Paradyne BitStorm 2600 IP DSLAM Installation Manual page 54

C. Technical Specifications
Table C-1. BitStorm 2600 Technical Specifications (2 of 2)
C-2
Specifications Criteria
Operating Ambient Temperature: 0° to 50° C (32° to 122° F)
Environment Relative Humidity: 5% to 95% noncondensing
Storage Temperature: –40° to 85° C (–40° to 185° F)
Shock and vibration tolerance sufficient to withstand normal shipping
Physical Height: 1.75" (44.5 mm, or 1U as defined in EIA-310-C) without feet
Dimensions Width: 17.2" (437 mm) without mounting brackets
Depth: 16.0" (406 mm) with cables
Power 90–265 VAC, 47–63 Hz
Power Model 2611: 45 Watts Maximum
Consumption
Model 2621: 43 Watts Maximum
Weight 2611-A1-420: 15.1 lbs (6.8 kg)
2611-A1-430: 17.0 lbs (7.7 kg)
2611-A1-434: 16.2 lbs (7.3 kg)
2611-A1-435: 16.2 lbs (7.3 kg)
2611-A1-436: 16.2 lbs (7.3 kg)
2621-A1-420: 14.7 lbs (6.7 kg)
2621-A1-430: 16.3 lbs (7.4 kg)
2621-A1-434: 15.8 lbs (7.2 kg)
2621-A1-435: 15.8 lbs (7.2 kg)
2621-A1-436: 15.8 lbs (7.2 kg)
January 2004 2600-A2-GN20-10
