Develop ineo+ 224 Product Manual page 15

Product Guide ineo
JOB SEPARATOR JS-602
Dimensions (WxDxH) (mm) 341 x 537 x 149
INNER JOB SEPARATOR JS-506
Dimensions (WxDxH) (mm) 491.9 x 469.5 x 226.5
POST INSERTER PI-505
Dimensions (WxDxH) (mm) 511 x 635 x 220
+
224/284/364/454/554
Function Additional 3
Paper Weight 60 - 90 g/m²
Paper Size A5 - A3W (311 x 457 mm)
Stacking Capacity Max. 100 sheets (60 - 90 g/m²)
Weight (kg) 1.75
Remark Cannot be used together with PI-505
Paper Size Tray 1/2: A6 to SRA3, Banner and Long Length Tray 2 only
Paper Weight Tray 1/2: 52 - 300 g/m²
Tray 1: 150 sheets (90 g/m²)
Capacity
Tray 2: 50 sheets (90 g/m²)
Weight (kg) 1.5
Function Pre-printed page insertion, manual stapling, half fold and punching
Upper Tray: A5 lengthwise up to A4 (B5)
Paper Size
Lower Tray: A5 lengthwise up to A3+ (311 x 457 mm)
Paper Weight 60 - 209 g/m²
Capacity Max. stack capacity 200 sheets 80 g/ m²
Weight (kg) 10,5
Remark Cannot be used together with JS-602
rd
bin for FS-535
15
Option for FS-535
Option
Option for FS-535
