When Designing your LogiTouch System:
- Be sure to design your LogiTouch control system so that in the event of a main
power supply failure or a LogiTouch accident, this system's overall safety integ-
rity will be maintained. If this is not done, incorrect output signals or a LogiTouch
malfunction may cause an accident.
(1) Interlock circuits, etc. designed to interrupt or oppose normal machine move-
ment (i.e. Emergency Stop, General Protection, forward and reverse rotation,
etc.), as well as those designed to prevent machine damage (i.e. for upper,
lower and traverse movement limit positioning, etc.) should all be designed to
be located outside of the LogiTouch.
(2) Whenever the LogiTouch generates a "Watchdog Timer Error", LogiTouch
operation will halt. Also, when an error occurs in Input/Output control areas
that the LogiTouch cannot detect, it is possible for unexpected equipment
operation to occur there. As a result, to prevent unsafe or unexpected equip-
ment operation, a "Failsafe Circuit" should be created which is completely
external to the LogiTouch.
(3) If an external unit's relay or transistor malfunctions, causing an output (coil)
to remain either ON or OFF, a major accident can occur. To prevent this, be
sure to set up external watchdog circuits that will monitor vital output signals.
- Be sure to design a circuit that will supply power to the LogiTouch's I/O unit(s)
before starting up the LogiTouch. If the LogiTouch's internal program enters
RUN mode prior to the I/O unit's load control power turning ON, an incorrect
output (signal) or malfunction could cause an accident to occur.
- Be sure to design a program that will ensure the safety of your system in, in the
event of a LogiTouch display or control unit malfunction, or in the event of either
a data transmission error or power failure between the LogiTouch and any con-
nected unit(s). These types of problems can lead to an incorrect output (signal) or
malfunction, which could thereby cause an accident to occur.
- Do not create touch panel switches which could possibly endanger the safety of
humans or equipment. This is due to the possibility of a malfunction in the
LogiTouch or its cable(s), causing the output of a signal that could result in a
major accident. All of a system's major, safety-related switches should be desig-
nated to be operated separately from the LogiTouch.
- Be sure to design your system so that equipment will not malfunction due to a
communication fault between the LogiTouch and its host controller. This is to
prevent any possibility of bodily injury or material damage.
- Do not use the LogiTouch with aircraft control devices or medical life support
equipment, central trunk data transmission (communication) devices, nuclear
power control devices, or medical life support equipment, due to these devices
inherent requirements of extremely high levels of safety and reliability.
- When using the LogiTouch with transportation vehicles (trains, cars and ships),
disaster and crime prevention devices, various types of safety equipment, non-
life support related medical devices, etc. be sure to use redundant and/or failsafe
system designs ensure the proper degree of reliability and safety.
DANGERS
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LogiTouch GLC150-BG41-RSFL-24V and is the answer not in the manual?

Questions and answers

Summary of Contents for Pro-face LogiTouch GLC150-BG41-RSFL-24V

  • Page 1 DANGERS When Designing your LogiTouch System: - Be sure to design your LogiTouch control system so that in the event of a main power supply failure or a LogiTouch accident, this system’s overall safety integ- rity will be maintained. If this is not done, incorrect output signals or a LogiTouch malfunction may cause an accident.
  • Page 2 2) Or, if your LogiTouch is set to Standby Mode, but touching the screen does not cause the display to reappear, your backlight is burned out. Also, to prevent an accidental machine operation error, Pro-face suggests you use the LogiTouch’s built-in “USE TOUCH PANEL AFTER BACKLIGHT BURN- OUT”...
  • Page 3 CAUTIONS Wiring Layout: - Be sure that all LogiTouch input/output signal lines are isolated from all power wiring or power cables, via a separate wiring duct. This is to prevent excessive noise, which can cause a unit malfunction. Installation: - Be sure all data cables attached to the LogiTouch are securely connected. If all connector pins do not make complete contact, incorrect input or output signals can result.
  • Page 4: Ul/C-Ul(Csa) Application Notes

    UL/c-UL(CSA) Application Notes The GLC150-BG41-RSFL-24V is a UL/c-UL listed product. (UL file No. E214883) This unit conforms as a component to the following standards: UL508 Industrial Control Equipment UL1604 Electrical Equipment for Use in Class I and II Division 2 and Class III Hazardous (Clas- sified) Locations CAN/CSA-C22.2, Nos.1010 Standard for Safety of Information Technology Equipment, including Electrical Busi-...
  • Page 5: Package Contents

    Package Contents The following items are included in the LogiTouch's package. Before using the LogiTouch, please confirm that all items shown here are present. Installation Guide (1) LogiTouch Type-C (1) (GLC150-BG41-RSFL-24V) <This Guide> Installation Fasteners (4) This unit has been carefully packed, with special attention to quality. However, should you find any of the items shown here to be damaged or missing, please contact your local LogiTouch distributor immediately.
  • Page 6 C : Status LED : Operation Controller LED Color Mode Operation Mode OFFLINE STOP Green - Constant In Operation Green - Constant In Operation STOP Green - Flashing Backlight burnout Green / Red In Operation has occurred - Constant In Operation Major Error Red - Constant *1 Operation mode includes Display and touch key...
  • Page 7: General Specifications

    This relay switch remains OFF until the LT unit’s system software completes its startup routine. During this startup period, this external circuit must be informed that the LT is not yet operational. Be sure to design a hold timer circuit that will start operations after the startup routine is completed, or create an alarm monitoring sys- tem that will monitor the LT unit’s circuits.
  • Page 8 Interfaces Serial Interface RS-232C and RS-422 serial interface. Used to connect with a host (PLC). Pin Arrangement Pin No. Signal Condition Frame Ground Send Data (RS-232C) Receive Data (RS-232C) Request Send (RS-232C) Clear Send (RS-232C) No Connection Signal Ground Carrier Detect (RS-232C) TRMX Termination (RS-422) Receive Data A (RS-422)
  • Page 9: Installation

    Flex Network Interface Connect a Flex Network unit to this interface. Pin Arrangement Pin No. Signal CH2 Shielded Line (SLD) CH2 Communication Data (TR - ) CH2 Communication Data (TR + ) CH1Shielded Line (SLD) CH1 Communication Data (TR - ) CH1 Communication Data (TR + ) Recommended Connector : MC1, 5/6-STF-3,81 (Made by Phoenix Contact) FN-IFCN01 (Maintenance Option / Digital Electron-...
  • Page 10 Create a Panel Cut and insert the LogiTouch into the panel from the front Unit:mm [in.] +0.04 191.5 [7.54 under 4-R3 1.6 to 5.0 –0 [0.06 to 0.2] Attach the Installation Fasteners from Inside the Panel The following figures show the four (4) fastener insertion slot locations. Insert each fastener’s hook into the slot and pull it back until the hook catches.
  • Page 11 Wiring WARNINGS • To prevent an electric shock, prior to connecting the LogiTouch’s power cord terminals to the power terminal block, be sure that the LogiTouch’s power supply is turned OFF, via a breaker, or similar unit. • The GLC150-BG41-RSFL-24V unit is designed to use only DC24V input.
  • Page 12: Power Supply Cautions

    Power Supply Cautions Please pay special attention to the following instructions when connecting the power cord terminals to the LogiTouch unit. • If the power supply voltage exceeds the LogiTouch's specified range, connect a voltage transformer. • Between the line and the ground, be sure to use a low noise power supply. If there is still an excessive amount of noise, connect a noise reducing transformer.
