Worksman SBST 1215 Instructions And Parts List

W
ORKSMAN
Worksman Trading Corp - 94-15 100
www.worksmancycles.com
the rules of safe riding. Always keep your Worksman Tricycle in tip-top shape by replacing worn
parts as needed with Genuine Worksman Cycles Parts. (Do not use generic bicycle parts.) With
simple maintenance, your Worksman will perform reliably day after day, year after year.
Your Team Dual Tricycle has been hand-made in the USA by our American craftspeople with
American and foreign components.
satisfaction is our goal. Completion of this cycle and final adjustments should be performed by
a qualified bicycle mechanic. Failure to do so could result in injury or death.
Worksman SBST Parts List

Frame, Fork and Related Parts

Part # Description
72SBCB Frame Only- Specify color
5020HD Fork (Black) w/ Brake Insert Tab
48 Head Set Cups (pair)
50A Headset Complete (48,49,52,53,54)
52 Top Adjusting Cone (threaded)
54 Fork Top Lock nut
55U Stem for Handlebar

Front Drum Brake Parts

Part # Description
L500-F Front Drum Brake Hub (Hub only)
L725-1 Drum Brake Plate Kit w/ Brake Pads
F852R Brake Lever w/ Parking Lock
F769 Anchor Bolt Assembly for F719-SBST Cable

Rear Axle and Related Parts

Part # Description
64M Woodruff Key
58SBS Rear Axle (EACH - Left or right are same)
62C Key
(Fits in axle slot between 69 sprocket & axle)
M13975 Side/Center Bearing with Plate (each)
404SBST 3 Speed Coaster Brake w/Dual Sprockets
4915E Chain adjuster (3 speed)
SS12N-3 3 Speed Cable and Trigger for 404SBST
Worksman Trading Corp - 94-15 100
S S T
IDE BY IDE EAM
th
Street - Ozone Park, NY 11416 - (888) 3-WHEELER or 718 322 2000
Worksman Side by Side Team Dual Trike
Congratulations! You have purchased an American Made
Worksman Team Dual Tricycle . This is one of the most
unique adult tricycles in the world. It combines comfort with
durability, a truly unique combination. We utilize the
components and technology used on our world famous
Worksman Industrial Cycles to insure your satisfaction.
Before assembly and riding, make certain to read this manual
and any other literature provided thoroughly. Always follow
Our reputation rides along with you, so your ultimate
(See wheel section for complete front drum brake wheels.)
th
Street - Ozone Park, NY 11416 - (888) 3-WHEELER or 718 322 2000
www.worksmancycles.com
D T I
UAL RIKE NSTRUCTIONS AND
Part #
3928S
5020HD-SP
49
51
53
55SBS
55Y
Part #
L509
L517
F719-SBST
F770
Part #
59M
69
63B
301M
SS721
4915E-55mm
P
ARTS
Parts list SBST-1215
Description
Basket frame support
Fork (other color- please specify)
Headset Bearings (pair)
Bottom Cone (presses on Fork)
Key Washer
Tiller Handlebar
Foam Handlebar Grips (set)
Description
Axle (for pressed bearing)
Pressed Bearing (each)
Drum Brake Cable and Casing (55 )
Adjusting Barrel for F719-SBST Cable
Description
Axle Locknut
Fixed Drive Sprocket w/ Key & Set
Set screw for 69
1 spd Coaster Brake w/Dual Sprockets
Internal Parts Kit for 301M
Chain Adjuster (1 speed)
Email: cycles@worksman.com
L
IST
