SPECIFICATIONS

Source Voltage:
120 V AC 60 Hz
Input Capacity:
552W
Power Output:
DC 15V OUT:
LAMP AC OUT: 120V AC, max. 500W, min. 250W
Pan/tilt head connecting
cables:
5 cables (2 DC power cables, 2 lamp control cables, 1 option switch control cable)
(in case of using the lamp control and option switch control functions)
Maximum cable length
30 m
Operating temperature:
–10°C to +45°C (14°F to 113°F)
Dimensions:
210(W) x 51(H) x 250(D) mm
8-1/4"(W) x 2"(H) x 9-7/8"(D)
Weight:
2.5
Finish:
AV Ivory baking
Weight and dimensions indicated are approximate.
Specifications are subject to change without notice.

ACCESORY

AC Cable .......................................................................1 pc.
DC15V 2.5A, with over-current protect circuit
kg (5.5 lbs.)
-8-
