MAIN MENU

CHANGING THE CAMERA TITLE

1. Double click the camera title. A virtual keyboard will pop up

2. Enter a title for the camera by clicking each letter individually.

The title can be up to 11 characters and can include both

numbers and letters.

3. The

button allows you to move between capital letters and

lowercase, and

can be used to delete letters.

4. When you have finished making sequence title, click

exit the onscreen

MAKING CHANGES TO THE COLOR SETUP MENU:

1. After saving any desired changes to other menus, click the COLOR SETUP title on the left hand side of the window.

2. A list of cameras is displayed on screen as well as well as brightness, contrast, tint, and color options for each camera.

3. To view a camera in full screen and make adjustments

use the mouse to double click one of the settings of the

camera you wish to change.

4. The camera will pop up in full screen and a status bar

at the bottom of the screen will display each of the 4

settings as well as the camera channel.

5. Under BRIGHTNESS, click the

brightness between 1 and 100 (the default is 60).

6. Under CONTRAST, click the

brightness between 1 and 100 (the default is 50).

7. Under TINT, click the

brightness between 1 and 100 (the default is 50).

8. Under COLOR, click the

brightness between 1 and 100 (the default is 50).

9. When you have completed changing settings for that particular camera, you can use the

10. When you have made all desired adjustments, click

SENTINEL10

keyboard.

buttons to adjust the

to exit the setup screen.

buttons to select another camera channel.
