6. Begin driving along the desired field boundary. Cruizer will record the field
boundary path according to the vehicle position.
7. While recording, touch Boundary Mapping Menu
Pause , Stop
8. While recording a field boundary, touch Pause
a field boundary.
This feature is useful when refilling tanks or when the vehicle path is not
part of the boundary. When paused, touch the Boundary Mapping Menu
button and select Record to resume recording the boundary.
9. Touch Stop
Note: The Cruizer automatically completes the field boundary if the
vehicle returns to within one boom width of the starting point.

Field Area Display

After completing a field boundary, the Cruizer displays
the calculated field area displays in either the lower
panel of the Field Review Screen or by opening the
Boundary Mapping Menu.

Other Field Boundary Icons

The following icons and features may be used while
operating in the Field Review Mode:
• Touch the Zoom
in the Field Review Mode.
• The Pan Lock
to follow the vehicle indicator as it moves off of the screen. To enable the
Pan Lock feature, touch the Pan
displayed.
and Reset
when ready to complete the field boundary.
icons to zoom in or out
feature automatically scrolls the Field Review display
boundary icons.
to pause recording of
icon until the Pan Lock icon is
to access the
