CONNECTION

• Switch off all the devices before making any connec-
tion.
• Use the Pan/tilt Head AW-PH300.
• Connect the DC 15V OUT Terminals [+] and [–] on this
adapter to the DC 15V IN Terminals [+] and [–] on the
Pan/tilt Head (AW-PH300) respectively with cables (to
be locally purchased) with a nominal cross section of
1.25 mm
2
or more that meets the UL specifications.
The maximum allowable cable length between the
adapter and pan/tilt head is 30 meters.
Applicable (usable) wire
Solid wire:
ø1.29 (AWG 16)
Stranded wire:
1.25mm
Strand diameter ø0.18 or more
Standard bare end length:
• To switch on and off the halogen lamp from the control
panel, connect the LAMP CONTROL Input Terminals
[C] and [S] to the LAMP CONTROL Output Terminals
[C] and [S] on the pan/tilt head respectively with cables
(to be locally purchased) with a nominal cross section
of 0.3 mm
or more that meets the UL specifications.
2
The maximum allowable cable length is 30 meters.
Locally purchase an AC plug conversion cable that
matches the AC plug for the halogen lamp to be used,
and connect a halogen lamp of 250 W to 500 W to the
lamp AC outlet. If a halogen lamp of less than 250 W is
connected, the LAMP Indicator on the control panel
may flash to indicate a burnt bulb even though the
lamp is normal.
(AWG 16)
2
11 mm
-6-
Applicable wire
Solid wire:
ø1.29 (AWG 16)
Stranded wire:
1.25 mm(AWG16)
Usable wire range
Solid wire:
ø0.64 to 1.29 (AWG 22 to 16)
Stranded wire:
0.3 mm
(AWG 22 to 16)
Strand diameter ø0.18 or more
Standard bare end length:
• To control the option switch terminal to short or open
from the control panel, connect the OPTION SW CON-
TROL IN Terminal [OP] on the adapter to the OP
Output Terminal on the pan/tilt head with a cable (to be
locally purchased) with a nominal cross section of 0.3
mm
or more that meets the UL specifications. The
2
maximum capacity of the option switch terminal is
120V 1A (AC/DC).
Applicable wire
Solid wire:
ø1.02 (AWG 18)
Stranded wire:
0.75 mm
Usable wire range
Solid wire:
ø0.64 to 1.02 (AWG 22 to 18)
Stranded wire:
0.3 mm
(AWG 22 to 20)
Strand diameter ø0.18 or more
Standard bare end length:
• For details on the connection, refer to the Operating
Instructions.
2
to 1.25 mm
2
2
11 mm
2
2
to 0.75 mm
2
10 mm
