Stretch Mover™
Worksman
and Parts List
Models M2620-CB-STR, M2620-3CB-STR
Congratulations! You have purchased an American Made Worksman Stretch Mover™
Industrial Tricycle. The Mover™ is considered the flagship of the Worksman Business Cycle
System, which is undoubtedly the finest line of industrial cycles on earth. The Stretch Mover is the
newest addition to the Worksman Mover™ lineup. These durable tricycles are used around the
world by leading companies and organizations to move personnel and supplies efficiently, safely
and in an environmentally friendly manner. The Stretch Mover™.......the next Worksman Classic.
Before assembly and riding, make certain to read this manual and any other literature
provided thoroughly. Always follow the rules of safe riding. Always keep your Mover™ Tricycle in tip-
top shape by replacing worn parts as needed with Genuine Worksman Cycles parts (do not use
generic bicycle parts). With simple maintenance, your Worksman Mover Tricycle will perform reliably
day after day, year after year, decade after decade.
Your Stretch Mover™ Tricycle has been hand-made in the USA by our American
craftspeople. Our reputation rides along with you, so your ultimate satisfaction is our goal.
M2620-CB-STR Drum & Coaster Brake (most popular)
Worksman Mover™ Parts List M2620-STR-03
Frame, Fork and related parts
Part #
Description
MF2620STRA Mover Stretch Frame Only- Specify color
50HD-YEL
Fork- Color Safety Yellow
50HD-SP
Fork (other color- please specify)
49
Headset Bearings (pair)
51
Bottom Cone (presses on Fork)
53
Key Washer
55F
Handlebar-Junior High Rise
55B
Hand Grips (pair)
4921
Rear Leaf Springs (each)- Support platform
Front Wheel (26") and Related Parts
Part #
Description
77A
Front Wheel w/Drum Brake w/o tire
77S
Front Wheel w/Drum Brake- Solid Tire
L709
Front Axle Set for Drum Brake
F719
Front Drum Brake Cable and Casing
(includes Adjusting Barrel and Anchor Bolt)
L752R
Brake Lever w/ Parking Lock- Right Hand)
F769
Anchor Bolt Assembly for F719 Cable
Industrial Tricycles Assembly Instructions
Parts list M2620-STR-03
Worksman Stretch Mover
- T
N
W
HE
EWEST
ORKSMAN
M
™
OVER
M2620-3CB-STR Drum & 3 Speed Coaster
Part #
Description
50HD
Fork-Color Black
50HD-ORG
Fork-Safety Orange
48
Head Set Cups (pair)
50A
Headset Complete (48,49,52,53,54)
52
Top Adjusting Cone (threaded)
54
Fork Top Lock nut
55A
Stem for Handlebar
3927STPT
Rear Platform 38x26"
4926
U-Bolts (attach Springs)
Part #
Description
77
Front Wheel w/Drum Brake w/air tire
L900
Drum Brake-Hub Only
F817
Bearings-Loose 11 balls
L725
Drum Brake Plate Kit (Internal parts kit
-Shoes, Plate, Lever and Cam)
L752L
Brake Lever w/ Parking Lock- Left
F770
Adjusting Barrel For F719 Cable
™
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Worksman Stretch Mover M2620-CB-STR
Summary of Contents for Worksman Stretch Mover M2620-CB-STR
- Page 1 Always follow the rules of safe riding. Always keep your Mover™ Tricycle in tip- top shape by replacing worn parts as needed with Genuine Worksman Cycles parts (do not use generic bicycle parts). With simple maintenance, your Worksman Mover Tricycle will perform reliably day after day, year after year, decade after decade.
-
Page 2: Rear Axle And Related Parts
MSF2620-STR Side Fender Set (M2620-CB-STR) M13970 Rear Basket 6911V-5 Saddle 7228 Front Basket 23x23x16” Thickly Padded 21”x15”x9” Part #’s and Specifications subject to change without notice as we are constantly seeking ways to improve our products. ---Worksman Cycles---- Parts List M2620-STR03... -
Page 3: Wheels , Tires And Fenders
American Made Worksman Business Cycle will never let you down! Worksman Cycles…….Unmatched Quality----------Incredibly Selection----------Unmatched Enduring Value Worksman Personal Activity Vehicle Worksman Team Dual Tricycle No Fuel, No Fumes Part #’s and Specifications subject to change without notice as we are constantly seeking ways to improve our products. ---Worksman Cycles----... - Page 4 Mover™ M2620-CB-STR #22 M13975 Side Bearing with Plate #28 130 Axle Parts Set 69 Fixed Drive Sprocket 58 Axle M13975 Side Bearing Key # Part # Description Key # Part # Description MF2620STRA Frame 5020HD Fork Stem for Handlebar M13975...
-
Page 5: Installing Pedals
Assembly Instructions for The Worksman Stretch Mover™ Industrial Tricycle: Congratulations! You have purchased one of the most unique, useful, practical industrial cycles ever made. The Worksman Stretch Mover is the latest member of the Worksman Business Cycle System. Your Worksman Stretch Mover™ Industrial Tricycle has been hand made by American Craftspeople at our Ozone Park New York City Factory. - Page 6 Check chain tension regularly. Tires: Always check for worn or damaged tires. The Worksman Sup-r-tires are heavy duty. We recommend 40PSI as proper level of inflation. Replace tires that are worn or cut immediately. Replace tubes that show leaks.
