Worksman Eagle Lite Owner's Manual

Tricycle

Advertisement

Quick Links

Worksman Trading Corporation – 94-15 100
www.worksmancycles.com
Models EAG-FW, EAG-2F, EAG-CB, EAG-3CB
Worksman Eagle Lite Tricycle - The Finest Adult Tricycle in the World!
FAILURE TO HAVE A QUALIFIED BICYCLE MECHANIC ASSEMBLE THIS CYCLE COULD RESULT IN SERIOUS INJURY OR DEATH.
Worksman Eagle Lite Parts List
Frame, Fork and Related Parts
Part #
Description
3950
Eagle Lite Frame (specify color)
3950A
Eagle Lite Rear w/ Axle (freewheel, Silver)
48
Headset Cups (pair)
50A
Headset Complete (48,49,52,53,54)
52
Top Adjusting Cone (threaded)
54
Fork Top Lock nut
55A
Stem
5031
Front Reflector Bracket
L752R
Brake Lever (Right) w/ Parking Lock
G219A
Brake Cable (caliper brake)
Front Drum Brake Parts
Part #
Description
G250
Drum Brake Hub
G815
Drum Brake Outside Axle Nut (each)
G269
Anchor Bolt Assembly for G219 Cable
Rear Axle and Related Parts
Part #
Description
57
Rear Axle Elastic Locknut
176
Rear Axle (29 ½" w/ drive plate)
4129A
Freewheel Sprocket (18 tooth)
62B
Keyway for Rear Sprocket
301
1 Speed Coaster Brake Hub
SS13N-1
3 Speed Cable and Trigger for 404N
Crank Parts (Pedal Section) and Chains
Part #
Description
1265
Crank Parts
1266
Crank Bearings (pair)
1268
Cups for Crank Housing (pair)
1271
Key Washer (outside)
1273
Stationary Cone (inside)
3275
Crank (one piece, forged - 5.5")
7217
Pedal Set (pair)
4914M
Chain Connecting Link (1/2"x1/8")
4914Y
Chain (freewheel models 1/8"x121 links)
4914G
Chain (coaster brake 1/8"x41 links)
4916
Chain Idler Sprocket
Worksman Eagle Lite Tricycle Owner's Manual
Congratulations! You have purchased an American-made Worksman Eagle Lite Tricycle. Before
assembling and riding, make certain to read this manual thoroughly. Always follow the rules of
safe riding. Always keep your Eagle Lite tricycle in tip-top shape by replacing worn parts as
needed with genuine Worksman Cycles parts. (Do not use generic bicycle parts.) With simple
maintenance, your Eagle Lite Tricycle will perform reliably day after day, year after year. Your
Eagle Lite Tricycle has been hand-made in the USA by our American craftspeople.
reputation rides along with you, so your ultimate satisfaction is our goal.
The Eagle is a light-duty tricycle. It has a recommended maximum capacity of 250 pounds,
including the rider. If you are a heavier rider, or intend to use this cycle for heavy industrial use,
we recommend our Worksman Business Cycle System of industrial, heavy-duty tricycles.
(For all freewheel, coaster brake and three-speed coaster brake Eagle Lite Tricycles.)
(For models with front drum brake wheels.)
(1266,1268,1269,1271,1272,1273,1274)
Street – Ozone Park, NY 11416 – (718) 322-2000
th
Part #
154
3950B
49
51
53
55F
55B
2002A
L752L
4905A
Part #
G219
F818
G270
Part #
174HD
69B
62
62C
404N
SS721
Part #
1265BMXS
1267G
1269
1272
1274
1380C
4910
4914R
4914W
4915
Description
Fork (Silver)
Eagle Lite Rear (coaster brake, Silver)
Headset Bearings (pair)
Bottom Cone (Presses on fork)
Key Washer
Handlebar - Junior High Rise
Handgrips (pair)
Caliper Brake Set (no cable or lever)
Brake Lever (Left) w/ Parking Lock
Bolt/Nut/Washer (rear frame to front)
Description
Drum Brake Cable w/ G269 and G270
Arm Band Assembly for Brake Arm
Adjusting Barrel for G219 Cable
Description
Wheel / Axle Bearings (each)
Fixed Drive Sprocket
Bushing for 4129A (freewheel models)
Set screw for 69B and 62
3 Speed Coaster Brake Hub
Coaster Brake Parts Kit (for 301)
Description
Deluxe Sealed Crank Set (Upgrade)
Complete Crank Set
(36T,1265,3275,1380C)
Stationary Washer (inside)
Adjusting Cone (threaded, outside)
Crank Locknut
Sprocket 36 Tooth (1/8")
Chainguard
Chain Half Link (1/8")
Chain (coaster brake 1/8"x103 links)
Chain Adjusters (for coaster brake)
Parts list EAG07
Our

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Eagle Lite and is the answer not in the manual?

Questions and answers

Woody Norsworthy
June 3, 2025

Do I need new wheels/hubs(469A and D) plus a coaster brake hub (301) when converting a freewheel to coaster brake? Will the coaster brake come with chain tensioner, etc. to make the conversion or is that the ss721 part.

Subscribe to Our Youtube Channel

Summary of Contents for Worksman Eagle Lite

  • Page 1 Always follow the rules of safe riding. Always keep your Eagle Lite tricycle in tip-top shape by replacing worn parts as needed with genuine Worksman Cycles parts. (Do not use generic bicycle parts.) With simple maintenance, your Eagle Lite Tricycle will perform reliably day after day, year after year.
  • Page 2 Worksman Trading Corporation – 94-15 100 Street – Ozone Park, NY 11416 – (718) 322-2000 www.worksmancycles.com Parts list EAG07 Seats, Seatpost, Baskets, and Fenders Part # Description Part # Description 6910V Saddle (wide w/o springs - standard) 6911V Saddle (wide w/ springs) 4908D Seatpost (15”x1”x7/8”)
  • Page 3: Tools Required For Assembly

    ASSEMBLY INSTRUCTIONS FOR THE WORKSMAN EAGLE LITE™ TRICYCLE (rev. July 2014): Please read this manual carefully prior to performing the finishing assembly and prior to riding. We strongly recommend that a qualified bicycle mechanic assemble this cycle. Carefully remove the tricycle components from the carton, and follow the instructions in the order presented.
  • Page 4 Single Speed Coaster Brake Model...
  • Page 5 Three Speed Coaster Brake Model We recommend that only qualified bicycle mechanics disassemble the hubs for maintenance.
  • Page 6: Free Wheel

    Cut excess plastic and aim cut sections away from the frame. Note: If you have a freewheel model, we recommend that you upgrade to a single- or three-speed coaster brake model. To order, call the Worksman Cycles Customer Service Center at (718) 322-2000. 3) REAR WHEEL ASSEMBLY (See illustrations) The right-side drive wheel has one bearing and a keyed slot.
  • Page 7 8. Install the handlebar stem (#55A) into the steerer tube, with the handlebar clamp facing forward. It must be inserted beyond the minimum insertion line. Loosen the handlebar clamp nut. Insert and center the handlebar into the clamp. 9. Rotate the handlebar within the clamp to the desired angle, then tighten the clamp. Pivot the handlebar about the steerer fork until it is perpendicular to the front wheel, then tighten the stem bolt.
  • Page 8: Maintenance Tips

    Parts list EAG07 MAINTENANCE TIPS: Always inspect your Worksman Cycle to ensure that all nuts, bolts, screws and hardware are tight and that no parts are worn or damaged. Do not attempt to straighten bent forks or frames. Chain: Lubricate chain once a month or as needed with light oil.
  • Page 9: Limited Warranty

    THE DEALER WILL ADVISE YOU AS TO THE COST OF REPAIR, REPLACEMENT OR LABOR PRIOR TO PERFORMING ANY WORK OR REPLACING ANY PARTS. IF YOU CHOOSE NOT TO HAVE THE DEALER OR WORKSMAN CYCLES PERFORM THE WORK, THE PARTS WILL BE RETURNED TO YOU AT YOUR EXPENSE OR DISCARDED IF NO REPLY IS RECEIVED WITHIN 2 WEEKS OF NOTIFICATION.

Table of Contents
