 00 9 Wo h le r Te ch n o l og ie s, I n c . A l l r i g h t s r e s e r v e d .
