Worksman ADP-CB Owner's Manual page 2

Rear Axle and Related Parts
Part # Description
101 Hub for Free Wheel w/ Cups
103 Cups for 101 Hub
106 Stationary Cone (presses onto axle)
113 Locknut - Left Hand Thread - Free Wheel Side
130 Axle Parts Set (102,105,109,113,146,59A,93D) 58A
3980 Drive Wheel Hub
59A Locknut - Drive Side
4129 Freewheel Sprocket (22 tooth)
63B Set screw for 69 and 4129
91 Pillow Block Bearings (each)
93 Spacer Washer for Left Side Wheel
301 1 Speed Coaster Brake Hub
302 Coaster Brake Conversion Kit (for freewheel)
405 3 Speed Conversion Kit (for freewheel)
Crank Parts (Pedal Section) and Chains
Part # Description
1265 Crank Parts
1266 Crank Bearings (pair)
1267D Complete Crank Set
1267F Complete Crank Set
1271 Key Washer (outside)
1273 Stationary Cone (inside)
1275 Crank (one piece, forged, 6½ , plated)
1380D Sprocket 36 Tooth (3/16 , Chrome)
1380F Sprocket 32 Tooth (3/16 , Chrome)
1380H Sprocket 28 Tooth (3/16 , Chrome)
4910A Chainguard (Chrome plated - optional)
7217 Pedal Set
7217-EXT Pedal Extenders (mounts pedals further apart)
4914B Chain (freewheel models)
4914EE Chain (short for coaster brake)
4915 Chain Adjusters (for coaster brake)
Note - The Adaptable comes standard with a 36 tooth front sprocket and 1265 crank part set. Smaller sprockets in the front will reduce
the gear ratio, making it easier to start pedaling. The 1265BMXS is a sealed, heavier duty upgrade for crank parts.
Seats, Seatpost, Baskets, Cabinets, and Fenders
Part # Description
6910V Saddle (wide w/o springs - standard)
4908C Seatpost (12 x 7/8 )
4909 Bolt, Nut, Washer for 4911C
3927 Rear Cabinet (22 x15 x16 )
7227-P Rear Flat Steel Basket (24 x17 x12 )
7228 Front Wire Basket (21 x15 x9 )
82 Front Fender (Chrome)
82P-BLK Front Fender (Black Polycarbonate)
83A Front Fender U-Brace
82K Front Fender Hardware Kit (95, 4907, 4907A)
4907 Bolts, Nut, Washer (U-brace to fender)
4902 Rear Fender (Fits 24 & 26 - Chrome)
4902P-BLK Rear Fender (Fits 24 & 26
84 Rear Fender Brace Set (26 , one side)
84A Rear Fender Brace Set (24 , one side)
4902K Rear Fender Hardware (6-4905, 6-4906)
4906 Bolt, Nut, Washer (rear fender brace to 92)
* Complete rear fender kits include 2 rear fenders, 6 braces, and all nuts and bolts. Bracket # 92 is not included.
(1266/1268/1269/1271/1272/1273/1274)
(36T blk sprocket, crank, 1265)
(32T blk sprocket, crank, 1265)
Black)
Part # Description
102 Key Lock Washer
105 Adjusting Cone (threaded)
109 Dust Washer
146 Wheel Bearings (pair)
Rear Axle (31 ½ )
58 Rear Axle (34 - Pre 1965)
69 Fixed Drive Sprocket
63AD Bushing for 4129 (freewheel models)
62C Keyway for Rear Sprocket
91A Bolt, Nut, Washer for 91 Bearing
93D Washer - Drive Side Spacer
404N 3 Speed Coaster Brake Hub
SS13N-1 3 Speed Cable and Trigger for 404N
SS721 Coaster Brake Internal Part Kit (for 301)
Part # Description
1265BMXS Deluxe Sealed Crank Set (Upgrade)
1268 Cups for Crank Housing (pair)
1269 Stationary Washer (inside)
1267H Complete Crank Set
1272 Adjusting Cone (threaded, outside)
1274 Crank Locknut
1275-EDB Crank (one piece, forged, 6½ , black)
1380D-EDB Sprocket 36 Tooth (3/16 , Black)
1380F-EDB Sprocket 32 Tooth (3/16 , Black)
1380H-EDB Sprocket 28 Tooth (3/16 , Black)
4910P-BLK Chainguard (Black plastic - standard)
7217-41557 Pedal Set - Alloy Platform (Optional)
4914A Chain Connecting Link (1/2 x3/16 )
4914C Chain (long for 32T and coaster brake)
4914F Chain (long for 36T and coaster brake)
(Black resin polycarbonate fenders became standard starting in 2013.)
Part # Description
6911V Saddle (wide w/ springs - optional)
7913A Seatpost Clamp (seatpost to seat)
4911C Seatpost Clamp (seatpost to frame)
5927 Rear Wire Basket (21 x15 x9 )
133WH Removable Front Basket (14.5 x9.5 x9 )
139 Front Wire Basket (18 x13 x6 )
82-C Front Fender w/ all parts attached (Chr)
82P-BLK-C Front fender w/ all parts attached (Blk)
95 Front L Bracket (fender to fork)
4907A Bolt, Nut, Washer ( L bracket to fork)
AD26* Complete Rear Fender Kit (26 Chrome)
AD24* Complete Rear Fender Kit (24 Chrome)
AD26P-BLK* Complete Rear Fender Kit (26 Black)
AD24P-BLK* Complete Rear Fender Kit (24 Black)
4905 Bolt, Nut, Washer (rear fender to brace)
92 Rear Fender Brace Bracket (on frame)
(28T blk sprkt, crank, 1265)
