MEC 02.1 marine version Operation instructions Scope of these instructions: These instructions are valid for globe valve actuators of the type range SV 05.1 – SV 07.1 with controls MEC 02.1 in marine version. Table of contents Page Safety instructions 1.1.
Short description AUMA globe valve actuators type SV 05.1 – SV 07.1. have a modular design. Motor and gearing are mounted in a common housing and make up a coaxial unit together with the output drive.
Globe valve actuators SV 05.1 – SV 07.1 with actuator controls MEC 02.1 marine version Operation instructions Transport and storage Transport to place of installation in sturdy packing. Do not attach ropes or hooks to the handwheel/crank for the purpose of lifting by hoist.
Globe valve actuators SV 05.1 – SV 07.1 Operation instructions with actuator controls MEC 02.1 marine version Mounting to valve Mounting is most easily done with the valve shaft pointing vertically upward. But mounting is also possible in any other position. The globe valve actuator leaves the factory in position CLOSED.
Globe valve actuators SV 05.1 – SV 07.1 with actuator controls MEC 02.1 marine version Operation instructions Manual operation For purposes of setting and commissioning, in case of motor or power failure, the actuator may be operated manually. Different versions are avail- able as operation elements, refer to figures 2 to 5.
AUMA globe valve actuators SV 05.1 – SV 07.1 are operated via the controls MEC 02.1. These are designed to be mounted separately on a wall. Suitable, flexible, and screened cables must be used between controls and actuator.
Page 10
In case the terminal plan is not available, it can be obtained from AUMA (state commission no., refer to name plate) or downloaded directly from the Internet (www.auma.com). Protective earth connection interface is provided and marked according to...
Globe valve actuators SV 05.1 – SV 07.1 Operation instructions with actuator controls MEC 02.1 marine version Switch compartment The following sub-assemblies are located within the switch compartment: End position detection (refer to page 12) Electronic position transmitter (option) (refer to page 15)
Globe valve actuators SV 05.1 – SV 07.1 with actuator controls MEC 02.1 marine version Operation instructions 10. End position detection: check and set 10.1. Clockwise closing: The following description is only valid for “clockwise closing”, i.e. driven shaft turns counterclockwise to close the valve.
Globe valve actuators SV 05.1 – SV 07.1 Operation instructions with actuator controls MEC 02.1 marine version End position OPEN Move valve to end position OPEN. The end position detection is correctly set if the green LED is illuminated and the output contacts (refer to terminal plan) indicate “end position OPEN”.
Globe valve actuators SV 05.1 – SV 07.1 with actuator controls MEC 02.1 marine version Operation instructions 11. Test run 11.1. Direction of rotation: check The direction of rotation of the indicator disc (figure 13) indicates the direc- tion of rotation of the output drive.
Globe valve actuators SV 05.1 – SV 07.1 Operation instructions with actuator controls MEC 02.1 marine version 12. Electronic position transmitter RWG (option): set The electronic position transmitter records the valve position and generates a current signal between 4 and 20 mA, using the position feedback measured by the potentiometer.
Globe valve actuators SV 05.1 – SV 07.1 with actuator controls MEC 02.1 marine version Operation instructions 13. Mechanical position indicator: set The mechanical position indication is realised using the white pointer below the indicator glass of the cover. The pointer setting shows the position CLOSED or OPEN with respect to the pipeline.
Globe valve actuators SV 05.1 – SV 07.1 Operation instructions with actuator controls MEC 02.1 marine version 14. Actuator controls MEC 02.1 Figure 19: MEC 02.1 with Figure 20: MEC 02.1 standard local controls 14.1. Type of seating: set The MEC 02.1 is set in the factory in compliance with the order details. Later modifications are possible as described below.
Globe valve actuators SV 05.1 – SV 07.1 with actuator controls MEC 02.1 marine version Operation instructions 15. Fuses Disconnect controls from the mains. For this, at least dis- connect plug XG1 from the controls. When exchanging the fuses, only fuses with the same val- ues must be used.
Defective actuators can therefore only be repaired in the factory or in an authorised workshop. 18. Disposal and recycling AUMA actuators have an extremely long lifetime. However, they have to be replaced at one point in time. The actuators have a modular design and may therefore easily be disas- sembled, separated, and sorted according to materials, i.e.:...
Globe valve actuators SV 05.1 – SV 07.1 with actuator controls MEC 02.1 marine version Operation instructions 20. Spare parts list 20.1. Globe valve actuator SV 05.1 – SV 07.1...
Page 21
MEC 02.1 marine version Note: Please state type and commission no. of the device (see name plate) when ordering spare parts. Only original AUMA spare parts should be used. Failure to use original spare parts voids the warranty and exempts AUMA from any liability.
SV 05.1 – SV 07.1 with actuator controls MEC 02.1 marine version Operation instructions 21. Declaration of incorporation and EC declaration of conformity...
Page 23
SV 05.1 – SV 07.1 Operation instructions with actuator controls MEC 02.1 marine version Notes...
Page 24
SV 05.1 – SV 07.1 with actuator controls MEC 02.1 marine version Operation instructions Notes...
SV 05.1 – SV 07.1 Operation instructions with actuator controls MEC 02.1 marine version Index Controls MEC Maintenance Corrosion protection Manual operation Coupling Mechanical position indicator Mounting to valve/gearbox Declaration of conformity Declaration of incorporation Packaging Disposal and recycling...
