A-B Tools; Recording A Field Boundary - Raven Cruizer Operation Manual

A-B Tools:

Recording a Field Boundary

Recording a field boundary allows the operator to define the field area. Once
a field boundary is completed, the Cruizer displays the shape of the field and
will also calculate the total acreage within the field boundary.
1. Begin with the vehicle stopped at the beginning of the field boundary.
2. From the Home
3. Select New Job to start a new coverage map or select Resume to add to
an existing coverage map. Touch Next
4. If Clear History is selected, choose a pattern to use during the job. See
the Starting Guidance
patterns.
5. Next, touch Boundary Mapping Menu
1 1
A-B Line Tools - Select this icon to access the available
A-B line tools and features. This icon is only displayed
when an A-B line has been set.
Reset A-B Line - Clear the displayed A-B line. Touch this
icon to set a new Guidance path.
Recalibration A-B Line - Adjust the displayed A-B line to
the current vehicle location.
Nudge A-B Line - Touch these icons to nudge the A-B line
to the left or right in 1 inch [2 cm] increments. This feature
is especially useful when used with an automated steering
system to adjust the guidance path for actual field
conditions.
Screen, touch Start Guidance
section on page 6 for a detailed description of
.
to continue.
Record .
