ADJUSTING AREA SETUP

1. Click the AREA SETUP button of the camera
you wish to change.
2. The camera will be displayed full screen and
will be orange in color with a light blue grid
covering the entire frame.
3. By default the entire frame is set to detect
motion (indicated by orange shading). To
change this, you can deselect specific areas.
4. To deselect areas, click a square on the grid
that is in the area you want to deselect.
Hold the click button down and drag the
mouse across the desired area.
5. You will see a yellow box appear on screen
as you are dragging. Everything within
this area will NOT trigger motion recording
(indicated by blue shading). When the
area you want is inside the yellow box, let
go of the mouse button. The squares will
then turn blue.
