LEDs

LED Locations

The locations of the System and DSL Port LEDs on the front panel of the
BitStorm 2600 are shown in
Figure 3-1.
2600-A2-GN20-10
Figure 3-1, Front Panel
Link LEDs
Activity LEDS
Front Panel LEDs
January 2004
3
LEDs.
DSL Ports LEDs
260 0
03-17454
3-1
