Connectors and Pin Assignments

Overview

The following sections provide pin assignments for:
„
„
„
„
„
„
Figure A-1.
2600-A2-GN20-10

DSL Ports and POTS Splitter Connectors

Port 1 and Port 2 10/100BaseT Connectors

Port 3 1000BaseT Connector

Port 3 GigE SFP Connector

Console Port Connector

ALARM Connector

on page A-6
BitStorm 2600 IP Front Panel
January 2004
on page A-2
on page A-3
on page A-3
on page A-4
on page A-5
DSL PORTS 1-24
A
POTS 1-24
2600
03-17455
A-1
