Changing the throttle end point value has the following visual effect on the driving screen bars.
The position of the pointer on the bar is affected by end point values (throttle and brake) and trim
setting; increasing the throttle end point value may visually appear to have the same effect as
decreasing the brake end point value.
An end point setting of 100 (the default) is typical for most servos, and should always be used for
ESCs. Larger setting values will overdrive most servos

Adjusting the Throttle End Point

The throttle end point value is a relative value, and is expressed as the percentage of full travel to the
THROTTLE end.
Use the navigation controls to adjust the throttle end point as follows:
1. Access the top function menu from the
driving screen.
2. Navigate to the Throttle (Ch2) menu.
3. Navigate to Throttle End Point.
4. Change the value.

Trim and EPA Interaction

A trim (or sub-trim) setting of 100 is equivalent to an End point setting of 50.
Throttle end point value is approximately the
same as the brake end point value.
Increased throttle end point value (more servo
travel for THROTTLE is possible).
Decreased throttle end point value (less servo
travel for THROTTLE is possible).
or
or
Value
0
or
1-199
200
then
Description
Minimum throttle end point; allows NO throttle.
Throttle end point value is set to a percentage of full
throttle travel.
Maximum throttle end point (will overdrive most
servos)
