Toshiba TOSVERT VF-FS1 Instruction Manual page 26

Note3) The maximum output voltage is equal to the input supply voltage.
Note4) ±10% when the inverter is operated continuously (under a load of 100%).
Note5) IP54-compliant structures refer to structures that protect the contents from dust and harmful effects of water that
drops from every direction.
Use PG screw type cable grounds among cable grounds available are skin-top grounds manufactured by LAPP
(Germany).
When using this type of grounds, use them in combination with lock nuts specified below.
Cable port
Φ16.5 hole
Φ20.5 hole
Φ25.5 hole
Φ32.5 hole
Φ40.5 hole
Φ50.5 hole
Φ63.5 hole
Note6) For control specifications, parameters and functions, refer to the instruction manual E6581381.
Note7) The inverter has a built-in cooling fan. The cooling fan has a useful life of approximately 30,000 hours (2 to 3 years
when operated continuously), so it needs to be replaced periodically.
If the cooling fan does not operate normally, the temperatures of the internal electrical components will rise high,
and as a result their lives will be shortened. So inspect it periodically.
Cable ground Cable ground(EMC-compliant)
MS-M16X1.5
MS-M20X1.5
MS-M25X1.5
MS-M32X1.5
MS-M40X1.5
MS-M50X1.5
MS-M60X1.5
MS-SC-M16X1.5
MS-SC-M20X1.5
MS-SC-M25X1.5
MS-SC-M32X1.5
MS-SC-M40X1.5
MS-SC-M50X1.5
MS-SC-M60X1.5
26
Ｅ６５８１４７１
Lock nut
SM-M16X1.5
SM-M20X1.5
SM-M25X1.5
SM-M32X1.5
SM-M40X1.5
SM-M50X1.5
SM-M60X1.5
