Alarm input modes
Alarm output modes
Alarm update rate

Memory

Parameter
EEPROM

Microcontroller

Parameter
Type

Data Logging

Parameter
Standalone power supply
Memory card type
Supplied memory card
Memory card host access
File systems supported
Log file format
Logging rate
Data items logged
Logging start methods
Alarm when input temperature > T1

Alarm when input temperature > T1, reset alarm when input temperature goes below T2

Alarm when input temperature < T1

Alarm when input temperature < T1, reset alarm when input temperature goes above T2

Alarm when input temperature is < T1 or > T2

T1 and T2 may be independently set for each alarm.
Disabled, digital I/O line may be used for normal operation

Enabled, active high output (digital I/O line goes high when alarm conditions met)

Enabled, active low output (digital I/O line goes low when alarm conditions met)

1 second
Table 12. Memory specifications
Specification
1,024 bytes isolated micro reserved for sensor configuration
256 bytes USB micro for external application use
256 bytes USB micro reserved for data logging configuration
Table 13. Microcontroller specifications
Specification
Two high performance 8-bit RISC microcontrollers
Table 14. Data logging specifications
Specification
USB power adapter
2.5 watt USB adapter with interchangeable plugs
(Includes plug for USA)
CompactFlash
512 MB CompactFlash card
USB Mass Storage Device (MSD)
FAT16, FAT32
The device only creates 8.3 file names in the root subdirectory.
binary
Min 1 second between entries, max 2
Timestamp, temperature, or raw reading from selected channels, state of DIO lines, CJC
sensor readings
Configurable:
Start Logging on Power Up – Logging begins 5 seconds after power on to allow

hardware to settle.
Start Logging on Button – Device is idle on power on. Press and hold the button until

the LED turns on to begin logging. The first sample is acquired 1 second after the LED
turns on unless less than 5 seconds have elapsed since power on.
Start Logging at Specified Time – Device is idle until the real-time clock indicates

the time is equal to or greater than the specified time, at which time the LED turns on. The
first sample is acquired 1 second after the LED turns on unless less than 5 seconds have
elapsed since power on.
32
seconds, 1 second granularity
27
Specifications
