Installation Instructions
Compact™ 16-Point 100 to 240V ac Solid State
Output Module
(Catalog Number 1769-OA16)
Inside
Module Description ................................................................................. 2
Module Installation.................................................................................. 3
System Assembly..................................................................................... 4
Mounting Expansion I/O .......................................................................... 5
Replacing a Single Module within a System .......................................... 7
Field Wiring Connections......................................................................... 8
I/O Memory Mapping ............................................................................ 11
1769-OA16 Configuration File ............................................................... 12
Spare/Replacement Module Parts ........................................................ 13
Specifications ........................................................................................ 14
Hazardous Location Considerations ...................................................... 17
Environnements dangereux ................................................................... 17
For More Information ............................................................................. 18
Advertisement
Table of Contents
Related Manuals for Rockwell Automation 1769-OA16
Summary of Contents for Rockwell Automation 1769-OA16
-
Page 1: Table Of Contents
Mounting Expansion I/O ................5 Replacing a Single Module within a System .......... 7 Field Wiring Connections................. 8 I/O Memory Mapping ................11 1769-OA16 Configuration File ............... 12 Spare/Replacement Module Parts ............13 Specifications ..................14 Hazardous Location Considerations ............17 Environnements dangereux .............. -
Page 2: Module Description
Compact™ 16-Point 100 to 240V ac Solid State Output Module Module Description The 1769-OA16 is a 16-point 100 to 240V ac output module. The module has two isolated groups with 8 points per group, thereby allowing you to mix 120 and 240V ac sources. -
Page 3: Module Installation
Compact™ 16-Point 100 to 240V ac Solid State Output Module Module Installation Compact I/O is suitable for use in an industrial environment when installed in accordance with these instructions. Specifically, this equipment is intended for use in clean, dry environments (Pollution degree 2 ) and to circuits not exceeding Over Voltage Category II (IEC 60664-1). -
Page 4: System Assembly
Compact™ 16-Point 100 to 240V ac Solid State Output Module System Assembly The module can be attached to the controller or an adjacent I/O module before or after mounting. For mounting instructions, see "Panel Mounting" on page 5, or "DIN Rail Mounting"... -
Page 5: Mounting Expansion I/O
Compact™ 16-Point 100 to 240V ac Solid State Output Module 7. Attach an end cap terminator (5) to the last module in the system by using the tongue-and-groove slots as before. 8. Lock the end cap bus terminator (6). A 1769-ECR or 1769-ECL right or left end cap must be used to IMPORTANT terminate the end of the serial communication bus. - Page 6 ±0.4 mm (0.016 in.). Locate holes every 17.5 mm (0.689 in.) to allow for a mix of single-wide (e.g. 1769-IQ16) and one-and-a-half-wide modules (e.g. 1769-OA16). Panel Mounting Procedure Using Modules as a Template The following procedure allows you to use the assembled modules as a template for drilling holes in the panel.
-
Page 7: Replacing A Single Module Within A System
Compact™ 16-Point 100 to 240V ac Solid State Output Module DIN Rail Mounting The module can be mounted using the following DIN rails: 35 x 7.5 mm (EN 50 022 - 35 x 7.5) or 35 x 15 mm (EN 50 022 - 35 x 15). Before mounting the module on a DIN rail, close the DIN rail latches. -
Page 8: Field Wiring Connections
Allen-Bradley publication 1770-4.1, for additional information. Output Wiring Basic wiring of output devices to the 1769-OA16 is shown below. Be careful when stripping wires. Wire fragments that fall into a ATTENTION module could cause damage at power up. Once wiring is complete, ensure the module is free of all metal fragments. - Page 9 Compact™ 16-Point 100 to 240V ac Solid State Output Module A removable, write-on label (see page 2, item 9) is provided with the module. Remove the label from the door, mark the identification of each terminal with permanent ink, and slide the label back into the door. Your markings (ID tag) will be visible when the module door is closed.
- Page 10 Compact™ 16-Point 100 to 240V ac Solid State Output Module 2. Route the wire under the terminal pressure plate. You can use the bare wire or a spade lug. The terminals will accept a 6.35 mm (0.25 in.) spade lug. The terminal screws are non-captive.
-
Page 11: I/O Memory Mapping
Compact™ 16-Point 100 to 240V ac Solid State Output Module I/O Memory Mapping Output Data File Data output bits are turned on or off using the bit positions in Word 0. 1 = output on 0 = output off Example: To turn on bit position 12, type 1 in Word 0, Bit 12. For each module, slot x, word 0 in the output data file contains the control program’s directed state of the discrete output points. -
Page 12: 1769-Oa16 Configuration File
Compact™ 16-Point 100 to 240V ac Solid State Output Module 1769-OA16 Configuration File The read/writable configuration data file allows the setup of the hold last state and user-defined safe state conditions. The manipulation of the bits from this file is normally done with programming software (e.g. -
Page 13: Spare/Replacement Module Parts
Compact™ 16-Point 100 to 240V ac Solid State Output Module Fault Value Word Value Bit Setting The fault value word, word 4, is used to program the fault state value (0=Off, 1=On). Each output is individually configurable for on or off. Program to Fault Enable Bit (PFE) Value Applied Bit Setting... -
Page 14: Specifications
Compact™ 16-Point 100 to 240V ac Solid State Output Module Specifications General Specifications Specification Value Dimensions 118 mm (height) x 87 mm (depth) x 52.5 mm (width) height including mounting tabs is 138 mm 4.65 in. (height) x 3.43 in (depth) x 2.07 in (width) height including mounting tabs is 5.43 in. - Page 15 Compact™ 16-Point 100 to 240V ac Solid State Output Module Output Specifications Specification 1769-OA16 Voltage Category 120 to 240V ac Operating Voltage Range 85V ac to 265V ac at 47 to 63 Hz Number of Outputs Bus Current Draw (max.) 225 mA at +5V dc line (1.125W)
- Page 16 Compact™ 16-Point 100 to 240V ac Solid State Output Module Temperature Derating The area within the curve represents the safe operating range for the module under various conditions of user supplied voltages and ambient temperatures. 1769-OA16 Maximum Amperes Per Point vs. Temperature 0.50 0.45 0.40 0.35...
-
Page 17: Hazardous Location Considerations
Compact™ 16-Point 100 to 240V ac Solid State Output Module Hazardous Location Considerations This equipment is suitable for use in Class I, Division 2, Groups A, B, C, D or non-hazardous locations only. The following WARNING statement applies to use in hazardous locations. -
Page 18: For More Information
• download a free electronic version from the internet: www.ab.com/micrologix or www.theautomationbookstore.com • purchase a printed manual by: – contacting your local distributor or Rockwell Automation representative – visiting www.theautomationbookstore.com and placing your order – calling 1.800.963.9548 (USA/Canada) or 001.330.725.1574 (Outside USA/Canada) -
Page 19: Publication 1769-In061A-En-P - December
Compact™ 16-Point 100 to 240V ac Solid State Output Module Publication 1769-IN061A-EN-P - December 2001... - Page 20 Compact, MicroLogix, CompactLogix, RSLogix and RSNetworx are trademarks of Rockwell Automation. DeviceNet is a trademark of Open DeviceNet Vendor Association (ODVA). Publication 1769-IN061A-EN-P - December 2001 PN 40072-118-01 (1) © 2001 Rockwell International Corporation. Printed in Malaysia. ´H'52!¶1{¨...
