Preface This guidebook introduces the procedures to replace a unit in GP-2300 series with a GP-4301T/TW unit. Model in use Recommended Substitution GP-2300T/S GP-4301T GP-2300L GP-4301TW GP-2301T/S/L 2/59...
GP4000 Series Model Number GP4000 series model number partly differs depending on a specification. Before placing an order, please make sure of the model number. GP-4200 series (3.5”) GP-4300 series (5.7”) GP-4400 series (7.5”/7.0”W) GP-4500 series (10.4”) GP-4600 series (12.1”) RS-232C/422/485 RS-485 (isolation) TFT color LCD...
Contents PREFACE GP4000 SERIES MODEL NUMBER CONTENTS CHAPTER 1 SPECIFICATION COMPARISON 1.1 S GP-2300T/S GP-4301T PECIFICATIONS OF 1.2 S GP-2300L GP-4301TW PECIFICATIONS OF 1.3 S GP-2301T/S/L GP-4301TW PECIFICATIONS OF CHAPTER 2 COMPATIBILITY OF HARDWARE 2.1 L OCATIONS OF CONNECTOR 2.2 T...
Page 5
CHAPTER 3 REPLACEMENT PROCEDURE 3.1 W 3.2 P REPARATION 3.3 R GP-2300 ECEIVE SCREEN DATA FROM SERIES 3.4 C ONVERT SCREEN DATA WITH THE ROJECT ONVERTER 3.5 C HANGE THE ISPLAY 3.6 T GP-4301T/TW RANSFER SCREEN DATA TO 3.7 D IFFERENCES OF SOFTWARE 3.7.1 D IFFERENCES AFTER CONVERSION...
Chapter 2 Compatibility of Hardware 2.1 Locations of connector Connector locations on GP-2300 series and GP-4301T/TW are as follows: GP-2300T/S GP-4301T 12/59...
Page 13
Interface names GP-2300T/S GP-4301T Power Input Terminal Block Power Connector Serial Interface (COM1) Serial Interface (COM2) Serial Interface (COM2) Tool Connector Ethernet I/F USB Interface (Type A) USB Interface (Type mini B) SD Card Interface CF Card Interface Expansion Unit Interface...
Page 15
Interface names GP-2300L GP-4301TW Power Input Terminal Block Power Connector Serial Interface (COM1) Serial Interface (COM2) Serial Interface (COM2) Tool Connector Ethernet Interface USB Interface (Type A) USB Interface (Type mini B) CF Card Interface Expansion Unit Interface Printer Interface 15/59...
Page 17
Interface names GP-2301T/S/L GP-4301TW Power Input Terminal Block Power Connector Serial Interface (COM1) Serial Interface (COM2) Tool Connector Ethernet Interface USB Interface (Type A) USB Interface (Type mini B) CF Card Interface Expansion Unit Interface 17/59...
Page 18
2.2 Touch Panel specifications GP-4301T/TW adopts the Analog type. Because of it, simultaneous 2-point touch input operaion is not supported. When simultaneous 2-point touch input operation is performed, GP's operation is as described below. GP-4301T: Only the first detected touch is effective. GP-4301TW: When two different points are pushed at the same time,touch input on the middle coordinates between those two points is recognized.
2.3 Display Colors (for GP-2300L/2301L only) The display color of GP-2300L/2301L is monochrome, but GP-4301T/TW has a TFT color LCD. After replacement, the display color changes from monochrome to color. When data of a monochrome model is converted to data of a color model with GP-Pro EX, the data may be displayed in colors depending on the version of the Project Converter or settings of the drawing/the parts on the screen.
And even though the both COM1 and COM2 ports on GP-2300T/S/L are used with RS-232C setting, only the COM1 port can be used for GP-4301T/TW. In this case, please contact our sales office in your region.
2.6.2 Printer Connection (for GP-2300T/S/L only) GP-4301T/TW is not equipped with Centronics (parallel) Interface for a printer though GP-2300T/S/L is equipped with it. If the printer for GP-2300T/S/L is used for GP-4301T/TW, a converter that converts USB I/F on GP-4301T/TW to Centronics I/F is required.
2.6.3 Expansion Unit GP-4301T/TW is not equipped with an expansion unit interface. The expansion unit (each kind of unit like CC-LINK Unit) for GP-2300 series cannot be used. 2.6.4 Isolation Unit The isolation unit for GP-2300 series (CA2-ISOALL232-01, CA2-ISOALL422-01) cannot be used for GP-4301T/TW. You can use the RS-232C isolation unit for GP-4301T/TW (CA3-ISO232-01) instead.
2.9 Power Consumption The power consumption of GP-2300 series is different from that of GP-4301T/TW. GP-2300 series GP-4301T/TW 22W or less 10.5W or less For the detailed electric specifications, see the hardware manual. 2.10 Materials/Colors of the body The materials and the colors of GP-2300 series and GP-4301T/TW are as follows: Color Material GP-2300 series...
2.11 Backup Memory (SRAM) When replacing GP-2300L with GP-4301TW, SRAM size becomes smaller (256KB -> 128KB). In case that SRAM size of your project file is more than 128KB after converting GP-2300L project file (*.prw) with GP-Pro EX Project Converter, replace GP-2300L with GP-4301T instead of GP-4301TW.
Check the differences of Check the connection hardware in Chapter 2. specifications in OtasukePro! between GP-4301T/TW [Compatibility of Software] and a PLC in the GP-Pro EX (http://www.pro-face.com/o Device/PLC Connection tasuke/qa/gp3000/replace/s Manual. Remove GP-2300 series. oft/conv/care/3/). Receive screen data from GP-2300 series.
・ GPW-CB03 (USB to PC) ・ GP430-CU02-M or GPW-SET (D-sub 25 pin to PC) * Possible to send/receive a screen via Ethernet (for GP-2300T/S/L only) or with a CF card. Requirements for PC in which GP-Pro EX Ver.3.0 or later is installed...
3.3 Receive screen data from GP-2300 series This section explains, as an example, how to receive screen data from GP-2300 series using a transfer cable, GPW-CB02 or GPW-CB03. If you have backed up screen data, this step is unnecessary; skip to the next section [3.4 Convert screen data with the Project Converter].
Page 28
(4) In the Communication Port field, select [COM], specify the COM port to which the cable is connected, and click [OK]. If you use a USB transfer cable (GPW-CB03) You can check the COM port for the USB transfer cable (GPW-CB03), which is assigned to the PC, with the Device Manager of Windows.
Page 29
(5) Select the [Transfer] menu and click [Receive...]. (6) Specify the location to save the received screen data at and the project file name and save them. 29/59...
Page 30
In case there is no Upload Information “Upload Information” is necessary to receive screen data from GP-2300 series. It needs to be included in screen data when transferring screen data to the display unit beforehand. The Upload Information is sent to the display unit by default, however, you may check off the box of Upload Information to prevent screen reception by a third party.
Convert a project file (*.prw) for GP-2300 series with the GP-Pro EX’s Project Converter. (1) Click the [Start] button, select [All Programs] (or [Programs])->[Pro-face]-> [GP-Pro EX *.**]->[Project Converter] (For the [*.**] part, the version of the software you use is displayed.) (2) The Project Converter starts up and the [Project Converter] dialog box opens.
Page 32
(4) In [Convert-To], designate a GP-Pro EX’s project file (*.prx). Click the [Browse…] button and enter a new [File Name] (e.g.: “Product system A.prx”). Click [Save], and a new project file will be set to [Convert-To]. 32/59...
Page 33
NOTE When a convert-to file exists, the window that confirms whether or not to overwrite the file is displayed. 33/59...
Page 34
(5) Click [Convert] and start the conversion. (6) If you are asked about the [Convert-To] type as shown below, select a replacement model’s name on the pull-down menu. Click [OK]. NOTE When replacing GP-2300L with GP-4301TW, select [GP-4301T] on the pull-down menu.
Page 35
If an error message is displayed during conversion, refer to [Project Converter Error Message] (http://www.pro-face.com/otasuke/qa/gp3000/replace/soft/conv/project_con verter_error.html) on our Web site called [OtasukePro!] for the cause and the solution. NOTE If the following dialog box appears, CF Card Ouput Folder setting is required.
Page 36
(7) After conversion, the [Save convert information] dialog box appears. If you click [Save], you can save the conversion information in a CSV file format. NOTE Because the differences made at the time of conversion from GP-Pro/PBIII for Windows are described in the CSV saved file, the project file (*.prx) after conversion can be checked and modified according to the conversion information.
Page 37
When the settings for the both COM1 and COM2 ports are configured for GP-2300T/S/L, the settings for the COM2 port are not converted on GP-Pro EX. If you still need the settings of the COM2 port for GP-2300T/S/L, add Device/PLC setting from [System Settings] on the [Project] menu of GP-Pro EX.
IMPORTANT ・ In the [Question] dialog box, be sure to select [Yes] and specify the destination folder. If you select [No], images will not be called correctly. ・ GP-4301T/TW that is a replacement model is not equipped with a CF card slot. If a destination folder is created in the work above, the CF card setting will be replaced with the SD card setting automatically.
3.6 Transfer screen data to GP-4301T/TW Transfer the project file after conversion to GP-4301T/TW. You can transfer data to GP-4301T/TW via; ・ An USB transfer cable (model: CA3-USBCB-01) ・ An USB data transfer cable (model: ZC9USCBMB1) ・ A commercial USB cable (USB Type A/mini B) ・...
Page 40
・ If the following symptoms appear on Microsoft Windows® 7, go to updating “USB Data Transfer Driver” on [OtasukePro!] for download (http://www.pro-face.com/otasuke/download/freesoft/gpproex_transfer.ht - An error occurs when GP-Pro EX or Transfer Tool is installed - An error occurs when data is transferred via a USB transfer cable (model: CA3-USBCB-01).
Page 41
(2) Turn on the power of GP-4301T/TW. The “Initial Start Mode” screen will appear on the display unit. After transferring a project file once, this screen will not appear again. (3) On the GP-Pro EX’s State Toolbar, click the [Transfer Project] icon to open the Transfer Tool.
Page 42
(4) Make sure that the [Device] in the “Transfer Settings Information” is set to [USB]. If not, click the [Transfer Setting] button to open the “Transfer Setting” dialog box. Select [USB] in the Communication Port Settings field and click [OK]. (5) Click [Send Project] to start transfer.
Page 43
(7) When transfer is completed, the status displayed in the dialog box will change from [Transferring] to [Complete Transfer]. Click [Close] to close the dialog box. The display unit will be reset and a screen of the transferred project file will be displayed.
3.7 Differences of software 3.7.1 Differences after conversion Check the differences of screen data after conversion from GP-PRO/PBIII to GP-Pro EX. For the details of each item, refer to our website, http://www.pro-face.com/otasuke/qa/gp3000/replace/soft/conv/care/3/ Differences of Software Touch Panel Type Compatibility of Bit Switch...
Page 45
Compatibility of Ladder Monitor Compatibility of J Tag and R Tag Converting Screen Data of DOS Compatibility of Standard Font D Script starts right after screen change or power on. (Compatibility of D Script Trigger Condition) The position shifts when loading a window screen (Compatibility of U Tag) Precautions for using Screen Level Change Compatibility of H tag 45/59...
Chapter 4 Communication with Device/PLC 4.1 Drivers More connectable drivers will be added. For the devices/PLC each driver supports, see [Connectable Devices] (http://www.pro-face.com/product/soft/gpproex/driver/driver.html). 4.2 Shapes of COM ports GP-2300T/S/L GP-2301T/S/L GP-4301T/TW D-Sub 25 pin (socket) D-Sub 9 pin (plug) RS-232C/422...
4.3 Signals of COM ports 4.3.1 Signals of COM1 For GP-2300 series RS-232C or RS-422 (socket) 47/59...
Page 48
For GP-4301T/TW RS-232C (plug) *1: RI and VICC of Pin 9 are switched on the software. VCC Output is not protected from overcurrent. Please follow the current rating to avoid false operation or breakdown. 48/59...
For the communication drivers that support serial multi-link, see [Which drivers support serial multilink communication?] (http://www.pro-face.com/otasuke/files/manual/gpproex/new/device/com_mlnk.ht 4.5 Internal 2-Port feature for Mitsubishi PLC For GP-4501TW, the internal 2-Port feature for Mitsubishi PLC cannot be used. If [GP Setup]->[Mode Settings]->[Option]->[Inernal 2 port] is selected on GP-PRO/PBIII, the following message will appear when converting the project file with the GP-Pro EX Project Converter.
IMPORTANT ・ Please check the connection configurations GP-4301T/TW supports with GP-Pro EX Device/PLC Connection Manual before using a connection cable. (http://www.pro-face.com/otasuke/files/manual/gpproex/new/device/index.ht ・ The Siemens MPI connection cable cannot be used. Please refer to the above-mentioned GP-Pro EX Device/PLC Connection Manual and prepare a connection cable for GP-4301T/TW newly.
4.6.1 When using a RS-232C connection cable GP-2300 series System Configuration (connecting to COM1) GP-4301T/TW System Configuration (connecting to COM1) To replace GP-2300 series with GP-4301T/TW, prepare the following item. Product Name Model RS-232C 9-pin/25-pin Conversion Cable (20cm) CA3-CBLCBT232-01 52/59...
Page 53
When using CPU I/F Cable for Mitsubishi PLC… When using CPU I/F Cables for Mitsubishi PLC (GP430-IP10-O/ GP430-IP11-O) with GP-2300 series, be sure to select “VCC” in the Device/PLC Setting on GP-Pro EX after converting a project file, or the communication will not work properly. To change this setting, select [System Settings] ->...
Page 54
* For GP-2300T/S/L only: GP-2300T/S/L System Configuration (connecting to COM2) GP-4301T/TW System Configuration (connecting to COM1) *The same cable can be used. 54/59...
Before connecting to GP-4301T/TW, be sure to change the port setting to [COM2] on Device/PLC Setting of GP-Pro EX. Please check the communication setting with GP-Pro EX Device/PLC Connection Manual just in case. (http://www.pro-face.com/otasuke/files/manual/gpproex/new/device/index.ht To replace GP-2300 series with GP-4301T/TW, prepare the following item. Product Name...
Page 56
NOTE When using a terminal block adapter (GP070-CN10-O), we recommend you to replace it with a terminal block conversion adapter (PFXZCBADTM1) for GP-4301T/TW. For replacement in this connection method, prepare the following item. Product Name Model Terminal Block Conversion Adapter PFXZCBADTM1 56/59...
Chapter 5 Appendix 5.1 Changing the setting of the external media to use If a CF card has been used for GP-PRO/PBIII, after GP-2300 series is replaced with GP-4301T/TW with GP-Pro EX, “a CF card” is automatically replaced with “a SD card” for the external media setting.
Page 58
[Solution] 1. Change the SD Card setting to the USB storage setting following the steps below. <Procedure> i. Click [Project]->[Information]->[Destination Folder]. ii. Uncheck “Enable SD Card” and check “Enable USB Storage. iii. Click the [Browse] button and specify a destination folder. iv.
Page 59
NOTE ・ To see how the tags or the parts of GP-PRO/PBIII for Windows are replaced on GP-Pro EX, refer to [OtasukePro!] (http://www.pro-face.com/) “Feature Comparison between GP-PRO/PBIII and GP-Pro EX” (http://www.pro-face.com/otasuke/qa/gp3000/replace/soft/conv/care/3/co mpare.htm) ・ To check each function setting of GP-Pro EX, refer to GP-Pro EX Reference Manual.
