Net to Net Technologies 12-Port SHDSL Access Multiplexer SAM2000G-12 User Manual page 4

PARAMETER
Gateway
Inband Management
Inband Management VLAN ID
IP Address: IPD12000 Slot 13
IP Address: IPD12000 Slot 14
IP Address: IPD4000 Slot 5
Management IP Address Filter Range
Subnet Mask
3.2 SAM2000G Port Parameters
PARAMETER
Circuit Identification
Back-bone VLAN
Flood
IP Range 1
IP Range 2
Priority (VLAN)
Protocol
Speed
VLAN Range
4.0 SAM2000G MANAGEMENT
Once your SAM2000G has been installed, bandwidth and other configurations are software selectable via
your IP DSLAM's MUM. Dependent upon the MUM model installed, the SAM2000G may be configured via
Command Line Interface (CLI), Simple Network Management Protocol (SNMP) and/or Net to Net
Technologies' web-based Network Management System (NMS).
If your IP DSLAM is newly installed, configuration of the DSLAM's IP Address, Subnet Mask and Gateway
must be completed, via CLI or NMS, before you will be able to access management data or configure any
other parameters. Refer to the CLI Management User Guide
0000052) or to the NMS Management User Guide
0000048) for initial configuration instructions.
210-0000026 rev07
DEFAULT CONFIGURATION
0.0.0.0
off
0 (off)
192.168.254.252
192.168.254.253
192.168.254.252
0.0.0.0 - 255.255.255.255 (all)
255.255.255.0
DEFAULT CONFIGURATION
n/a (no default)
0 (off)
uplink
0.0.0.0 - 255.255.255.255 (all)
0.0.0.0 - 0.0.0.0
0 (none)
all
272 kbps
0 - 0 (off)
(http://www.nettonet.com/support/docs/210-
(http://www.nettonet.com/support/docs/210-
