Defender 82-13080 Instructional Manual

4 channel h.264 digital video recorder
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
4 Channel H.264 Digital Video Recorder
Model# 82-13080
Instructional Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 82-13080 and is the answer not in the manual?

Questions and answers

Related Manuals for Defender 82-13080

Summary of Contents for Defender 82-13080

  • Page 1 4 Channel H.264 Digital Video Recorder Model# 82-13080 Instructional Manual...
  • Page 2 INSTRUCTION MANUAL To obtain the best performance and ensure device function correctly, please read this instruction manual carefully and completely. FCC Compliance USER-INSTALLER CAUTION: YOUR AUTHORITY TO OPERATE THIS FCC VERIFIED EQUIPMENT COULD BE VOIDED IF YOU MAKE CHANGES OR MODIFICATIONS NOT EXPRESSLY APPROVED BY THE PARTY RESPONSIBLE FOR COMPLIANCE TO PART 15 OF THE FCC RULES.

  • Page 3: Table Of Contents

    TABLE OF CONTENTS INTRODUCTION........................5 FEATURE ........................5 SPECIFICATION......................5 HARDWARE OVERVIEW...................... 8 FRONT PANEL ......................8 BACK PANEL........................9 ADVANCED AUTO SWITCH, ZOOM, PTZ, COPY KEY CONTROL & USB INFORMATION ........................9 EXTERAL ALARM.....................10 IR REMOTE CONTROL ...................12 PTZ (PAN, TILT AND ZOOM) CAMERA ...............13 SYSTEM SETUP ........................
  • Page 4 Half D1- 720x240..........................64 CIF-360x240 ............................. 67 APPENDIX B: HDD COMPATIBLE TABLE ................70 APPENDIX C: ERROR MESSAGE LIST..................71...

  • Page 5: Introduction

    INTRODUCTION FEATURE H.264 video compression. 120 PPS Recording quality/ rate adjustment per channel available. Support CMS (Central Management System)/ 3GPP. Audio Backup / Audio Streaming. Graphic User Interface (GUI). Support time-point backup function under Ethernet remote control mode. User can select any time period to process backup from remote side.
  • Page 6 AUDIO STREAMING RECORDING H.264 COMPRESSION TYPE RECORDING RESOLUTION (HALF 720 x 240 720 x 288 360 x 240 360 x 288 RECORDING RESOLUTION (CIF) 720 x 480 up to 60 PPS 720 x 488 up to 50 PPS RECORDING RATE (HALF D1) 360 x 240 up to 120 PPS 360 x 288 up to 100 PPS RECORDING RATE (CIF)
  • Page 7 E-MAIL & FTP Static/ Dynamic/ PPPoE NETWORK IP Yes ( 4 Clients at the same time available) MULTI-REMOTE CLIENT Yes ( MPEG4 ) PDA/ CELL PHONE SUPPORT Yes ( MPEG4 ) 3GPP ALARM 4 In (NO/ NC) ALARM INPUT 1 Out (NO/ NC) ALARM OUTPUT MOTION DETECTION VIDEO LOSS DETECTION...

  • Page 8: Hardware Overview

    HARDWARE OVERVIEW 2.1 FRONT PANEL DVR OPERATION LABEL OPERATION IR Sensor For Remote Control. Led Indicator LED REC CONTROL Record, Playback And Control Button. PANEL Press The Button To Display No.1~No.4 Full Screen and 1-4 & Quad Quad Screen DOWN, ▲▼◄►...

  • Page 9: Back Panel

    2.2 BACK PANEL LABEL OPERATION USB Mouse Connector (Only by supplied mouse). VIDEO INPUT Video input with BNC connector. MONITOR OUT Video output with BNC connector. AUDIO OUT/ IN Audio output/ input. ETHERNET RJ-45 connector for network. RS-485/ ALARM/ 4 pin connector for external control unit, 5 pin connector for RELAY Alarm input and 3 pin connector for relay VGA D-SUB OUT...

  • Page 10: Exteral Alarm

    2.4 EXTERAL ALARM There are three types of alarms that the system can be configured to handle. They are Motion detection Alarm, External Alarm and Video Loss Alarm. A. Motion detection Alarm and External Alarm: When motion detection or External Alarm was triggered, there are 5 possible actions will be taken.
  • Page 11 Terminal Connectors: RS-485 sends +/ receives + RS-485 sends -/ receives - RS-485 sends +/ receives + RS-485 sends -/ receives - ALARM1-4 Camera alarm input. GND. Relay N.C. Relay COM Relay N.O. EXAMPLE 1：Connect Alarm In One with PIR (Passive Infrared). EXAMPLE 2：Connect with Alarm Siren at Relay N.O.

  • Page 12: Ir Remote Control

    IR REMOTE CONTROL ITEM Press REC to start recording and press twice to stop. Select channel 1-4 with full screen. 1 - 4 Fast backward. QUAD Picture by picture backward. Picture by picture forward. Fast Forward. Play video forward. Switch channel format. COPY Move upward or increase the number.

  • Page 13: Ptz (Pan, Tilt And Zoom) Camera

    2.6 PTZ (PAN, TILT AND ZOOM) CAMERA Following diagram for DVR connect between PTZ camera & joystick controller, for DVR to control PTZ camera please make sure the CAMERA ID, BANDRATE (default at 9600 bps) and RS-485 cable. 2 CORE Under “Two Core”...

  • Page 14: System Setup

    3 SYSTEM SETUP 3.1 MENU SETUP INTERFACE(GUI) CAMERA SET MOTION SETUP RECORD SETUP ALARM SETUP HARD DISK SETUP NETWORK SETUP...
  • Page 15 BACKUP SETUP SYSTEM SETUP...

  • Page 16: Live Viewing And Pop-Up Menu

    3.2 LIVE VIEWING AND POP-UP MENU NOTE：The pop-up menu can be activated by moving the mouse cruise to the bottom of the live viewing screen. GUI MENU BAR With live viewing mode, press this button to get into the GUI menu. DISK INFORMATION With live viewing mode, press this button to display disk information.
  • Page 17 PTZ CONTROL Under PTZ control mode, press into PTZ setup menu. User can also press the “MENU” key on the DVR front panel to get into PTZ setup menu. Press to process Preset Point setup and press “■” to exit setup To process AUTO function.

  • Page 18: Camera Setup

    AUDIO CONTROL Press this button to turn the audio on or off. DISPLAY CONTROL Within live-viewing or playback mode, use display control to switch the camera channel. RECORD AND PLAYBACK CONTROL Same as front panel controller and remote controller. CAMERA SETUP Press ▲...
  • Page 19 B-4. COLOR Press ◄ or ►/ mouse wheel to change color level. B-5. SHAPRNESS Press ◄ or ►/ mouse wheel to change sharpness level. C. CAMERA TITLE Use mouse to select and change character. D. DISPLAY Press ◄ or ► to/ mouse wheel change value for the corresponding camera would be displayed on the screen or not.

  • Page 20: Motion Setup

    MOTION SETUP Press ▲ or ▼ to select items. Press ◄ or ► to change values. Press SET to see more options. A. CAMERA Press ◄ or ►/ mouse wheel to switch channels. B. MOTION DETECT Press ◄ or ►/ mouse wheel to change value for motion detect function. C.

  • Page 21: Record Setup

    3. Left-Click the mouse to see more options or exit the setup. SELECT: Cancel the selected area. CLEAR: Select the area without motion detection. EXIT: Exit the motion detection setup. RECORD SETUP Press ▲ or ▼ to select items. Press ◄ or ► to change values.
  • Page 22 B. NORMAL RECORD PPS Press SET to change the PPS in normal recording. User can click “AVERAGE” to set PPS automatically by system or change the PPS for each channel manually. Record Resolution: HALF D1: 720 × 240 ( NTSC ) / 720 × 288 ( PAL ) Record Resolution: CIF: 360 ×...
  • Page 23 D. ALARM RECORD DURATION Press ◄ or ► to set dwell time of alarm recording. E. RECORD QUALITY Press SET to switch image quality of each channel (720 × 240 ( NTSC ) / 720 × 288 ( PAL )) or each two channels (360 × 240 ( NTSC ) / 360 × 288 ( PAL )). User can use mouse wheel to change the image quality of each single channel: LOW/ MEDIUM/ HIGH/ BEST, or use “AVERAGE”...

  • Page 24: Alarm Setup

    H. SCHEDULE SETUP Press SET to get into schedule setup menu。 1. Use mouse to select schedule day/ time/ mode. 2. Click to save change and exit. ALARM SETUP Press ▲ or ▼ to select items. Press ◄ or ► to change values. Press SET to see more options.

  • Page 25: Hard Disk Management Setup

    HARD DISK MANAGEMENT SETUP Press ▲ or ▼ to select items. Press ◄ or ► to change values. Press SET to see more options. A. OVERWRITE MODE Press ◄ or ► to change value OVERWRITE MODE ON or OFF. B. CAPACITY WARNING (When Overwrite Mode is OFF, Capacity Warning will enable) Press ◄...

  • Page 26: Network Setup

    NETWORK SETUP Press ▲ or ▼ to select items. Press ◄ or ► to change values. Press SET to see more options. A. IP MODE Press ▲ or ▼ to select items and ◄ or ►/ mouse wheel to change to STATIC IP or DHCP.
  • Page 27 H-4. STATE Press SET to display status of PPPoE。 I. DDNS SETUP I-1. DDNS SETTING：Press◄ or ►/ mouse wheel to set DDNS ENABLE / DISABLE. I-2. PROVIDER：Press◄ or ►/ mouse wheel to select DDNS provider. I-3. USER NAME：Press SET to setup user name. I-4.

  • Page 28: Backup Setup

    BACKUP SETUP NOTE: *For function stability, Ethernet remote control function (IE) will be stopped when processing backup function. *USB DEVICE BACKUP : 3.2MB/ per sec. A. USB BACKUP Due to each USB device with different USB driver ICs, their compatibilities differ, too. This system is compatible with most of USB flash memory.
  • Page 29 USB BACKUP MENU User can use the mouse wheel to change the backup Start/ End time。 Click to start backup, the total process will be shown on screen. BACKUP FILE NAME Each backup file will be named as START TIME. EXAMPLE: 174624.264 is 17:46:24 AFTER BACKUP After backup, the system will copy “R6VIEWER.EXE”...

  • Page 30: System Setup

    3.10 SYSTEM SETUP Press ▲ or ▼ to select items. Press ◄ or ► to change values. Press SET to see more options. A. DATE / TIME SETUP Press SET to set DATE / TIME. A-1. TIME Use mouse wheel to change DATE/ TIME. A-2.
  • Page 31 D. DVR ID NUMBER Press ◄ or ►/ mouse wheel to change values. ID NUMBER is required to make difference of each DVR. E. DISPLAY SETUP Press SET to ENABLE or DISABLE display of CAMERA TITLE / DVR STATUS / DATE / TIME.
  • Page 32 J-1. MANUAL MODE Use SET to change the Day Light Saving start and end time. Press ◄ or ►/ mouse wheel to change DELAY TIME J-2. AUTO MODE Press ◄ or ►/ mouse wheel to change CITY option. Different CITY will have different START, END and DELAY TIME.

  • Page 33: Dvr Playback

    4 DVR PLAYBACK Click the playback button on the pop-up menu. Note: the pop-up menu can be activated by moving the mouse cruise to the bottom of the live viewing screen. DISK INFORMATION With playback mode, press this button to display disk and pen drive information. RECORD BACKUP With playback mode, press this button to backup record (.264 video backup) and press this button again to finish backup.

  • Page 34: Time Search

    TIME SEARCH Double click Left button of mouse to trigger play time search. Please set the start and end time to search.

  • Page 35: Event Search

    EVENT SEARCH Double click Left button of mouse to trigger event search. Please select the event to playback. NOTE: Display the type of the event as follows. POWER If the DVR got power loss, it will record the date and time of rebooting.

  • Page 36: Backup Playback

    5 BACKUP PLAYBACK SYSTEM REQUIREMENT CPU: Intel Celeron 1.6G MEMORY: 256MB. VGA: 32MB VGA RESOLUTION: 1024 x 768. OS: Windows XP / 2000 SUGGESTED REQUIREMENT CPU:Intel P4 2.8G MEMORY:512MB or above VGA:64MB or above VGA RESOLUTION:1024 x 768 OS: Windows XP / 2000 MAIN SCREEN SETTING Control Panel A.
  • Page 37 B. HDD PLAY Play about all the data from the Hard disk of DVR or perform the specific Time and Event Search to play. Note: Remove the DVR HDD and connect to the PC first. Then, use DVR player (R6Viewer.exe) to play the data of HDD. DVR player (R6Viewer.exe) can be attained from the attached CD or via the Internet;...
  • Page 38 B-2. EVENT SEARCH It will display all the events which are reserved within the DVR HDD after press (Shown in the following) and double click left button of mouse to trigger event. B-3. HDD COPY Copied and reserved the DVR HDD data to other data storage device. Press button, the Copy screen will pop-up.
  • Page 39 Finally, the complete information will pop-up while finished storage. (R6 Viewer.exe) can play not only DVR H.D.D. but also the *.264 and *.Y42 files which are reserved within the data storage devices. (i.e. CD/DVD disc, pen drive and the PC H.D.D which the data backup from DVR H.D.D) C.

  • Page 40: Cd/Dvd Backup Playback

    5.2 CD/DVD BACKUP PLAYBACK A. Insert the CD/DVD disk into CD/DVD ROM, the software will auto pop out, and select "Open File" and pick up the file. B. Press the icon to play the video.

  • Page 41: Usb & Local Backup File Playback

    USB & LOCAL BACKUP FILE PLAYBACK A. Plug the USB disk into PC or check the local backup folder. If using USB mode, please double click the player.exe from the pop-up diagram. (As below) B. The play backup program would appear on the screen, select "Open File".
  • Page 42 C. Open the USB disk located driver letter. (Example E:) or the local backup folder, and pick the file to playback. The backup file will named as the time when backup, as like: 170319.264 will be 17:03:19 D. Press the play icon to play the video or still picture.

  • Page 43: Backup File To Avi

    BACKUP FILE TO AVI A. Please select specific channel to backup. B. During video playback mode please press AVI bottom to start. C. Make up a filename and path than press bottom to start AVI backup. D. Press AVI bottom to finish backup.

  • Page 44: Network Viewing & Playback

    6 NETWORK VIEWING & PLAYBACK SYSTEM REQUIREMENT CPU: Intel Celeron 1.6G MEMORY: 256MB. VGA: 32MB VGA RESOLUTION: 1024 x 768. OS: Windows XP / 2000 SUGGESTED REQUIREMENT CPU:Intel P4 2.8G MEMORY:512MB or above VGA:64MB or above VGA RESOLUTION:1024 x 768 OS: Windows XP / 2000 6.1 IP ADDRESS SETUP ON PC SITE Install cameras inside in LAN or use network cable to connect with PC.

  • Page 45: Optional Microsoft Internet Explorer Setup

    NOTE: Please input correct network parameters without blank spaces. On Device Lists, it lists all servers. Click on one server and then its IP setting will show on the right side. After editing the parameters and clicking on Submit, the following dialogue box will popup.
  • Page 46 Above three options are all based on select as the prompt. As indicated in the dialogue box. Please select "YES."...
  • Page 47 OPTION 2: ADD TO TRUSTED SITES Tools Internet Options Security Trusted sites Sites...

  • Page 48: Login

    6.3 LOGIN INSTALL ACTIVEX START INSTALL ACTIVEX ACCOUNT & PASSWORD LOGIN After IP setup and connect to network or LAN, type IP address on IE Browser directly. The following User name & Password Login window will popup. Default user name: admin Default password: admin...

  • Page 49: Remote Control

    6.4 REMOTE CONTROL LIVE VIEWING DVR Configuration PTZ Control Screen Time-Point System Time Playback Format Backup Full Screen A. DVR Configuration Get into DVR network menu. B. PTZ Control PTZ control function panel Direction Keys PTZ Zoom in/out Auto Pan Function Preset Point Setup...
  • Page 50 Up to 32 preset points for operation C. SYSTEM TIME Live viewing mode: The current live viewing time. D. SCREEN FORMAT Switch screen format and click twice to switch different channels with full screen. Full Screen. Click again to return. REC.
  • Page 51 PLAYBACK by TIME SEARCH & EVENT SEARCH Playback Time Time Search Event Search HDD Select Playback Time A. HDD Select User can select HDD1 or HDD2 for playback B. Playback Time User can select the time then press “Time Search” for playback. C.
  • Page 52 Click to operate Time-Point backup. TIME-POINT BACKUP First, select Start and End backup time which have to among the Record Time. Then, click Save button to select the position on PC where the user is going to backup the data. After that, press OK button to start the backup.
  • Page 53 OTHER FUNCTIONS User can use other functions by clicking the left of mouse A. Snapshot: User can save any single picture from image. B. Performance: User can select image quality (high, medium & low). C. Use Overlay: User can use Overlay function. D.

  • Page 54: Configure

    6.5 CONFIGURE A. System - System Information A-1 SYSTEM INFORMATION SERVER NAME: This name will show on the IP Installer. A-2 NTP Setting NTP SERVER: Revise the time of DVR via different NTP Server. Note: Time zone and Interval cannot adjust in here (User can adjust both in DATE and TIME SETUP option of DVR Menu).
  • Page 55 B-1. ANONYMOUS USER LOGIN: YES: Accept anonymous user login without password as guest login. NO: Anonymous login unacceptable. B-2. USER MANAGEMENT: Add: Input Username and Password and then click on Add/Set to save. Modify: Click on selected User name on User List and the following window will popup.
  • Page 56 D. NETWORK – IP SETTING D-1. IP ASSIGNMENT DHCP: In Dynamic Host Configuration Protocol (DHCP) mode, DHCP server will get setting done automatically. STATIC IP: Please input IP address, Subnet Mask, and Gateway based on network environment. D-2. PORT ASSIGNEMENT With IP Share (Router), the following Ports needed to be adjusted in case of conflict.
  • Page 57 E-1. PPPoE SETTING Click on Enabled to enable ADSL dial function. Username: Username for ADSL account. Password: Password for ADSL account. After dialed successfully, new IP address will appear. E-2. SEND MAIL AFTER DIALED Click on Enabled to enable SEND MAIL AFTER DIALED function. E-3.
  • Page 58 F-1. DYNDNS.ORG DDNS SETTING - DYNDNS.ORG PROVIDER: Select dyndns.org HOSTNAME: The registered hostname in DYNDNS.ORG. USERNAME: The registered username in DYNDNS.ORG. PASSWORD: The registered password in DYNDNS.ORG. SCHEDULE UPDATE: A period of time to update IP address. STATE 1. Updating: Information update. 2.
  • Page 59 DDNS SETTING – DDNS.CAMDDNS.COM PROVIDER: Select ddns.camddns.com USERNAME: The registered username in DDNS.CAMDDNS.COM. SCHEDULE UPDATE: A period of time to update IP address. STATE 1. Updating: Information update. 2. Idle: Stop service. 3. DDNS registered successfully, now log by http://<username>.ddns.camddns.com: Registered successfully. 4.
  • Page 60 ○ Finally, the DVR domain name 5 (http://DVR_GODDNS.ddns.camddns.com) will be shown on the state block. NOTE: 1. If the user selects another provider which is ddns2.ydsdvr.com, all of the setting steps are the same with ddns.camddns.com setting. 2. However, if dyndns.org provider is selected, please go to www.dyndns.org website to register the account first.
  • Page 61 Mail Server: The IP address of Mail Server (i.e. mail.huntelec.com.tw). SMTP Port: The port of SMTP (known as Simple Mail Transfer Protocol). (Default value is 25) Username: The username while log in to the mail server. Password: The password while log in to the mail server. Sender’s Mail: The sender’s account when send the mail via this mail server.

  • Page 62: 3Gpp Application & Setting

    3GPP APPLICATION & SETTING 3GPP (also known as 3 Generation Partnership Project) is a corporation which formulate -generation communication standard specification. Via this wireless communication protocol, the 3G mobile can perform the remote control. The following example is operated by Sony Ericsson 3G mobile phone: 1.
  • Page 63 “Connected to media server” will 8. Success with vivid image appear * 1. 3GPP BANDWIDTH: Minimum 30kbit /sec. per channel. 2. CONNECTION NUMBERS: Maximum 16 people per channel.

  • Page 64: Appendix A: Recording Time Lapse (Hours)

    APPENDIX A: RECORDING TIME LAPSE (HOURS) Half D1- 720x240 Unit: Hour 80 GB Hard Disk PICTURE QUALITY (KB) Recording MEDIUM HIGH BEST Speed simple complex average simple complex average simple complex average simple complex average (PPS) 1.00 3.80 2.40 2.00 6.00 4.00 5.00...
  • Page 65 PICTURE QUALITY (KB) Recording MEDIUM HIGH BEST Speed simple complex average simple complex average simple complex average simple complex average (PPS) 1.00 3.80 2.40 2.00 6.00 4.00 5.00 10.00 7.50 6.00 17.00 11.50 1941 1226 3883 1022 2452 1941 1294 7767 2044 4905...
  • Page 66 2427 1532 1213 4854 1277 3065 2427 1618 9709 2555 6132 4854 1618 3236 1941 1455 1618 1094 19418 5110 12264 9709 3236 6472 3883 1941 2912 3236 1142 2189 36408 9581 22994 18204 6068 12136 7281 3640 5460 6068 2141 4104 72817...

  • Page 67: Cif-360X240

    CIF-360x240 Unit: Hour 80 GB Hard Disk PICTURE QUALITY (KB) Recording MEDIUM HIGH BEST Speed simple complex average simple complex average simple complex average simple complex average (PPS) 0.50 1.90 1.20 1.00 3.00 2.00 2.50 5.00 3.75 3.00 8.75 5.88 1553 3106 1961...
  • Page 68 PICTURE QUALITY (KB) Recording MEDIUM HIGH BEST Speed simple complex average simple complex average simple complex average simple complex average (PPS) 0.50 1.90 1.20 1.00 3.00 2.00 2.50 5.00 3.75 3.00 8.75 5.88 1941 1226 3883 1022 2452 1941 1294 7767 2044 4905...
  • Page 69 Speed MEDIUM HIGH BEST (PPS) simple complex average simple complex average simple complex average simple complex average 0.50 1.90 1.20 1.00 3.00 2.00 2.50 5.00 3.75 3.00 8.75 5.88 2427 1532 1213 4854 1277 3065 2427 1618 9709 2555 6132 4854 1618 3236...

  • Page 70: Appendix B: Hdd Compatible Table

    APPENDIX B: HDD COMPATIBLE TABLE Brand Model Capacity Speed (RPM) SEAGATE ST3160815AS 160G 7200 10 STM3250820AS 250G 7200 10 ST3500320SV 250GB SV35.3 ST3400620AS 400G 7200 10 ST3500320SV 500GB SV35.3 ST3500320AS 500GB 7200 11 ST3500418AS 500GB 7200 12 ST3750640AS 750G 7200 10 ST3750330AS 750G 7200 11...

  • Page 71: Appendix C: Error Message List

    APPENDIX C: ERROR MESSAGE LIST ERROR MESSAGE ERROR STATUS & REASON NOTE DISK ACCESS ERROR! H.D.D. Data structure Un-normal. Data does not record into DVR or bad sector on DVR H.D.D. Please install another H.D.D. and perform the record again. UPDATE FILE ERROR! Please re-download the update file and update again.
