Measuring system

4
The measuring system consists of a transmitter and a sensor. Two versions are available:
• Compact version: transmitter and sensor form a mechanical unit.
• Remote version: transmitter and sensor are mounted physically separate from one another.
Transmitter
Promass 80
Esc
-
+ E
a0003671
Promass 83
Esc
- +
E
a0003672
Sensor
E
a0002271
Other sensors can be found in the separate documentation
F
a0003673
F (High-temperature)
a0003675
M
a0003676
• Two-line liquid-crystal display
• Operation with push buttons
• Four-line liquid-crystal display
• Operation with "Touch control"
• Application-specific Quick Setup
• Mass flow, volume flow, density and temperature measurement as well as
calculated variables (e.g. fluid concentrations)
• General purpose sensor, ideal replacement for volumetric
flowmeters.
• Nominal diameters DN 8 to 50
• Material: Stainless Steel EN 1.4539/ASTM 904L,
EN 1.4404/ASTM 316L
• Universal sensor for fluid temperatures up to 200 °C.
• Nominal diameters DN 8 to 250
• Material: Stainless Steel EN 1.4539/ASTM 904L,
EN 1.4404/ASTM 316L, Alloy C-22 DIN 2.4602
• Universal high-temperature sensor for fluid temperatures
up to 350 °C.
• Nominal diameters DN 25, 50, 80
• Material: Alloy C-22, DIN 2.4602,
EN 1.4404/ASTM 316L
• Robust sensor for extreme process pressures, high
requirements for the secondary containment and fluid
temperatures up to 150 °C
• Nominal diameters DN 8 to 80
• Material: Titanium, Ti Grade 2, Ti Grade 9
Proline Promass 80E, 83E
Documentation No.
TI 061D/06/en
Documentation No.
TI 053D/06/en
