PANEL DESCRIPTION

LED indicator

The LED indicator indicates the status of various
parameters of the transceiver as follows:
(Reference: R=Red, G=Green, O=Orange)
• Transmitting
R R R R R R R R
• Receiving
G G G G G G G G
The following LED indicator patterns are repetitive.
One cycle is approximately two seconds.
• Cloning (reading or writing data)
G G G G
• Cloning Error (if cloning fails)
R G R G R G R G R G R G R G R G
• Inh, Blank CH, Unlocked
(when you cannot use the channel)
R O R O R O R O R O R O R O R O
• TX Low Battery 2 (while transmitting)
R R R R R R
• TX Low Battery 1 (while transmitting)
R R R R R R R R R R R R R
• Call LED=ON
(when receiving a matching 2-Tone or 5-Tone)
O O
• Call LED=Blink
(when receiving a matching 2-Tone or 5-Tone)
O O
• Scanning
G
• Low Battery 2 (You must charge the battery.)
G G
• Low Battery 1 (You should charge the battery.)
• Calling
O O O
• Audible
O
R R R R R R R R
G G G G G G G G
G G G G
R R R R R R
R
G
G G
G G
O O O
O
The following LED indicator patterns light only once.
• When turning ON the power
R O G R O G
• Lockout, TX Inh, TOT
(when transmit is inhibited)
R R R O
• Successful
O O O O G
• Failed, Error
O O O O R
• Emergency, Siren
G O R G
1-3
O O
G G G
R R R
O R G O R G O R
