Related Manuals for ORiNG IGS-3032GC

Summary of Contents for ORiNG IGS-3032GC

  • Page 2: Copyright Notice

    ORing warrants that all ORing products are free from defects in material and workmanship for a specified warranty period from the invoice date (5 years for most products). ORing will repair or replace products found by ORing to be defective within this warranty period, with shipment expenses apportioned by ORing and the distributor.

  • Page 3: Table Of Contents

    IGS-3032GC User Manual Table of Content Getting Started ....................5 About the IGS-3032GC Series ..................5 Software Features ......................5 Hardware Features ......................5 Hardware Overview ..................7 Front Panel ........................7 Front Panel LEDs ......................8 Bottom Panel ........................8 Rear Panel ........................
  • Page 4 IGS-3032GC User Manual 4.4.2 Configurations .................... 24 STP/RSTP/MSTP ......................25 4.5.1 STP/RSTP ....................25 4.5.2 MSTP ......................28 Fast Recovery ......................32 Management ....................34 Basic Settings....................35 5.1.1 System Information ..................35 5.1.2 System Setting ................... 36 5.1.3 Admin & Password ..................37 5.1.4...
  • Page 5 IGS-3032GC User Manual 5.5.2 Client List ....................58 5.5.3 Port and IP Bindings ................... 58 5.5.4 Relay Agent ....................58 SNMP......................60 5.6.1 Agent Setting....................60 5.6.2 Trap Setting ....................61 5.6.3 SNMPV3 ....................62 Security ......................64 5.7.1 IP Security ....................64 5.7.2...

  • Page 6: Getting Started

    The IGS-3032GC is a powerful managed industrial switch designed for extreme temperatures, dusty environments, and high humidity. With three 10/100/1000Base-T(X) and two Gigabit combo ports, the IGS-3032GC can be managed via web browsers, TELNET, Console or other third-party SNMP software as well as ORing’s proprietary management utility Open-Vision.
  • Page 7 IGS-3032GC User Manual Operating humidity: 5% to 95%, non-condensing Casing: IP-30 Dimensions (W x D x H): 54.1(W)x106.1(D)x145.4(H) mm (2.13x4.18x5.72 inch.) ORing Industrial Networking Corp...

  • Page 8: Hardware Overview

    IGS-3032GC User Manual ardware Overview 2.1 Front Panel The device comes with the following ports on the front panel: Port Description 10/100/1000Base-TX) 4 x 10/100Base-T(X) RJ-45 fast Ethernet ports supporting RJ-45 Fast Ethernet ports auto-negotiation. Gigabit RJ-45 ports 2 x 10/100/1000Base-T Gigabit ports (as combo ports)

  • Page 9: Front Panel Leds

    IGS-3032GC User Manual 2.2 Front Panel LEDs Color Status Description PWR1 Green DC power module 1 activated. PWR2 Green DC power module 2 activated. PWR3 Green DC power module 3 activated. Green System running in Ring Master mode System running in Ring mode...

  • Page 10: Rear Panel

    IGS-3032GC User Manual 1. Console port 2. Reset button 3. Terminal block 4. Power 3 connector 2.4 Rear Panel On the rear panel of the switch sit three sets of screw holes. The two sets placed in triangular patterns on both ends of the rear panel are used for wall-mounting (red boxes in the figure below) and the set of three holes in the middle are used for Din-rail installation (blue box in the figure below).

  • Page 11: Hardware Installation

    IGS-3032GC User Manual ardware Installation 3.1 DIN-rail Installation The switch comes with a DIN-rail kit which can be installed on the rear panel. With the DIN-rail kit, the switch can be fixed on a DIN-rail. Installing the switch on the DIN-rail is easy. First, screw the Din-rail kit onto the back of the switch, right in the middle of the back panel.

  • Page 12: Wall Mounting

    IGS-3032GC User Manual 3.2 Wall Mounting Besides Din-Rail, the switch can be fixed to the wall via a wall mount panel, which can be found in the package. Wall-Mount Kit Measurement (Unit = mm) To mount the switch onto the wall, follow the steps: 1.

  • Page 13: Wiring

    IGS-3032GC User Manual 3. Insert screws through the round screw holes (the red arrow as below) on the sides or through the cross-shaped aperture (the green arrow as below) in the middle of the plate and fasten the screw to the wall with a screwdriver.

  • Page 14: Grounding

    IGS-3032GC User Manual should be routed separately. 6. You can use the type of signal transmitted through a wire to determine which wires should be kept separate. The rule of thumb is that wiring sharing similar electrical characteristics can be bundled together 7.
  • Page 15 IGS-3032GC User Manual With 10/100/1000BASE-T(X) cables, pins 1 and 2 are used for transmitting data, and pins 3 and 6 are used for receiving data. 10/100Base-T RJ-45 Pin Assignments: Pin Number Assignment Not used Not used Not used Not used...
  • Page 16 IGS-3032GC User Manual Not used Not used RD-(receive) TD-(transmit) Not used Not used Not used Not used 1000 Base-T MDI/MDI-X Pin Assignments: Pin Number MDI port MDI-X port BI_DA+ BI_DB+ BI_DA- BI_DB- BI_DB+ BI_DA+ BI_DC+ BI_DD+ BI_DC- BI_DD- BI_DB- BI_DA-...

  • Page 17: Sfp

    IGS-3032GC User Manual 3.4.2 The switch comes with fiber optical ports that can connect to other devices using SFP modules. The fiber optical ports are in multi-mode (0 to 550M, 850 nm with 50/125 µm, 62.5/125 µm fiber) and single-mode with LC connectors. Please remember that the TX port of Switch A should be connected to the RX port of Switch B.
  • Page 18 IGS-3032GC User Manual them into a couping ring. All you need to do is select two switches from each ring to be connected, for example, switch A and B from Ring 1 and switch C and D from ring 2. Decide which port on each switch to be used as the coupling port and then link them together, for example, port 1 of switch A to port 2 of switch C and port 1 of switch B to port 2 of switch D.
  • Page 19 IGS-3032GC User Manual O-Chain When connecting multiple O-Rings to meet your expansion demand, you can create an O-Chain topology through the following steps. 1. Select two switches from the chain (Switch A & B) that you want to connect to the O-Ring and connect them to the switches in the ring (Switch C &...
  • Page 20 IGS-3032GC User Manual ORing Industrial Networking Corp...

  • Page 21: Redundancy

    4.1 O-Ring 4.1.1 Introduction O-Ring is ORing's proprietary redundant ring technology, with recovery time of less than 30 milliseconds (in full-duplex Gigabit operation) or 10 milliseconds (in full-duplex Fast Ethernet operation) and up to 250 nodes. The ring protocols identify one switch as the master of the network, and then automatically block packets from traveling through any of the network’s...
  • Page 22 IGS-3032GC User Manual Label Description Check to enable O-Ring topology. Enable Ring Only one ring master is allowed in a ring. However, if more than one switches are set to enable Ring Master, the switch with the Enable Ring Master lowest MAC address will be the active ring master and the others will be backup masters.

  • Page 23: Open-Ring

    4.2 Open-Ring 4.2.1 Introduction Open-Ring is a technology developed by ORing to enhance ORing switches’ interoperability with other vendors’ products. With this technology, you can add any ORing switches to the network based on other ring technologies. 4.2.2 Configurations Label...

  • Page 24: O-Chain

    IGS-3032GC User Manual 4.3 O-Chain 4.3.1 Introduction O-Chain is ORing’s revolutionary network redundancy technology which enhances network redundancy for any backbone networks, providing ease-of-use and maximum fault-recovery swiftness, flexibility, compatibility, and cost-effectiveness in a set of network redundancy topologies. The self-healing Ethernet technology designed for distributed and complex...

  • Page 25: Mrp

    IGS-3032GC User Manual Label Description Enable Check to enable O-Chain function Ring Port The first port connecting to the ring Ring Port The second port connecting to the ring Edge Port An O-Chain topology must begin with edge ports. The ports with a smaller switch MAC address will serve as the backup link and RM LED will light up.

  • Page 26: Stp/Rstp/Mstp

    IGS-3032GC User Manual Force Speed / Duplex By default, this is in auto-negotiation mode. Enabling this for 100BASE-TX function will automatically change the default to Full mode.(this function is used in combination with Hirschmann’s switch as the MRP ring port speed/duplex of Hirschmann’s switches are always in Full mode) 4.5 STP/RSTP/MSTP...
  • Page 27 IGS-3032GC User Manual specify edge port. The user must specify the edge port according to topology of network. RSTP Bridge Setting Label Description RSTP mode You must enable or disable RSTP function before configuring the related parameters. Priority (0-61440) A value used to identify the root bridge. The bridge with the lowest value has the highest priority and is selected as the root.
  • Page 28 IGS-3032GC User Manual The following pages show the information of the root bridge, including its port status. Label Description Path Cost The path cost incurred by the port. The path cost is used when (1-200000000) establishing an active topology for the network. Lower path cost ports are chosen as forwarding ports in favor of higher path cost ports.

  • Page 29: Mstp

    IGS-3032GC User Manual Port Priority (0-240) Decide which port should be blocked by priority in the LAN. The valid value is between 0 and 240, and must be a multiple of 16 Oper P2P Configures the port connects to a point-to-point LAN rather than a shared medium.
  • Page 30 IGS-3032GC User Manual Bridge Settings This page allows you to examine and change the configurations of current MSTI ports. A MSTI port is a virtual port, which is instantiated separately for each active CIST (physical) port for each MSTI instance configured and applicable for the port. The MSTI instance must be selected before MSTI port configuration options are displayed.
  • Page 31 IGS-3032GC User Manual Configuration Name The name which identifies the VLAN to MSTI mapping. Bridges must share the name and revision (see below), as well as the VLAN-to-MSTI mapping configurations in order to share spanning trees for MSTIs (intra-region). The name should not exceed 32 characters.
  • Page 32 IGS-3032GC User Manual Label Description Port No. The number of port you want to configure Priority (0-240) Decide which port should be blocked by priority in the LAN. The valid value is between 0 and 240, and must be a multiple of 16.

  • Page 33: Fast Recovery

    IGS-3032GC User Manual mapped to one MSTI. An unused MSTI will be left empty (ex. without any mapped VLANs). Priority (0-61440) A value used to identify the root bridge. The bridge with the lowest value has the highest priority and is selected as the root. If the value changes, you must reboot the switch.
  • Page 34 IGS-3032GC User Manual providing redundant links. Fast recovery mode supports 5 priorities. Only the first priority will be the active port, and the other ports with different priorities will be backup ports. Label Description Active Activate fast recovery mode Port.01 - 05 Ports can be set to 5 priorities.

  • Page 35: Management

    IGS-3032GC User Manual anagement The switch can be controlled via a built-in web server which supports Internet Explorer (Internet Explorer 5.0 or above versions) and other Web browsers such as Chrome. Therefore, you can manage and configure the switch easily and remotely. You can also upgrade firmware via a Web browser.

  • Page 36: Basic Settings

    IGS-3032GC User Manual Password: admin After logging in, you will see the information of the switch as below. On the left hand side of the management interface shows links to various settings. Clicking on the links will bring you to individual configuration pages. On the right hand side shows the picture of the front device whose indicators correspond to the physical device.

  • Page 37: System Setting

    IGS-3032GC User Manual Label Description An administratively assigned name for the managed node. By convention, this is the node's fully-qualified domain name. A domain name is a text string consisting of alphabets (A-Z, a-z), System Name digits (0-9), and minus sign (-). Space is not allowed to be part of the name.

  • Page 38: Admin & Password

    IGS-3032GC User Manual System Description Displays the description of the switch. Specifies the physical location of the switch. The maximum System Location length is 64 bytes. System Contact Enter the name of a contact person or organization 5.1.3 Admin & Password This page allows you to configure the system password required to access the web pages or log in from CLI.

  • Page 39: Time Setting

    IGS-3032GC User Manual Label Description Enables or disables the DHCP client. If DHCP fails or the DHCP Client configured IP address is zero, DHCP will retry. If DHCP retry fails, DHCP will stop trying and the configured IP settings will be used.
  • Page 40 IGS-3032GC User Manual (YYYY/MM/DD). Year: 2006-2015. Month: Jan-Dec. Day:1-31(28) System Time Specify the hour, minute and second of the system clock (hh:mm:ss). Hour:0-24, Minute:0-59, Second:0-59 SNTP SNTP (Simple Network Time Protocol) is a protocol able to synchronize the time on your system to the clock on the Internet.
  • Page 41 IGS-3032GC User Manual Local Time Zone Conversion from UTC Time at 12:00 UTC November Time Zone - 1 hour 11 am Oscar Time Zone -2 hours 10 am ADT - Atlantic Daylight -3 hours 9 am AST - Atlantic Standard...

  • Page 42: Lldp

    IGS-3032GC User Manual Label Description PTP Client Enables or disables PTP Client 5.1.6 LLDP LLDP (Link Layer Discovery Protocol) provides a method for networked devices to receive and/or transmit their information to other connected devices on the network that are also using the protocols, and to store the information that is learned about other devices.

  • Page 43: Auto Provision

    IGS-3032GC User Manual Label Description Mode Enables or disables Modbus TCP function 5.1.8 Auto Provision Auto Provision allows you to update switch firmware automatically. You can put the firmware or configuration file on a TFTP server. When you reboot the switch, it will upgrade firmware automatically.

  • Page 44: Upgrade Firmware

    IGS-3032GC User Manual The following page allows you to restore the system to previous configurations from a TFTP server. Label Description TFTP Server The IP address of the FTFP where you put the configuration file or Address where you want to restore the switch to previous settings.

  • Page 45: Multicast

    IGS-3032GC User Manual 5.2 Multicast 5.2.1 IGMP Snooping IGMP (Internet Group Management Protocol) snooping monitors the IGMP traffic between hosts and multicast routers. The switch uses what IGMP snooping learns to forward multicast traffic only to interfaces that are connected to interested receivers. This conserves bandwidth by allowing the switch to send multicast traffic to only those interfaces that are connected to hosts that want to receive the traffic, instead of flooding the traffic to all interfaces in the VLAN.

  • Page 46: Mvr

    IGS-3032GC User Manual IGMP Query Configures the switch to be the IGMP querier. Only one IGMP querier Mode is allowed in an IGMP application. Auto will select the switch with the lowest IP address as the querier. Apply Click to apply the configurations.

  • Page 47: Port Setting

    IGS-3032GC User Manual manually. The function enables end devices to receive multicast traffic only if they register to join specific multicast groups. With static multicast filtering, network devices only forward multicast traffic to the ports connected to registered end devices. The function allows you to control the multicast traffic precisely.

  • Page 48: Port Status

    IGS-3032GC User Manual Port Control Label Description Port NO. The number of the port to be configured. State Enables or disables the port. Speed/Duplex Available values include auto-negotiation, 100-full, 100-half, 10-full, or 10-half Flow Control Supports symmetric and asymmetric modes to avoid packet loss...

  • Page 49: Rate Limit

    IGS-3032GC User Manual addresses. You could specify other IP addresses here. 5.2.7 Rate Limit This page allows you to define the rate limits applied to a port, including incoming and outgoing traffic. Label Description Ingress Limit Frame Valid values include All, Broadcast only, Broadcast/Multicast Type and Broadcast/Multicast/Flooded Unicast.

  • Page 50: Port Trunking

    IGS-3032GC User Manual 5.2.8 Port Trunking A port trunk is a group of ports that have been grouped together to function as one logical path. This method provides an economical way for you to increase the bandwidth between the switch and another networking device. In addition, it is useful when a single physical link between the devices is insufficient to handle the traffic load.

  • Page 51: Loop Guard

    IGS-3032GC User Manual The total number of active ports in a dynamic trunk group. The Work Ports default value of works ports is Max. In a dynamic trunk group, if the number of work ports is lower than the number of...

  • Page 52: Vlan

    IGS-3032GC User Manual Port Status Indicates the enabled/disabled status of the port. 5.3 VLAN 5.3.1 VLAN Setting - IEEE 802.1Q A VLAN (Virtual LAN) is a logical LAN based on a physical LAN with links that does not consist of a physical (wired or wireless) connection between two computing devices but is implemented using methods of network virtualization.
  • Page 53 IGS-3032GC User Manual Trunk Link: All the devices connected to a trnk link, including workstations, must be VLAN-aware. All frames on a trunk linke must have a special header attached. Hybrid Link: The combination of Access Link and Trunk Link.

  • Page 54: Traffic Prioritization

    IGS-3032GC User Manual Label Description VLAN Operation Mode Available options include Disable, Port Base, and 802.1Q Group Name The name of the VLAN that you want to change settings. VLAN ID The number of the VLAN Select ports from the left column and clicks Add to include...

  • Page 55: Qos Policy

    IGS-3032GC User Manual 5.4.1 QoS Policy Policing is a traffic regulation mechanism for limiting the rate of traffic streams, thereby controlling the maximum rate of traffic sent or received on an interface. When the traffic rate exceeds the configured maximum rate, policing drops or remarks the excess traffic. This page allows you to configure QoS policies for the switch.

  • Page 56: Port-Base Priority

    IGS-3032GC User Manual 5.4.2 Port-base Priority Label Description Assigns a port to a priority queue. Four priority queues are Priority available: High, Middle, Low, and Lowest. Apply Click to apply the configurations Help Shows help file. 5.4.3 COS/802.1p COS (Class of Service), also known as 802.1p, is a parameter for differentiating the types of payloads contained in the packet to be transmitted.

  • Page 57: Tos/Dscp

    IGS-3032GC User Manual Label Description Assigns a port to a priority queue. Four priority queues are Priority available: High, Middle, Low, and Lowest. Apply Click to apply the configurations Help Shows help file. 5.4.4 TOS/DSCP TOS (Type of Service) is a field in the IP header of a packet. It is used by Differentiated Services and is called the DSCP (Differentiated Services Code Point).

  • Page 58: Basic Setting

    IGS-3032GC User Manual DHCP server and dynamically assigns IP addresses and related IP information to network clients. 5.5.1 Basic Setting This page allows you to set up DHCP settings for the switch. You can check the Enabled checkbox to activate the function. Once the box is checked, you will be able to input information in each column.

  • Page 59: Client List

    IGS-3032GC User Manual been assigned. The time is measured in seconds. Apply Click to apply the configurations 5.5.2 Client List When DHCP server functions are activated, the switch will collect DHCP client information and display it in the following table.
  • Page 60 IGS-3032GC User Manual Label Description DHCP Relay Enables or disables DHCP relay agent DHCP Server Specify the IP address and VID of the DHCP server. 0.0.0.0 means Address and VID the server is inactive. DHCP Option Provides an identifier for the remote server. Four types of IDs are Remote ID supported: IP, MAC, Client-ID, and Other.

  • Page 61: Snmp

    IGS-3032GC User Manual in relaying DHCP responses back to the proper circuit. Apply Click to apply the configurations 5.6 SNMP SNMP (Simple Network Management Protocol) is a protocol for managing devices on IP networks. It is mainly used network management systems to monitor the operational status of networked devices.

  • Page 62: Trap Setting

    IGS-3032GC User Manual any of your SNMP agents. Since anyone with SNMP manager software installed on his/her PC can make changes to your SNMP agents, this will expose your SNMP agent to any SNMP management station. Privilege Choose the appropriate access level from the dropdown list.

  • Page 63: Snmpv3

    IGS-3032GC User Manual Label Description Server IP The IP address of the server to receive traps Community The community string for authentication Trap Version The trap version. V1 and V2c are supported. Click to add the trap sever to the trap server profile.
  • Page 64 IGS-3032GC User Manual Label Description Context Table Context is a collection of management information accessible by a SNMP entity and is stored in the context table. You can assign a context name to the context table and click Apply to change the name.

  • Page 65: Security

    IGS-3032GC User Manual table. Group Name: the name of the group Click Add after inputting the information. The Access table lists the access rights and restrictions of the various groups. 1. You can manage existing and add new tables in this section.
  • Page 66 IGS-3032GC User Manual Label Description Mode Indicates IP security mode. Enables or disables IP security functions. Enable WEB Management Check to enable WEB management Enable Telnet Management Check to enable Telnet management Enable SNMP Management Check to enable MPSN management Apply Click to apply the configurations.
  • Page 67 IGS-3032GC User Manual Label Description MAC Address Enter a MAC address for a specific port. Port NO. Select a switch port Add the MAC address and port information. Delete Deletes an entry Help Shows help file MAC Blacklist You can block specific devices from network access by creating a MAC blacklist.MAC blacklists will prevent traffic from forwarding to specific MAC addresses in the list.
  • Page 68 IGS-3032GC User Manual man-in-the-middle, forwarding requests and responses between the supplicant and the authentication server. Frames sent between the supplicant and the switch are special 802.1X frames, known as EAPOL (EAP Over LANs) frames which encapsulate EAP PDUs. Frames sent between the switch and the RADIUS server are RADIUS packets. RADIUS packets also encapsulate EAP PDUs together with other attributes like the switch's IP address, name, and the supplicant's port number on the switch.
  • Page 69 IGS-3032GC User Manual Label Description 802.1x Protocol Enables or disables 802.1X Radius server Radius Server IP IP address of the authentication server The UDP port number used by the authentication server to Server Port authenticate The number of the UDP port that the RADIUS server uses for Accounting Port accounting requests.
  • Page 70 IGS-3032GC User Manual The maximum number of times to retry sending packets to the Max Requests supplicant. The period of time after which clients connected must be Re-Auth Period re-authenticated Apply Click to apply the configurations Help Shows help file The 802.1x authorized mode of each port can be set in the following dialog:...

  • Page 71: Ip Guard

    IGS-3032GC User Manual 5.7.2 IP Guard Port Setting This page allows you to configure IP guard functions for each port, an intelligent and user-friendly IP security method. It protects the network from unknown IP (IPs not in the allowed list) attack. Unauthorized IP traffic will be blocked.
  • Page 72 IGS-3032GC User Manual Port Port number of the allowed entry The option allows you to block suspicious IP traffic. Status Active: allows the IP traffic. Suspend: blocks the IP traffic. Delete Check to delete an entry Super-IP List A super-IP list enables you to give full access to the switch to the user you specify. Devices with the IP addresses listed in the table will be able to manage the switch disregarding the rule you have set.

  • Page 73: Warning

    IGS-3032GC User Manual Port The port number you want to monitor Time The time when the entry is logged. Add to Allow List Check to add the entry to the allow list 5.8 Warning The switch supports several alerting methods, including SYSLOG, e-mail, and fault relay.

  • Page 74: Event Selection

    IGS-3032GC User Manual Label Description E-mail Alert Enables or disables transmission of system warnings by e-mail The IP address of the SMTP server to receive the SMTP Server IP Address notification e-mail Mail Subject Subject of the mail Sender The email account to send the alert...

  • Page 75: Monitor And Diag

    IGS-3032GC User Manual Label Description Device cold start Sends alerts when you restart the device using the power button on your PC. Sends alerts when you restart the device using the Reset Device warm start button or software. Authentication Failure...

  • Page 76: Mac Address Table

    IGS-3032GC User Manual Label Description Page The page number of the selected LOG Reload Click to refresh the information in this page Clear Clear log Help Shows help file 5.9.2 MAC Address Table A MAC address tablet is a table in a network switch that maps MAC addresses to ports. The switch uses the table to determine which port the incoming packet should be forwarded to.
  • Page 77 IGS-3032GC User Manual must be a multiple of 15. MAC Table Learning The switch can add the address and port on which the packet was received to the MAC table if the address does not exist in the table by examining the source address of each packet received on a port.

  • Page 78: Port Counters

    IGS-3032GC User Manual Apply Click to apply the configurations. Port Overview This page provides an overview of general traffic statistics for all switch ports. Label Description Type Shows port speed and media type. Link Shows port link status State Shows port status...
  • Page 79 IGS-3032GC User Manual Label Description InGoodOctetsLo The lower 32-bits of the 64-bit InGoodOctets counter. This field indicates the total length of all good Ethernet frames received. The upper 32-bits of the 64-bit InGoodOctets counter. This field InGoodOctetsHi indicates the total length of all good Ethernet frames received.
  • Page 80 IGS-3032GC User Manual Total frames received (and/or transmitted) with a length of between Octets127 65 and 127 octes, including those with errors. Total frames received (and/or transmitted) with a length of between Octets255 128 and 255 octes, including those with errors.
  • Page 81 IGS-3032GC User Manual Total frames received with a length of more than MaxSize octets Oversize but with a valid FCS Total frames received with a length of more than MaxSize octets Jabber but with an invalid FCS InMACRcvErr Total frames received with an RxErr signal from the PHY...

  • Page 82: Ping

    IGS-3032GC User Manual Apply Click to activate the configurations. Clear Clears all checked boxes (disable the function) Help Shows help file Traffic Monitoring By enabling traffic monitoring function, the switch will send out an SYSLOG event notification or SMTP e-mail when the traffic becomes too large.

  • Page 83: Save Configuration

    IGS-3032GC User Manual ping command, you can see if another site on the network can be reached After you press Active, four ICMP packets will be transmitted, and the sequence number and roundtrip time will be displayed upon reception of a reply. The page refreshes automatically...

  • Page 84: Factory Default

    IGS-3032GC User Manual 5.11 Factory Default This function is to force the switch back to the original factory settings. You can decide to keep current IP address settings or username/password by checking in the boxes. 5.12 System Reboot You can reset the stack switch on this page. After reset, the system will boot normally as if you...

  • Page 85: Command Line Interface Management

    IGS-3032GC User Manual ommand Line Interface Management Besides Web-based management, the switch also supports CLI management. You can use console or telnet to manage the switch by CLI. CLI Management by RS-232 Serial Console (115200, 8, none, 1, none) Before configuring RS-232 serial console, connect the RS-232 port of the switch to your PC Com port using a RJ45 to DB9-F cable.
  • Page 86 IGS-3032GC User Manual Step 3. Select a COM port in the drop-down list. Step 4. A pop-up window that indicates COM port properties appears, including bits per second, data bits, parity, stop bits, and flow control. ORing Industrial Networking Corp...
  • Page 87 IGS-3032GC User Manual Step 5. The console login screen will appear. Use the keyboard to enter the Username and Password (same as the password for Web browsers), then press Enter. CLI Management by Telnet You can can use TELNETto configure the switch. The default values are: IP Address: 192.168.10.1...
  • Page 88 IGS-3032GC User Manual User Name: admin Password: admin Follow the steps below to access console via Telnet. Step 1. Telnet to the IP address of the switch from the Run window by inputingcommands (or from the MS-DOS prompt) as below.
  • Page 89 IGS-3032GC User Manual Commands Level Modes Access Method Prompt Exit Method About This Model User EXEC Begin a session switch> Enter logout The user command with your switch. or quit. available at the level of user is the subset of those available at the privileged level.
  • Page 90 IGS-3032GC User Manual or end. Symbol of Command Level. Mode Symbol of Command Level User EXEC Privileged EXEC Global configuration VLAN database Interface configuration Commands Set List—System Commands Set IGS-3032GCCommands Level Description Example show config Show switch switch>show config configuration...
  • Page 91 IGS-3032GC User Manual function of switch show ip Show IP information of switch#show ip switch no ip dhcp Disable DHCP client switch(config)#no ip dhcp function of switch reload Halt and perform a switch(config)#reload cold restart default Restore to default Switch(config)#default...
  • Page 92 IGS-3032GC User Manual show dhcpserver Show IP-Binding switch#show dhcpserver ip-binding ip-binding information of DHCP server no dhcpserver Disable DHCP server switch(config)#no dhcpserver function security enable Enable IP security switch(config)#security enable function security http Enable IP security of switch(config)#security http HTTP server...
  • Page 93 IGS-3032GC User Manual the speed mode of operation for Fast Ethernet., the speed can’t be set to 1000 if the port isn’t a giga port.. flowcontrol mode Use the flowcontrol switch(config)#interface [Symmetric|Asymmetric] configuration fastEthernet 2 command on Ethernet switch(config-if)#flowcontrol mode...
  • Page 94 IGS-3032GC User Manual bandwidth in Set interface input switch(config)#interface [Value] bandwidth. Rate fastEthernet 2 Range is from 100 switch(config-if)#bandwidth in 100 kbps to 102400 kbps or to 256000 kbps for giga ports, and zero means no limit. bandwidth out Set interface output...
  • Page 95 IGS-3032GC User Manual status show interface show interface switch(config)#interface accounting statistic counter fastEthernet 2 switch(config-if)#show interface accounting no accounting Clear interface switch(config)#interface accounting fastEthernet 2 information switch(config-if)#no accounting Commands Set List—Trunk command set IGS-3032GCCommands Level Description Example aggregator priority Set port group system...
  • Page 96 IGS-3032GC User Manual range(ex.1-4) or a port list separate by a comma(ex.2, 3, 6) show aggregator Show the information switch#show aggregator of trunk group no aggregator lacp Disable the LACP switch(config)#no aggreator lacp 1 [GroupID] function of trunk group no aggregator group...
  • Page 97 IGS-3032GC User Manual [TaggedVID List] vlan 8021q aggreator Assign a access link switch(vlan)#vlan 8021q aggreator 3 [TrunkID] for VLAN by trunk access-link untag 33 access-link untag group [UntaggedVID] vlan 8021q aggreator Assign a trunk link for switch(vlan)#vlan 8021q aggreator 3...
  • Page 98 IGS-3032GC User Manual does not receive a bridge protocol data unit (BPDU) message from the root switch within this interval, it recomputed the Spanning Tree Protocol (STP) topology. spanning-tree Use the spanning-tree switch(config)#spanning-tree hello-time [seconds] hello-time global hello-time 3 configuration...
  • Page 99 IGS-3032GC User Manual Tree Protocol (STP) calculations. In the event of a loop, spanning tree considers the path cost when selecting an interface to place into the forwarding state. stp-path-priority Use the spanning-tree switch(config)#interface fastEthernet [Port Priority] port-priority interface configuration...
  • Page 100 IGS-3032GC User Manual Commands Set List—QoS command set IGS-3032GCCommands Level Description Example qos policy Select QOS policy switch(config)#qos policy [weighted-fair|strict] scheduling weighted-fair qos prioritytype Setting of QOS switch(config)#qos prioritytype [port-based|cos-only|tos priority type -only|cos-first|tos-first] qos priority portbased Configure Port-based switch(config)#qos priority portbased...
  • Page 101 IGS-3032GC User Manual snooping function no igmp-query Disable IGMP query switch#no igmp-query Commands Set List—MAC/Filter Table command set IGS-3032GCCommands Level Description Example mac-address-table static Configure MAC switch(config)#interface fastEthernet hwaddr address table of [MAC] interface (static). switch(config-if)#mac-address-table static hwaddr 000012345678 mac-address-table filter...
  • Page 102 IGS-3032GC User Manual community information and trap-version v1 [Community-string] community string (remove) trap-version Switch(config)# [v1|v2c] no snmp-server host 192.168.10.50 snmp Configure the switch(config)#snmp community-strings community string right community-strings public right RO [Community-string] right switch(config)#snmp [RO|RW] community-strings public right RW snmp snmpv3-user...
  • Page 103 IGS-3032GC User Manual function monitor tx Set TX destination switch(config)#monitor tx port of monitor function show monitor Show port monitor switch#show monitor information monitor Configure source port switch(config)#interface fastEthernet [RX|TX|Both] of monitor function switch(config-if)#monitor RX show monitor Show port monitor...
  • Page 104 IGS-3032GC User Manual the accounting port 8021x system sharekey Use the 802.1x switch(config)# 8021x system [ID] system share key sharekey 123456 global configuration command to change the shared key value. 8021x system nasid Use the 802.1x switch(config)# 8021x system nasid...
  • Page 105 IGS-3032GC User Manual command to set the MAX requests. 8021x misc Use the 802.1x misc switch(config)# 8021x misc reauthperiod [sec.] reauth period global reauthperiod 3000 configuration command to set the reauth period. 8021x portstate Use the 802.1x port switch(config)#interface fastethernet...
  • Page 106 IGS-3032GC User Manual upgrade Upgrade firmware by switch(config)#upgrade flash:upgrade_fw TFTP and need to lash:upgrade_fw specify the IP of TFTP server and the file name of image. 6.13 Commands Set List—SYSLOG, SMTP, EVENT command IGS-3032GCCommands Level Description Example systemlog ip Set System log server...
  • Page 107 IGS-3032GC User Manual event device-cold-start Set cold start event switch(config)#event [Systemlog|SMTP|Both] type device-cold-start both event Set Authentication switch(config)#event authentication-failure failure event type authentication-failure both [Systemlog|SMTP|Both] event Set s ring topology switch(config)#event O-Ring-topology-change changed event type ring-topology-change both [Systemlog|SMTP|Both] event systemlog...
  • Page 108 IGS-3032GC User Manual 6.14 Commands Set List—SNTP command set IGS-3032GCCommands Level Description Example sntp enable Enable SNTP function switch(config)#sntp enable sntp daylight Enable daylight saving switch(config)#sntp daylight time, if SNTP function is inactive, this command can’t be applied. sntp daylight-period...
  • Page 109 IGS-3032GC User Manual no sntp Disable SNTP switch(config)#no sntp function no sntp daylight Disable daylight switch(config)#no sntp daylight saving time 6.15 Commands Set List—O-Ring command set IGS-3032GCCommands Level Description Example Ring enable Enable O-Ring switch(config)# ring enable Ring master Enable ring master...

  • Page 110: T Echnical Specifications

    IGS-3032GC User Manual echnical Specifications ORing Switch Model IGS-3032GC Physical Ports 10/100/1000 Base-T Ports in RJ45 Auto MDI/MDIX Gigabit Combo Port with 10/100/1000Base-T(X) and 100/1000Base-X SFP port Technology IEEE 802.3 for 10Base-T, IEEE 802.3u for 100Base-TX and 100Base-FX IEEE 802.3z for 1000Base-X IEEE 802.3ab for 1000Base-T(X),...
  • Page 111 IGS-3032GC User Manual Ring Indicator Green : Indicate system operated in O-Ring mode Fault Indicator Amber : Indicate unexpected event occurred 10/100/1000Base-T(X) RJ45 Port Green for port Link/Act. Amber for 100Mbps indicator Indicator 100/1000Base-X SFP Port Indicator Green for port Link/Act.
