Changing the high end point value has the following visual effect on the driving screen bars.
The position of the pointer on the bar is affected by end point settings (low and high) and trim setting;
increasing the high end point value may visually appear to have the same effect as decreasing the low
end point value.
An end point setting of 100 (the default) is typical for most servos, and should always be used for
ESCs. Larger setting values will overdrive most servos

Adjusting the High End Point

The high end point value is a relative value, and is expressed as the percentage of full travel to the
HIGH end.
Use the navigation controls to adjust the high end point as follows:
1. Access the top function menu from
the driving screen.
2. Navigate to the Channel 3 or
Channel 4 menu.
3. Navigate to High End Point.
4. Change the value.
Trim and EPA Interaction
A trim (or sub-trim) setting of 100 is equivalent to an End point setting of 50.
High end point value is approximately the same as
the low end point value.
Increased high end point value (more servo travel
on HIGH end is possible).
Decreased high end point value (less servo travel
on HIGH end is possible).
or
or
Value Description
0 Minimum high end point; allows NO travel to high end.
or
High end point value is set to a percentage of travel
1-199
range to high end.
200 Maximum high end point (will overdrive most servos)
