USER SETTINGS

Setting the VOX gain

Adjust the VOX gain.

Higher values make the VOX function more sensitive

to the user voice.

NOTE:

You should turn ON the Beep function (p. 5-2)

before you start setting the VOX gain.

Rotate [VOL] to turn OFF the transceiver power.

Set [ROTARY SELECTOR] to Channel 16.

While holding down [PTT] and [Upper], rotate

[VOL] to turn ON the power and enter the VOX gain

adjustment mode.

Push [Upper] to increase, or push [Lower] to

decrease the microphone gain.

• T he adjustable range is 1 (minimum) to 10 (maximum).

• A beep sounds after pushing [Upper] or [Lower]. An

error beep sounds if you try to exceed the adjustable

range.

Rotate [VOL] to turn OFF the power to exit the VOX

gain adjustment mode.

[ROTARY SELECTOR]

[PTT]

[Upper]

[Lower]

5-8

[VOL]
