Heat output III

Temperature set: 70/50/20 °C
Panel length
1.00 - 1.19 m
1.20 - 1.39 m
1.40 - 1.59 m
1.60 - 1.79 m
1.80 - 1.99 m
2.00 - 2.19 m
2.20 - 2.39 m
2.40 - 2.59 m
2.60 - 2.79 m
2.80 - 2.99 m
3.00 - 3.19 m
3.20 - 3.39 m
3.40 - 3.50 m
Temperature set: 65/45/20 °C
Panel length
1.00 - 1.19 m
1.20 - 1.39 m
1.40 - 1.59 m
1.60 - 1.79 m
1.80 - 1.99 m
2.00 - 2.19 m
2.20 - 2.39 m
2.40 - 2.59 m
2.60 - 2.79 m
2.80 - 2.99 m
3.00 - 3.19 m
3.20 - 3.39 m
3.40 - 3.50 m
14
Heat output
64 W
134 W
212 W
295 W
380 W
467 W
555 W
643 W
732 W
821 W
910 W
1,000 W
1.089 W
Heat output
49 W
108 W
174 W
245 W
319 W
394 W
470 W
548 W
625 W
703 W
781 W
859 W
938 W
VD.YC.D2.02 © Danfoss 01/2006
(Fan speed: 1500 RPM)
Flow
3 l/h
6 l/h
9 l/h
13 l/h
17 l/h
21 l/h
24 l/h
28 l/h
32 l/h
36 l/h
40 l/h
44 l/h
48 l/h
(Fan speed: 1500 RPM)
Flow
2 l/h
5 l/h
8 l/h
11 l/h
14 l/h
17 l/h
21 l/h
24 l/h
27 l/h
31 l/h
34 l/h
38 l/h
41 l/h
