Led Diagnostics & Troubleshooting - Xpresskit DBALL Installation Manual

Platform: DBALL/DBALL2
Firmware: TL1 Remote Start Ready (RSR) Installation
LED Diagnostics & Troubleshooting
LED Status
Programming the Module
Off
Off
Solid Red
Solid
Flashes Flashes Orange
Solid Green x3
Solid
x3 secs
seconds
Solid Orange x3
Solid
seconds
x3 secs
Active Ground While Running
Flashes Flashes Green
Flashes Red &
Flashes
Orange
Flashes Green
Flashes
quickly
Quickly
D2D & W2W Commands
Flashes Orange
Flashes
x1
x1
Flashes Orange
Flashes
x2
x2
Flashes Orange
Flashes
x3
x3
Flashes Orange
Flashes
x4
x4
Description
Module has no power.
Waiting to begin the
programming sequence.
OEM remote starter detected.
Module has been successfully
programmed.
Module was successfully
programmed without bypass
(convenience only).
GROUND OUT ON (GWR)
command received.
IGNITION ON command
received.
START ON command received.
Lock command received.
Unlock command received.
Trunk command received.
AUX1 command received.
Troubleshooting
Make sure the D2D harness is connected or that the 12 Volt is
present between the red and black wires. If the 12 Volt is present,
the module may be defective.
Refer to the wiring diagram to make sure that all the connections
are correct.
If the user wants to use the module as a convenience only, he
should skip bypass by pressing the programming button 5 times.
However, if the user wants to use the module as a remote starter,
he should disconnect the OEM remote starter and repeat the
programming sequence.
Normal operation.
Normal operation. An OEM remote starter was detected
(convenience mode only). If the user wants to use the module as
a remote starter, he should disconnect the OEM remote starter
and repeat the programming sequence, by doing a short reset.
Otherwise, the Ground While Running (status) signal was lost or
was never received by the module. Commands can come from
RF, D2D or W2W.
Otherwise, the ignition signal was not received by the module. In
a W2W install, it will show only if the ignition input wire is used.
Otherwise, the start signal was not received by the module.
Refer to the wiring diagram to make the right connections.
If the bypass module fails to flash, it means the module did not
receive the signal. Commands can come from RF, D2D or W2W.
Rev.: 20150709
Page 15
