Generac Power Systems rtsy100a3 Owner's Manual page 51

EXPLODED VIEW: ASSEMBLY 150A SERVICE ENTR GEN
DRAWING #: 0K0165A
ITEM PART#
1 0D9618
2 074908
3 0K0971
4 0K0973
5 0H6306
6 0G4413
7 024334
8 0K0130
9 049897
10 022129
11 0E3375
12 0F1252
(3)13 0E6033
14 0E6034
15 0J8202
16 0K1081
17 0K0108A
18 090388
19 0K01170AL0R
20 0K01180AL0R
21 0K0119
22 0K01310AL0R
23 0K0132
(1)24 0K1736B
25 0E3484
26 0G9651A
27 0G9651B
28 0G9651C
29 0G8535
30 0K1018
31 0D3587
32 0H7917
33 0K1738
34 0G3274
35 0G3259
36 0K1098
(1)37 0H6389
38 0H7274
39 0A1495
40 026850
41 0E7213
42 085889
43 0G8411
44 022473
45 022097
46 0E6193
47 0D6162
(3)48 0E6155
49 0K0103
(2)50 0D2572
(2)51 073590A
(2)52 0D7393T
53 0K0124
54 0F2659
55 0H7190
56 0H7270
57 0K0220A
58 064761
59 0K0123
60 0E6303
61 0E6303B
(1) SERIAL NUMBER AND FRONT DECAL PER MODEL
(2) SUPPLIED WITH HARNESS ITEM #59
(3) SUPPLIED WITH TRANSFER SWITCH
REVISION: -A-
DATE: 12/6/12
QTY. DESCRIPTION
1 XFRSW HSB 200A 2P 250V
5 SCREW HHTT M5-0.8 X 10 BP
1 CB 150A 2POLE 240V 225AF
2 SCREW RHM #8-32 X 2-1/2
2 LUG SLDLSS 350 MCM-6 AL/CU
2 SPACER,200 AMP TRANSFER SWITCH
2 BOLT CARR 1/4-20 X 1
2 BUSBAR 200A TRANSFER SW N1,N2
4 SCREW SHC M8-1.25 X 20 G8
4 WASHER LOCK M8-5/16
4 LUG SLDLSS 250-#6 AL/CU
4 SCREW BHSC 1/4-20 X 3/8
4 90 DEGREE DN SPADE CONNECTOR
1 STRAIGHT SPADE CONNECTOR
1 LUG SLDLSS 2/0-#14X#10-32X.125
1 WIRE NEUTRAL/GND CONNECTION
1 ASSY-NEUT BLK 200A W/TAP
2 SCREW HHTT M6-1.0 X 12 ZINC
1 ENCLOSURE 200A SE XFRSW RAW
1 COVER,200A SE XFRSW RAW
1 SUBPLATE,200A SE XFER SW
1 COVER INSIDE 200A SE XFER SW RAW
1 CB RISER BRACKET 200A GENERAC
1 DECAL,XFER SW SE 150A 120/240
1 DECAL WARN MANUAL OPER HANDLE
1 DECALS, SERVICE ENTRANCE
1 DECALS, SERVICE ENTRANCE
1 DECALS, SERVICE ENTRANCE
1 DECAL TRANSFER SWITCH ID 200A
1 DECAL, NEUTRAL CONNECTION
1 DECAL, FUSE REPLACEMENT
1 DECAL CUSTOMER CONN RTS
1 DECAL TEST SEQUENCE 100-200A SE
1 DECAL LIVE CIRCUIT ENG/FRN/SPN
1 DECAL TERMINAL SHOCK HZD BI
1 DECAL RTS TRANSFER SW GENERAC
1 DECAL UTILITY LOAD SENSE 240V
1 DECAL 2008 NEC COMPLIANCE
8 SCREW HHTT M4-0.7 X 10 BP
2 WASHER LOCK EXT 1/4 STL
1 SCREW THUMB 1/4-20 X1/2 W/SHLD
1 NUT HEX 1/4-20 SS
8 NUT HEX FL WHIZ 1/4-20
4 WASHER FLAT 1/4-M6 ZINC
4 WASHER LOCK M6-1/4
1 BRACKET, ARM EXTENDER
2 RIVET POP .156 X .362 AL
1 PIN ARM EXTENDER
1 RELAY PNL 12VDC DPDT 10A@240VA
1 FUSEBLOCK 30A 600V 3POS W/SQ
3 FUSE 5A X BUSS
1 TERM BLOCK 3P UL 12-20AWG
2 SCREW PHTT M3-0.5 X 25
2 SCREW HHTT M3-0.5 X 6 BP
1 BRACKET LOAD SHED 200A RTS
1 CHANNEL SNAPTRACK 76.2 X 101.2
1 ASSY LOAD MANAGEMENT CONTROLLER PROGRAMMED
4 TIE WRAP UL 5.6 X .10 NATL (NOT SHOWN)
1 HARN 200A XFER SW SE 2010 (NOT SHOWN)
2 WIRE A 7.0" BLUE
1 WIRE E1 3.0" BLUE
GROUP
Page 2 of 2
