12-Pin Accessories Harness - ProStart CT-3100 Installation Manual

12-Pin Accessories Harness

Wire
1
2
3
4
5
6
7
8
9
9
CT-3200 Installation Guide
Downloaded from www.Manualslib.com
There is also a negative parking light output. Only one of these two
different outputs needs to be connected.
Function
500 ma negative output. This output can be used to control trunk release
(1-sec. pulse) or can be set to operate as a constant output as long as
BLUE
Ι & ΙΙ
(–) AUX 3 buttons
(Trunk) output
Aux 3 (trunk) operates only when ignition is off or when the vehicle is
running under remote control.
BROWN
Programmable 500 mA negative output: 7/10-sec. or 4-sec. pulse.
(–) Lock output
GREEN Programmable 500 mA negative output: 7/10-sec., 4-sec. or double 1/4-
(–) Unlock
sec. pulse.
output
Max. 500-ma ground signal when the doors are locked by remote. This
wire will go to ground 1/4 sec. before the lock pulse and go off 1/8 sec.
after lock. It must be connected to the OEM arm wire (usually the door
WHITE/BROWN
(–) Arm output pin).
Note: The system also gives a rearm pulse on this wire after remote-start
shutdown.
Max. 500-ma 1-sec. ground pulse when the doors are unlocked by
WHITE/GREEN
remote control. Connect to the OEM disarm wire of the vehicle. Note: the
(–) Disarm
output
system also gives a disarm pulse on this wire before remote start.
500 mA ground output for horn confirmation on the first or second press
BLUE/WHITE
of the I button –depending on the option that was selected in the
(–) AUX 1
programming menu (see page 9).
The unit is equipped with a selectable passive or active arming starter kill
circuit that will immobilize the vehicle when the system is armed. This
wire will provide a constant 500-ma negative output when the system is
armed (locked by remote) or if remote started. This wire should be
connected to a single pole double-throw relay (this wire will connect to pin
WHITE/ORANGE
85, on the relay, and pin 86 will be connected to the ignition wire). A
(–) Starter Kill
(Armed output)
second benefit of the starter kill is the anti-grind feature. When the
vehicle has been remote started the anti-grind prevents the starter motor
from re-engaging when the ignition key is inserted in the ignition switch
and accidentally turned to the crank position (the starter kill output
becomes active during remote starts).
ORANGE
Negative parking light output.
(–) Parking Light
output
The external trigger wire can be used for remote-starting the vehicle with
an external device. When the vehicle is running, triggering this input will
PURPLE
activate idle mode. the external trigger wire can also be used to operate
(–) External
Trigger input
as a negative trigger with the trunk pin-switch, the key sense wire or the
door pin-switch:
Option 1 connects to negative trunk pin. When this wire is
PURPLE
programmed for trunk pin, pressing
(–) External
Trigger input 1-second disarm output. If ground (-) is detected on the trunk pin (the
(cont'd)
trunk has been opened), an arm pulse will be sent 5 seconds after the
trunk is closes. an arm pulse will be sent 4 seconds after buttons
manuals search engine
Description
are held pressed (for sunroof or window close).
Ι & ΙΙ
simultaneously will activate a
Ι & ΙΙ
