36
L
Battery
R
T02086 Small clip
...............4
< Front >
37
Wheel
Must be purchased separately
X
x2
TR4034
X
Front-tyre
TR4034
X
Front sponge
TR4032
Front Rim
Assemble both Left and Right
L
R
TU0426
Carbon Battery Plate
T02086
< Rear >
TR4035
X
Rear-tyre
TR4035
X
Rear sponge
TR4033
x2
Assemble as many times as specified
18
T02086
X
Battery
x2
F
After fitting wheels to tyres,
apply instant glue as shown.
Rear Rim
Assemble both Front and Rear
F
R
x2
R
