- Page 1 Model:16008600630 OWNER’S MANUAL PLEASE CAREFULLY READ THIS ENTIRE MANUAL BEFORE OPERATING YOUR NEW TREADMILL!
-
Page 2: Table Of Contents
TABLE OF CONTENTS Product Registration.....………………..……..………………………………………………..1 Important Safety Instructions...................2 Important Electrical Information................3 Important Operation Instructions................4 Assembly Pack Checklist....................6 Assembly Instructions....................8 Folding Instructions....................12 Operation of Your Treadmill..................13 Bluetooth® Connectivity...................17 Programmable Features...................18 General Maintenance....................25 Service Checklist - Diagnosis Guide................28 Exploded View Diagram.....................30 Parts List........................31 Manufacturer’s Limited Warranty………………………………………………...…......36... -
Page 3: Product Registration
Please take a moment at this time to record below the name of the dealer, their telephone number and the date of purchase for easy contact in the future. We appreciate your confidence in SOLE and we will always remember that you are the reason that we are in business. Please complete and mail your registration card today and enjoy your new treadmill. -
Page 4: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS WARNING - Read all instructions before using this appliance. DANGER - To reduce the risk of electric shock disconnect your treadmill from the electrical outlet prior to cleaning and/or service work. WARNING - To reduce the risk of burns, fire, electric shock, or injury to persons, install the treadmill on a flat level surface with access to a 110-volt, 15-amp grounded outlet with only the treadmill plugged into the circuit. -
Page 5: Important Electrical Information
IMPORTANT ELECTRICAL INFORMATION WARNING NEVER use a ground fault circuit interrupt (GFCI) wall outlet with this treadmill. As with any appliance with a large motor, the GFCI will trip often. Route the power cord away from any moving part of the treadmill including the elevation mechanism and transport wheels. NEVER remove any cover without first disconnecting AC power. -
Page 6: Important Operation Instructions
These distractions may cause you to lose balance which may result in serious injury. NEVER mount or dismount the treadmill while the belt is moving. SOLE treadmills start at a very low speed and it is unnecessary to straddle the belt during start up. Simply standing on the belt during slow acceleration is proper after you have learned to opérate the unit. - Page 7 IMPORTANT SAFETY INSTRUCTIONS READ BEFORE UNPACKING YOUR FOLDING TREADMILL Serious injury could occur if this folding treadmill is not unpacked properly. There is a Velcro strap installed around the treadmill base that prevents the treadmill from unfolding accidentally during shipping. If this strap is not removed properly the treadmill could spring open unexpectedly and cause injury if someone is standing near the treadmill when the strap is removed.
-
Page 8: Assembly Pack Checklist
ASSEMBLY PACK CHECKLIST HARDWARE STEP 2 #128.M5 Speed Nuts Clip (6 pcs) HARDWARE STEP 3 #130. 5/16" × 1/2" Button Head Socket Bolt (8 pcs) HARDWARE STEP 5 #113. Ø10 × 2T #139. 3/8" × 1-3/4" Button Head Socket Bolt (4 pcs) Split Washer (4 pcs) HARDWARE STEP 6 #175. - Page 9 HARDWARE STEP 7 #159. 5/16" × 3/4" #75. Safety Key Button Head Socket Bolt (4 pcs) HARDWARE STEP 8 #120. 5 × 16mm Tapping Screw (6 pcs) ASSEMBLY TOOLS #131. Combination M5 Allen Wrench & Phillips Head Screwdriver #132. M6 Allen Wrench Customer Service 1-888-707-1880 Dyaco Canada Inc.
-
Page 10: Assembly Instructions
ASSEMBLY INSTRUCTIONS ASSEMBLY STEP 1 1. Remove the treadmill from the carton and position it aside on a smooth, level floor. The rear should be at least 3’ from any wall. Do not remove the Velcro belt until you have removed the plastic wrap and Styrofoam from beneath the unit. - Page 11 ASSEMBLY STEP 3 HARDWARE STEP3 #130. 5/16" × 1/2" Button Head Socket Bolts (8 pcs) 1. Attach the Upright Tubes (4 & 5) onto the Frame Base (2) with eight Button Head Socket Bolts (130) by using the Combination M5 Allen Wrench & Phillips Head Screwdriver (131).
- Page 12 ASSEMBLY STEP 5 HARDWARE STEP5 #139. 3/8" × 1-3/4" Button Head Socket Bolts(4 pcs) #113. Ø10 × 2T Split Washers (4 pcs) 1. Insert the Console Assembly (52) into the Upright Tubes (4 & 5) and attach with four Button Head Socket Bolts (139) and four Split Washers (113).
- Page 13 ASSEMBLY STEP 7 HARDWARE STEP7 #159. 5/16" × 3/4" Button Head Socket Bolts (4 pcs) #75. Safety Key 1. Attach the Support tube (26) between the upright tubes (4 & 5) with four Button Head Socket Bolts (159). Tighten bolts firmly. 2.
-
Page 14: Folding Instructions
FOLDING INSTRUCTIONS Do not attempt to move the unit unless it is in the folded and locked position. Be sure the power cord is secured to avoid possible damage. Use both handrails to maneuver the unit to the desired position. ... -
Page 15: Operation Of Your Treadmill
OPERATION OF YOUR TREADMILL GETTING FAMILIAR WITH THE CONTROL PANEL F63 CONSOLE COOLING FANS SPEAKER CONTROL KEYS AUDIO IN JACK (MP3, HEADPHONE JACK CD, OR SMARTPHONE) INCLINE QUICK SPEED QUICK KEYS KEYS CONTACT HEART RATE SENSORS GETTING STARTED CONSOLES Power the treadmill on by plugging it into an appropriate wall outlet, then turn on the power switch located at the front of the treadmill below the motor hood. -
Page 16: Incline Feature
QUICK-START OPERATION Attach the Safety Key to wake display up (if not already on). Press the Start key to begin belt movement then adjust to the desired speed using the Speed ▲/▼ keys (console or handgrip). You may also use the Quick speed keys 2, 3, 4, 5, 7, 9 or 12 to adjust the speed. - Page 17 DOT MATRIX CENTER DISPLAY Eighteen columns of dots (8 hight) indicate each segment of a workout. The dots are only to show an approximate level (speed/incline) of effort. They do not necessarily indicate a specific value – only an approximate percent to compare levels of intensity.
- Page 18 the wireless chest strap. The pulse value will display anytime the upper display is receiving a pulse signal. TURNING OFF TREADMILL The display will automatically turn off – go to sleep - after 30 minutes of inactivity when in the Pause/Stop mode.
-
Page 19: Bluetooth® Connectivity
New Sole App to be used in conjunction with select Apple & Android devices! In order to help you achieve your exercise goals, Sole has added an exciting new feature to all of our products. Your new exercise machine comes equipped with a Bluetooth ®... -
Page 20: Programmable Features
PROGRAMMABLE FEATURES The have ten built-in programs: one Manual program, five preset profiles (P1-P5), two user definde programs (U1 & U2) and two Heart Rate programs (HR1 & HR2). Hill The Hill program simulates going up and down a hill. The workload will steadily increase and then decrease during the program. - Page 21 SELECTING A PROGRAM 1. Press the Program keys to view the programs on the screen then press the Enter key to select the program you would like to perform. The display will prompt you through the programming steps or you can just press the Start key to begin the program using the preset program values for age, weight and other program specific information.
-
Page 22: User Programs
USER PROGRAMS 1. Select User 1 or User 2 via the PROGRAM keys then press Enter. Note that the dot matrix display portion will have a single row of dots at the bottom (Unless there is a previously stored program). If there is a program stored under the button that is pressed, it will be retrieved. -
Page 23: Heart Rate Programs
HEART RATE PROGRAMS Before we get started, a word about Heart Rate: The old motto, “no pain, no gain”, is a myth that has been overpowered by the benefits of exercising comfortably. A great deal of this success has been promoted by the use of heart rate monitors. With the proper use of a heart rate monitor, many people find that their usual choice of exercise intensity was either too high or too low and exercise is much more enjoyable by maintaining their heart rate in the desired benefit range. -
Page 24: Rate Of Perceived Exertion
RATE OF PERCEIVED EXERTION Heart rate is important but listening to your body also has a lot of advantages. There are more variables involved in how hard you should workout than just heart rate. Your stress level, physical health, emotional health, temperature, humidity, the time of day, the last time you ate and what you ate, all contribute to the intensity at which you should workout. -
Page 25: Using Heart Rate Transmitter
USING HEART RATE TRANSMITTER How to wear your wireless chest strap transmitter: Attach the transmitter to the elastic strap using the locking parts. Adjust the strap as tightly as possible as long as the strap is not too tight to remain comfortable. Position the transmitter with the logo centered in the middle of your body facing away from your chest (some people must position the transmitter slightly left of center). - Page 26 HEART RATE CONTROL PROGRAMMING CAUTION! Heart Rate Control programs are intended for wireless transmitter chest strap. Do not use Pulse Grip bar for Heart Control. You must receive a strong/steady value in the heart rate window (See Using Heart Rate Transmitter section for instrucions on how to use). The HR1 program has a default level that is 60% of your projected heart rate maximum.
-
Page 27: General Maintenance
GENERAL MAINTENANCE BELT & DECK Your treadmill uses a very high-efficient low-friction deck. Performance is maximized when the deck is kept as clean as possible. Use a soft, damp cloth, or paper towel, wipe the edge of the belt and the area between the belt edge and the frame. -
Page 28: Tread-Belt Tracking Adjustment
IS NOT COVERED UNDER THE WARRANTY. TREADMILL BELT The walking belt on your new Sole treadmill is made of the highest quality materials designed to last even under punishing conditions. When a treadmill belt is brand new, and has been in the package for a few months before use, a common occurrence can happen;... -
Page 29: Belt/Deck Lubrication
Only lubricate your treadmill with 100% silicone treadmill lubricant. Your treadmill comes with one tube of “Lube” and extra tubes can be ordered directly from Dyaco Canada Inc. or your authorized Sole Fitness dealer. You may also use a Lube ‐n‐Walk kit that can be purchased through bothaforementioned sellers. -
Page 30: Service Checklist-Diagnosis Guide
SERVICE CHECKLIST-DIAGNOSIS GUIDE Before contacting your dealer for aid, please review the following information. It may save you both time and expense. This list includes common problems that may not be covered under the treadmill’s warranty. PROBLEM SOLUTION/CAUSE 1. Tether cord not in position. Display does not light 2. - Page 31 CALIBRATION PROCEDURE Remove the Safety Key. 2. Press and hold down the Start and Speed ▲ buttons and at the same time replace the Safety Key. Continue to hold the Start and Speed ▲ keys until the window displays “Factory settings”, then press the Enter key.
-
Page 32: Exploded View Diagram
EXPLODED VIEW DIAGRAM Customer Service 1-888-707-1880 Dyaco Canada Inc. 2016 Email: customerservice@dyaco.ca... -
Page 33: Parts List
PARTS LIST KEY NO. PART NO. DESCRIPTION Q’TY 6006301 Main Frame Frame Base 6006302 Incline Bracket 6006303 Right Upright 6006304 Left Upright 6006305 Console Support 6006306 6006307 Deck Cross Brace Outer Slide 6006308 Inner Slide 6006309 Link 6006310 6006311 Link Shaft 6006312 Shaft Bushing Fastening Bracket... - Page 34 6006341 Handpulse End Cap 6006342 Breaker Power Socket 6006343 On/Off Switch 6006344 100m/m_Connecting Wire (Black) 6006345 6006346 300m/m_Connecting Wire (White) 300m/m_Connecting Wire (Black) 6006347 800m/m_Computer Cable (Upper) 6006348 1300m/m_Computer Cable (Middle) 6006349 1200m/m_Computer Cable (Lower) 6006350 Power Cord 6006351 6006352 Console Assembly 52~1 Console Top Cover...
- Page 35 52~34 6006352-34 STOP Key 52~35 6006352-35 START Key 52~36 6006352-36 52~37 Outer Cover 6006352-37 52~38 Fan Fixing Plate 6006352-38 52~41 6006352-41 Water-resist Rubber 52~44 Speaker Iron Net (L) 6006352-44 52~45 Speaker Iron Net (R) 6006352-45 52~46 Book Rack 6006352-46 52~47 LCD Transparent Piece 6006352-47 Motor Top Cover...
- Page 36 6006388 5/16" × UNC18 × 2-3/4"_Button Head Socket Bolt 6006389 M8 × P1.25 × 60L_Hex Head Bolt M8 × P1.25 × 80L_Socket Head Cap Bolt 6006390 M8 × P1.25 × 50L_Flat Head Countersink Bolt 6006391 M8 × P1.25 × 25L_Flat Head Countersink Bolt 6006392 6006393 M3 ×...
- Page 37 60063132 M6_L Allen Wrench 60063133 Controller Back Plate 60063134 Lubricant Handgrip End Cap 60063136 Ø3.5 × 32L_Sheet Metal Screw 60063137 60063139 3/8" × UNC16 × 1-3/4"_Button Head Socket Bolt M5 × P0.8 × 15L_Phillips Head Screw 60063140 Cushion Spacer 60063145 Top Motor Cover Plate 60063147 Pedal Cover (Top)
-
Page 38: Manufacturer's Limited Warranty
TREADMILL WARRANTY Dyaco Canada Inc. warrants all its Sole treadmills’ parts, for a period of time listed below, from the date of retail sale, as determined by sale receipt. Dyaco Canada Inc.’s responsibilities include providing new or remanufactured parts, at Dyaco Canada Inc.’s option, and technical support to our independent dealers and servicing organizations. - Page 39 Please visit us online for information about our other brands and products manufactured and distributed by Dyaco Canada Inc. www.dyaco.ca www.dyaco.ca www.dyaco.ca www.dyaco.ca www.spiritfitnesscanada.ca www.spiritfitnesscanada.ca www.dyaco.ca www.dyaco.ca www.trainorsports.ca www.solefitness.ca www.dyaco.ca www.dyaco.ca www.xterrafitness.ca www.dyaco.ca Customer Service 1-888-707-1880 Dyaco Canada Inc. 2016 Email: customerservice@dyaco.ca...
- Page 40 Customer Service 1-888-707-1880 Dyaco Canada Inc. 2016 Email: customerservice@dyaco.ca...
