2. Cabling

Ground

Procedure
To connect the unit to a ground:
2-10
1. Crimp a ring terminal onto the stripped end of 14 AWG or heavier copper
ground wire.
2. Remove the screw marked by the ground symbol (
front panel.
3. Fasten the ring terminal to the front panel using the same screw.
4. Attach the ground wire to an earth ground.
2 6 0 0
To Earth Ground
