Console Port Connector

The CONSOLE port connector is a DB9 socket connector that supports an
EIA-232-E circuit as shown in
Table A-5. Console Port Connector
2600-A2-GN20-10
RS-232 Signal Direction
Data Carrier Detect Out
Receive Data Out
Send Data In
Data Terminal Ready In
Ground —
Data Set Ready Out
Request to Send In
Clear to Send In
Ring Indicator —
January 2004
A. Connectors and Pin Assignments
Table A-5.
Pin
1
2
3
4
5
6
7
8
9
A-5
