Channel 3 / 4 Servo Dual Rate

Changing the dual rate setting has the following visual effect on the driving screen bars:

Adjusting Channel 3 /4 Servo Dual Rate

Use the navigation controls to adjust servo dual rate as follows:
1. Access the top function menu
from the driving screen.
2. Navigate to the Channel 3 or
Channel 4 menu.
3. Navigate to Dual Rate.
4. Change the value.
Channel 3 and Channel 4 servo
dual rates adjust the range of
servo movement when the grip
buttons are activated. The servo
dual rate value is applied to both
low and high ends, and is
expressed as a percentage of
servo range (configured by end
point adjustments).
On the driving screen, servo dual
rate range is represented by the
solid length of the bottom bar.
The total length of the bar (solid
and dotted) represents the servo
range. The length of the solid bar
represents the servo range as set
by the dual rate value.
Full servo range is used.
Lower dual rate value reduces servo range.
or
or
Value
0
or
1-99
100
Ch3 / Ch4 Dual Rate Ranges
then
Description
Servo range is set to minimum (0%).
Servo range is set to a percentage of full range.
For example, value "50" gives 50% of full servo range.
Servo range is set to full (100%)
